EI-42
EXTERIOR/INTERIOR TRIM
ROOF TRIM
21.Roof Trim
A: REMOVAL
CAUTION:
When removing clip, use great care not to dam-
age the roof trim.
1. SEDAN
1) Disconnect ground cable from battery.
2) Remove sunroof switch. (Sunroof equipped
model) <Ref. to SR-14, REMOVAL, Sunroof
Switch.>
3) Remove room light. <Ref. to LI-32, REMOVAL,
Room Light.>
4) Remove sun visor and hook of both sides. <Ref.
to EI-41, REMOVAL, Sun Visor.>
5) Remove assist grips (A).
6) Remove sunroof garnish (A).
7) Remove upper inner trim. <Ref. to EI-38, RE-
MOVAL, Upper Inner Trim.>
8) Remove rear window mole (A) of both sides.
9) Remove screw (B) of rear quarter lower trim
shown in the figure.
10) Remove rear quarter upper trim (C) of both
sides.
11) Remove clips, and then remove roof trim.
2. WAGON
1) Open the rear sunroof, and then remove four
clips. (Sunroof equipped model)
2) Disconnect ground cable from battery.
3) Remove sunroof switch. (Sunroof equipped
model) <Ref. to SR-14, REMOVAL, Sunroof
Switch.>
4) Remove room light and luggage room light.
<Ref. to LI-32, REMOVAL, Room Light.> and
<Ref. to LI-33, REMOVAL, Luggage Room Light.>
5) Remove sun visor and hook of both sides. <Ref.
to EI-41, REMOVAL, Sun Visor.>
EI-00201
( A )
EI-00202
( a )
EI-00197
( A )
( B )
( C )
EI-00204
( A )
( A )
EI-00205
