AB-27
Roll Connector
AIRBAG SYSTEM
D: ADJUSTMENT
CAUTION:
• Do not rotate the roll connector to more than
the specified number of turns. Otherwise, the
roll connector internal wire may be broken.
• When determining the end stop, rotate the
connector slowly without applying excessive
force. Applying excessive force at the end stop
may break the internal wire.
1) Check that front wheels are positioned in straight
ahead direction.
2) Turn the roll connector pin (A) clockwise until it
stops.
3) Turn the roll connector pins (A) approx. 3.25
turns in the counterclockwise direction until “ ”
marks are aligned.
AB-02078
(A)
