CS-24
CONTROL SYSTEMS
DRIVE SELECT CABLE
D: ADJUSTMENT
1) Set the drive select lever to HI position.
2) Remove the knob.
3) Remove console box. <Ref. to EI-34, REMOV-
AL, Console Box.>
4) Loosen the nut.
5) Make sure transmission is in HI position. If isn't,
pull on cable to put transmission in HI position.
6) Tighten the nut in the location where the cable
end bolt stops naturally.
Tightening torque:
18 N·m (1.8 kgf-m, 13.0 ft-lb)
7) Make sure to move transmission to HI or LO po-
sition by moving the drive select lever. If it doesn't,
readjust cable.
CS-00190
( A )
CS-00104
CS-00104
