EN(H6DO)-10
ENGINE (DIAGNOSTICS)
ELECTRICAL COMPONENTS LOCATION
4. Electrical Components Location
A: LOCATION
1. ENGINE
• MODULE
• LHD model
• RHD model
EN-01065
( 1 )
( 2 )
( 3 )
( 4 )
(1) Engine control module (ECM)
(3) Test mode connector
(2) Data link connector (for Subaru
Select Monitor and OBD-II general
scan tool)
(4) CHECK ENGINE malfunction indi-
cator lamp (MI)
EN-01066
( 1 )
( 2 )
( 3 )
( 4 )
