AC-4
HVAC SYSTEM (HEATER, VENTILATOR AND A/C)
GENERAL DESCRIPTION
• RHD Model
Item
Specifications
Type of air conditioner
Reheat air-mix type
Cooling capacity
4.7 kW (4,041 kcal/h, 16,035 BTU/h)
Refrigerant
HFC-134a (CH
2
FCF
3
)
[0.45
±
0.05 kg (0.99
±
0.11 lb)]
Compressor
Type
Through vane type (TV-12C)
Discharge
127 cm
3
(7.75 cu in)/rev
Max. permissible speed
6,000 rpm
Magnet clutch
Type
Dry, single-disc type
Power consumption
40 W
Type of belt
V-Ribbed 4 PK
Pulley dia. (effective dia.)
120 mm (4.72 in)
Pulley ratio
1.11
Condenser
Type
Corrugated fin (Sub cool type)
Core face area
0.19 m
2
(2.04 sq ft)
Core thickness
16 mm (0.63 in)
Radiation area
4.786 m
2
(51.50 sq ft)
Receiver drier
Effective inner capacity
250 cm
3
(15.26 cu in)
Expansion valve
Type
Externally equalizing
Evaporator
Type
Multi tank
Dimensions (W
×
H
×
T)
214.4
×
195
×
58 mm
(8.44
×
7.68
×
2.28 in)
Blower fan
Fan type
Sirocco fan
Outer diameter
×
width
150
×
75 mm (5.91
×
2.95 in)
Power consumption
220 W at 12 V
Condenser fan (Sub fan)
Motor type
Magnet
Power consumption
75 W at 12 V
Fan outer diameter
300 mm (11.81 in)
Radiator fan (Main fan)
Motor type
Magnet
Power consumption
75 W at 12 V
Fan outer diameter
300 mm (11.81 in)
Idling speed (A/C ON)
MPFI model
850
±
100 rpm
Dual switch
(Pressure
switch)
Low-pressure
switch operat-
ing pressure
ON
→
OFF
196
±
20 kPa
(2.0
±
0.2 kg/cm
2
, 28.4
±
2.8 psi)
OFF
→
ON
226
±
29 kPa
(2.3
±
0.3 kg/cm
2
, 33
±
4 psi)
High-pres-
sure switch
operating
pressure
ON
→
OFF
3,138
±
196 kPa
(32
±
2 kg/cm
2
, 455
±
28 psi)
DIFF
588
±
196 kPa
(6
±
2 kg/cm
2
, 85
±
28 psi)
OFF
→
ON
2,550
±
196 kPa
(26
±
2 kg/cm
2
, 370
±
28 psi)
Thermo control amplifier
working temperature
(Evaporator outlet air)
(1) 1±0.5
°
C (34±0.9
°
F)
(2) 3±1.5
°
C (37±2.7
°
F)
(3) Repeat
AC-00459
( 1 )
( 2 )
( 3 )
OFF
ON
