EN(H4DOSTC)-34
ENGINE (DIAGNOSTICS)
INSPECTION MODE
5) Connect the Subaru Select Monitor to data link
connector.
(1) Connect the Subaru Select Monitor to data
link connector located in the lower portion of in-
strument panel (on the driver's side).
(2) Connect the diagnosis cable to data link
connector.
CAUTION:
Do not connect scan tools except for the
Subaru Select Monitor and OBD-II general scan
tool.
6) Turn the ignition switch to ON (engine OFF) and
Subaru Select Monitor switch to ON.
7) On the «Main Menu» display screen, select the
{2. Each System Check} and press [YES] key.
8) On the «System Selection Menu» display
screen, select the {Engine Control System} and
press [YES] key.
9) Press the [YES] key after displayed the informa-
tion of engine type.
10) On the «Engine Diagnosis» display screen, se-
lect the {Dealer Check Mode Procedure} and press
[YES] key.
11) When the “Perform Inspection (Dealer Check)
Mode?” is shown on the display screen, press
[YES] key.
12) Perform subsequent procedures as instructed
on the display screen.
• If trouble still remains in the memory, the corre-
sponding diagnostic trouble code (DTC) appears
on the display screen.
NOTE:
• For detailed operation procedure, refer to the
SUBARU SELECT MONITOR OPERATION MAN-
UAL.
• For detailed concerning diagnostic trouble
codes, refer to the List of Diagnostic Trouble Code
(DTC). <Ref. to EN(H4DOSTC)-62, List of Diag-
nostic Trouble Code (DTC).>
• Release the parking brake.
• The speed difference between front and rear
wheels may light either the ABS warning light, but
this indicates no malfunctions. When engine con-
trol diagnosis is finished, perform the ABS memory
clearance procedure of self-diagnosis system.
(A) Power switch
EN-00999
EN-00040
( A )
