SE-2

SEATS

GENERAL DESCRIPTION

1. General Description

A: COMPONENT

1. FRONT SEAT

SE-00197

b

a

( 1 )

( 2 )

( 3 )

( 4 )

( 5 )

( 6 )

( 7 )

( 8 )

( 9 )

( 9 )

(10)

(10)

(10)

(10)

( 9 )

(10)

(10)

(11)

(12)

(13)

(13)

(14)

T2

T1

T2

T1

T1

T3

T1

T2

T2

T2

T1

T1

( A )

( B )

SE-3

SEATS

GENERAL DESCRIPTION

(A) Standard seat

(6) Seat cushion pad

Tightening troque: N·m (kgf-m, ft-lb)

(B) Power seat

(7) Slide rail inner ASSY

T1: 30 (3.1, 22)

(a) 8-way power seat

(8) Slide rail outer ASSY

T2: 53 (5.4, 39)

(b) 6-way power seat

(9) Hinge ASSY

T3: 10 (1.0, 7)

(1) Seat back pad

(10) Hinge cover

(2) Headrest

(11) Rod

(3) Seat back board

(12) Slide and unit ASSY

(4) Seat back frame ASSY

(13) Power seat harness

(5) Seat cushion frame ASSY

(14) Side airbag module

SE-4

SEATS

GENERAL DESCRIPTION

2. REAR SEAT (SEDAN)

(1) Backrest

(3) Cushion

Tightening troque: N·m (kgf-m, ft-lb)

(2) Head restraint

T: 24.5 (2.50, 18.1)

SE-00251

( 1 )

( 2 )

( 2 )

( 2 )

( 3 )

T

SE-5

SEATS

GENERAL DESCRIPTION

3. REAR SEAT (WAGON)

(1) Cover

(5) Backrest RH

Tightening troque: N·m (kgf-m, ft-lb)

(2) Cushion RH

(6) Backrest LH

T1: 10 (1.0, 7.2)

(3) Cushion LH

(7) Head restraint

T2: 24.5 (2.50, 18.1)

(4) Hook

T3: 33 (3.40, 24.1)

SE-00198

( 1 )

( 2 )

( 3 )

( 4 )

( 5 )

T3

T1

T3

T3

T2

( 6 )

( 7 )

( 7 )
