AB-14

AIRBAG SYSTEM (DIAGNOSTICS)

GENERAL DESCRIPTION

6. AIRBAG RESISTOR

The airbag resistor is used during diagnostics. The airbag resistor has the same resistance as the airbag
module and thus provides safety when used instead of the airbag module. It also makes it possible to finish,
diagnostics in less time.

AB-00067

PN 98299PA040

3

Y
R

4

1

2

3

6 5 4

Y
R

2

1

3

1
2

AB-15

AIRBAG SYSTEM (DIAGNOSTICS)

ELECTRICAL COMPONENTS LOCATION

4. Electrical Components Location

A: LOCATION

1. LHD MODEL

(1) Front sub sensor (LH)

(7) Roll connector

(13) Side airbag sensor (RH)

(2) Front sub sensor (RH)

(8) Airbag main harness

(14) Side airbag inflator (LH)

(3) Front sub sensor harness (LH)

(9) Inflator (Driver)

(15) Side airbag inflator (RH)

(4) Front sub sensor harness (RH)

(10) Side airbag harness (LH)

(a) To body harness

(5) Airbag control module with safety

sensor and electric sensor

(11) Side airbag harness (RH)

(b) To seal belt pretensioner (LH)

(12) Side airbag sensor (LH)

(c) To seal belt pretensioner (RH)

(6) Inflator (Passenger)

Connec-

tor No.

(AB1)

(AB2)

(AB3)

(AB6)

(AB7)

(AB8)

(AB9)

(AB10)

(AB11)

(AB12)

(AB13)

(AB14)

Pole

12

2

2

28

2

2

2

2

2

2

2

2

Color

Yellow

Yellow

Yellow

Yellow

Black

Yellow

Yellow

Yellow

Blue

Blue

Yellow

Blue

Male/

Female

Male

Male

Male

Female

Female

Female

Female

Male

Male

Female

Female

Male

Connec-

tor No.

(AB15)

(AB16)

(AB17)

(AB18)

(AB19)

(AB20)

(AB21)

(AB23)

(AB24)

(AB25)

(AB26)

(AB28)

Pole

2

2

12

12

2

2

2

4

2

2

2

4

Color

Blue

Yellow

Yellow

Yellow

Yellow

Yellow

Yellow

Yellow

Yellow

Yellow

Yellow

Yellow

Male/

Female

Female

Female

Female

Female

Female

Male

Female

Female

Female

Male

Female

Female

AB16

AB8

AB3

AB18

AB6

( 1 )

( 2 )

( 4 )

( 6 )

(14)

( a )

AB15

AB14

AB13

( 3 )

AB12

AB11

B31

AB1

( 8 )

( 7 )

AB17

( 9 )

(15)

(13)

(11)

AB26

( c )

AB28

AB25

AB24

AB20

AB19

AB9

AB10

( 5 )

(12)

(10)

AB21

( b )

AB23

AB7

AB-00347

AB-16

AIRBAG SYSTEM (DIAGNOSTICS)

ELECTRICAL COMPONENTS LOCATION

2. RHD MODEL

(1) Front sub sensor (LH)

(7) Roll connector

(13) Side airbag sensor (RH)

(2) Front sub sensor (RH)

(8) Airbag main harness

(14) Side airbag inflator (LH)

(3) Front sub sensor harness (LH)

(9) Inflator (Driver)

(15) Side airbag inflator (RH)

(4) Front sub sensor harness (RH)

(10) Side airbag harness (LH)

(a) To body harness

(5) Airbag control module with safety

sensor and electric sensor

(11) Side airbag harness (RH)

(b) To seal belt pretensioner (LH)

(12) Side airbag sensor (LH)

(c) To seal belt pretensioner (RH)

(6) Inflator (Passenger)

Connec-

tor No.

(AB1)

(AB2)

(AB3)

(AB6)

(AB7)

(AB8)

(AB9)

(AB10)

(AB11)

(AB12)

(AB13)

(AB14)

Pole

12

2

2

28

2

2

2

2

2

2

2

2

Color

Yellow

Yellow

Yellow

Yellow

Black

Yellow

Yellow

Yellow

Blue

Blue

Yellow

Blue

Male/

Female

Male

Male

Male

Female

Female

Female

Female

Male

Male

Female

Female

Male

Connec-

tor No.

(AB15)

(AB16)

(AB17)

(AB18)

(AB19)

(AB20)

(AB21)

(AB23)

(AB24)

(AB25)

(AB26)

(AB28)

Pole

2

2

12

12

2

2

2

4

2

2

2

4

Color

Blue

Yellow

Yellow

Yellow

Yellow

Yellow

Yellow

Yellow

Yellow

Yellow

Yellow

Yellow

Male/

Female

Female

Female

Female

Female

Female

Male

Female

Female

Female

Male

Female

Female

AB-00348

AB25

AB24

AB20

AB19

AB9

AB10

AB18

B31

AB16

AB13

AB15

AB14

AB8

AB3

AB26

AB28

AB7

AB17

AB6

AB23

AB21

AB12

AB11

AB1

( 2 )

( 3 )

( 4 )

( 5 )

( 6 )

( 7 )

( 8 )

( 9 )

(10)

(11)

(12)

(13)

(14)

(15)

( a )

( b )

( c )

( 1 )

AB-17

AIRBAG SYSTEM (DIAGNOSTICS)

AIRBAG CONNECTOR

5. Airbag Connector

A: OPERATION

1. POWER SUPPLY

1) How to disconnect:

(1) Move the slide lock (A) in the direction of the
arrow.
(2) Pull the female connector in the direction of
the arrow with slide lock (A) moved.

CAUTION:
When pulling, be sure to hold onto the conector
and not the wire.
2) How to connect:
Holding the connector (A), and push it in carefully
until a connecting sound is head.

CAUTION:
Be sure to insert the connector in until it locks.
Then pull on it gently to make sure that it is
locked.

2. DRIVER'S AIRBAG, PASSENGER’S AIR-
BAG, SIDE AIRBAG, FRONT SUB SENSOR
HARNESS TO AIRBAG MAIN HARNESS
AND PRETENSIONER

1) How to disconnect:

(1) Push lock arm (A).
(2) With lock arm (A) pushed in, move slide lock
(B) in the direction of the arrow.

(3) With slide lock (B) pulled, remove lock arm
(A) to its original position, and then pull in the di-
rection of the arrow and separate the connector.

CAUTION:
When pulling, be sure to hold onto the connec-
tor and not the wire.

2) How to connect:
Holding the connector, and push it in carefully until
a connecting sound is heard.

CAUTION:
Be sure to insert the connector in until it locks.
Then pull on it gently to make sure that it is
locked.

AB-00015

( A )

AB-00016

( A )

AB-00017

( A )

( B )

AB-00018

AB-00019
