EI-75
Ornament
EXTERIOR/INTERIOR TRIM
33.Ornament
A: INSTALLATION
1. LETTER MARK
Adhere the letter mark according to the following position.
• 5 door model
• 4 door model
(1)
Match the end of the application tape to the end of the
rear gate panel.
(2)
Application tape
(1)
Match the end of the application tape to the end of the
trunk lid garnish.
(3)
Bend the slit of the application tape to fit along the end
of the trunk panel.
(2)
Application tape
EI-02892
(2)
A-A
A
A
(1)
(1)
(1)
(2)
A-A
A
A
(1)
(1)
(1)
(2)
A-A
EI-03239
(3)
B-B
A
A
B
B
B
B
(1)
(1)
A
A
