GD(H4DOTC)-216

Diagnostic Trouble Code (DTC) Detecting Criteria

GENERAL DESCRIPTION

DY:DTC P2004 INTAKE MANIFOLD RUNNER CONTROL STUCK OPEN (BANK 1)

1. OUTLINE OF DIAGNOSIS

Detect the malfunction of tumble generator valve motor function.

Judge open fixing malfunction when the opening degree is large even after finishing the tumble generator

valve closing driving.

2. ENABLE CONDITIONS

3. GENERAL DRIVING CYCLE

Always perform the diagnosis continuously.

4. DIAGNOSTIC METHOD

• Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Time Needed for Diagnosis: 3000 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
• Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more

than the predetermined time.

Time Needed for Diagnosis: Less than 1 second

Secondary Parameters

Enable Conditions

Battery voltage

≥ 10.9 V

Engine coolant temperature

≥ –40 °C (–40 °F)

Ambient air temperature

≥ –40 °C (–40 °F)

Judgment Value

Malfunction Criteria

Threshold Value

Tumble generator valve opening

≥ 64.3 °

Tumble generator valve “close” signal
output

≥ 3200 ms

Judgment Value

Malfunction Criteria

Threshold Value

Tumble generator valve opening

< 64.3 °

Tumble generator valve “close” signal
output

≥ 3200 ms

GD(H4DOTC)-217

Diagnostic Trouble Code (DTC) Detecting Criteria

GENERAL DESCRIPTION

DZ:DTC P2005 INTAKE MANIFOLD RUNNER CONTROL STUCK OPEN (BANK 2)

1. OUTLINE OF DIAGNOSIS

Detect the malfunction of tumble generator valve motor function.

Judge open fixing malfunction when the opening degree is large even after finishing the tumble generator

valve closing driving.

2. ENABLE CONDITIONS

3. GENERAL DRIVING CYCLE

Always perform the diagnosis continuously.

4. DIAGNOSTIC METHOD

• Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Time Needed for Diagnosis: 3000 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
• Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more

than the predetermined time.

Time Needed for Diagnosis: Less than 1 second

Secondary Parameters

Enable Conditions

Battery voltage

≥ 10.9 V

Engine coolant temperature

≥ –40 °C (–40 °F)

Ambient air temperature

≥ –40 °C (–40 °F)

Judgment Value

Malfunction Criteria

Threshold Value

Tumble generator valve opening

≥ 64.3 °

Tumble generator valve “close” signal output

≥ 3200 ms

Judgment Value

Malfunction Criteria

Threshold Value

Tumble generator valve opening

< 64.3 °

Tumble generator valve “close” signal output

≥ 3200 ms

GD(H4DOTC)-218

Diagnostic Trouble Code (DTC) Detecting Criteria

GENERAL DESCRIPTION

EA:DTC P2006 INTAKE MANIFOLD RUNNER CONTROL STUCK CLOSED

(BANK 1)

1. OUTLINE OF DIAGNOSIS

Detect the malfunction of tumble generator valve motor function.

Judge close fixing malfunction when the opening degree is small even after finishing the tumble generator

valve open driving.

2. ENABLE CONDITIONS

3. GENERAL DRIVING CYCLE

Always perform the diagnosis continuously.

4. DIAGNOSTIC METHOD

• Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Time Needed for Diagnosis: 3000 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
• Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more

than the predetermined time.

Time Needed for Diagnosis: Less than 1 second

Secondary Parameters

Enable Conditions

Battery voltage

≥ 10.9 V

Engine coolant temperature

≥ –40 °C (–40 °F)

Ambient air temperature

≥ –40 °C (–40 °F)

Judgment Value

Malfunction Criteria

Threshold Value

Tumble generator valve opening

< 64.3 °

Tumble generator valve “open” signal output

≥ 4600 ms

Judgment Value

Malfunction Criteria

Threshold Value

Tumble generator valve opening

≥ 64.3 °

Tumble generator valve “open” signal
output

≥ 4600 ms

GD(H4DOTC)-219

Diagnostic Trouble Code (DTC) Detecting Criteria

GENERAL DESCRIPTION

EB:DTC P2007 INTAKE MANIFOLD RUNNER CONTROL STUCK CLOSED

(BANK 2)

1. OUTLINE OF DIAGNOSIS

Detect the malfunction of tumble generator valve motor function.

Judge close fixing malfunction when the opening degree is small even after finishing the tumble generator

valve open driving.

2. ENABLE CONDITIONS

3. GENERAL DRIVING CYCLE

Always perform the diagnosis continuously.

4. DIAGNOSTIC METHOD

• Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Time Needed for Diagnosis: 3000 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
• Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more

than the predetermined time.

Time Needed for Diagnosis: Less than 1 second

Secondary Parameters

Enable Conditions

Battery voltage

≥ 10.9 V

Engine coolant temperature

≥ –40 °C (–40 °F)

Ambient air temperature

≥ –40 °C (–40 °F)

Judgment Value

Malfunction Criteria

Threshold Value

Tumble generator valve opening

< 64.3 °

Tumble generator valve “open” signal output

≥ 4600 ms

Judgment Value

Malfunction Criteria

Threshold Value

Tumble generator valve opening

≥ 64.3 °

Tumble generator valve “open” signal output

≥ 4600 ms
