EN(H6DO)-18
ENGINE (DIAGNOSTICS)
ELECTRICAL COMPONENTS LOCATION
• LHD model
• RHD model
EN-01142
( 1 )
( 2 )
( 3 )
( 4 )
( 5 )
( 6 )
( 7 )
( 8 )
( 9 )
(10)
(1) Inhibitor switch
(5) Radiator main fan relay-1
(9) Starter
(2) Fuel pump
(6) Radiator sub fan relay-1
(10) Fuel pump controller
(3) Main relay
(7) Radiator main fan relay-2
(4) Fuel pump relay
(8) Radiator sub fan relay-2
EN-01143
( 1 )
( 2 )
( 3 )
(10)
( 4 )
( 5 )
( 6 )
( 7 )
( 8 )
( 9 )
