GD(H4DOTC)-136

Diagnostic Trouble Code (DTC) Detecting Criteria

GENERAL DESCRIPTION

BZ:DTC P0351 IGNITION COIL A PRIMARY/SECONDARY CIRCUIT

1. OUTLINE OF DIAGNOSIS

Based on the self-diagnostic result of the ignition coil driving IC, judge the ignition coil driving circuit as normal

or abnormal.

The ignition coil driving IC detects “no ignition” status as a malfunction.

2. ENABLE CONDITIONS

3. GENERAL DRIVING CYCLE

Always perform the diagnosis continuously.

4. DIAGNOSTIC METHOD

• Abnormality Judgment
Judge as NG when the following conditions are established.

Time Needed for Diagnosis: 2500 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
• Normality Judgment
Judge as OK and clear the NG if the following conditions are established.

Time Needed for Diagnosis: Less than 1 second

CA:DTC P0352 IGNITION COIL B PRIMARY/SECONDARY CIRCUIT

1. OUTLINE OF DIAGNOSIS

NOTE:

For the detection standard, refer to DTC P0351. <Ref. to GD(H4DOTC)-136, DTC P0351 IGNITION COIL A

PRIMARY/SECONDARY CIRCUIT, Diagnostic Trouble Code (DTC) Detecting Criteria.>

CB:DTC P0353 IGNITION COIL C PRIMARY/SECONDARY CIRCUIT

1. OUTLINE OF DIAGNOSIS

NOTE:

For the detection standard, refer to DTC P0351. <Ref. to GD(H4DOTC)-136, DTC P0351 IGNITION COIL A

PRIMARY/SECONDARY CIRCUIT, Diagnostic Trouble Code (DTC) Detecting Criteria.>

CC:DTC P0354 IGNITION COIL D PRIMARY/SECONDARY CIRCUIT

1. OUTLINE OF DIAGNOSIS

NOTE:

For the detection standard, refer to DTC P0351. <Ref. to GD(H4DOTC)-136, DTC P0351 IGNITION COIL A

PRIMARY/SECONDARY CIRCUIT, Diagnostic Trouble Code (DTC) Detecting Criteria.>

Secondary Parameters

Enable Conditions

Battery voltage

≥ 10.9 V

Elapsed time after starting the engine

> 1 s

Engine speed

> 500 rpm

Ignition energization time

> 2000 µs

Ignition status

Not during ignition cut

Judgment Value

Malfunction Criteria

Threshold Value

Ignition driving IC information

Malfunction

Judgment Value

Malfunction Criteria

Threshold Value

Ignition driving IC information

Normal

GD(H4DOTC)-137

Diagnostic Trouble Code (DTC) Detecting Criteria

GENERAL DESCRIPTION

CD:DTC P0365 CAMSHAFT POSITION SENSOR “B” CIRCUIT (BANK 1)

1. OUTLINE OF DIAGNOSIS

Detect the open or short circuit of the camshaft position sensor.

When there is no camshaft position signal input continuously, judge as NG.

2. ENABLE CONDITIONS

3. GENERAL DRIVING CYCLE

Always perform the diagnosis continuously.

4. DIAGNOSTIC METHOD

• Abnormality Judgment
Judge as NG when no input of camshaft position sensor signal in TDC remains for 10 time(s).

Time Needed for Diagnosis: TDC × 10 time(s)

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
• Normality Judgment
Judge as OK and clear the NG when the malfunction criteria below are met.

Time Needed for Diagnosis: Two engine revs.

Secondary Parameters

Enable Conditions

Battery voltage

≥ 8 V

Elapsed time after starting the engine

≥ 200 ms

Judgment Value

Malfunction Criteria

Threshold Value

No camshaft position sensor signal input in TDC

≥ 10 time(s)

Judgment Value

Malfunction Criteria

Threshold Value

No camshaft position sensor signal input in TDC

 = 0 time(s)

GD(H4DOTC)-138

Diagnostic Trouble Code (DTC) Detecting Criteria

GENERAL DESCRIPTION

CE:DTC P0366 CAMSHAFT POSITION SENSOR B CIRCUIT RANGE/PERFOR-

MANCE (BANK 1)

1. OUTLINE OF DIAGNOSIS

Detect the malfunction of camshaft position sensor property.

Judge as NG when the number of camshaft signals remains abnormal.

2. ENABLE CONDITIONS

3. GENERAL DRIVING CYCLE

Always perform the diagnosis continuously.

4. DIAGNOSTIC METHOD

• Abnormality Judgment
Judge as NG when the status where the number of camshaft position sensor signal in two crankshaft revo-

lutions is other than 2 time(s).

Time Needed for Diagnosis: Two engine revs. × 4 time(s)

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
• Normality Judgment
Judge as OK and clear the NG when the malfunction criteria below are met.

Time Needed for Diagnosis: Two engine revs.

CF:DTC P0390 CAMSHAFT POSITION SENSOR “B” CIRCUIT (BANK 2)

1. OUTLINE OF DIAGNOSIS

NOTE:

For the detection standard, refer to DTC P0365. <Ref. to GD(H4DOTC)-137, DTC P0365 CAMSHAFT PO-

SITION SENSOR “B” CIRCUIT (BANK 1), Diagnostic Trouble Code (DTC) Detecting Criteria.>

CG:DTC P0391 CAMSHAFT POSITION SENSOR B CIRCUIT RANGE/PERFOR-

MANCE (BANK 2)

1. OUTLINE OF DIAGNOSIS

NOTE:

For the detection standard, refer to DTC P0366. <Ref. to GD(H4DOTC)-138, DTC P0366 CAMSHAFT PO-

SITION SENSOR B CIRCUIT RANGE/PERFORMANCE (BANK 1), Diagnostic Trouble Code (DTC) Detect-

ing Criteria.>

Secondary Parameters

Enable Conditions

Battery voltage

≥ 8 V

Elapsed time after starting the engine

≥ 200 ms

Judgment Value

Malfunction Criteria

Threshold Value

Amount of camshaft sensor signal during 2 revs of crankshaft.

≠ 2 time(s)

Judgment Value

Malfunction Criteria

Threshold Value

Camshaft position sensor signal

 = 2 time(s)

GD(H4DOTC)-139

Diagnostic Trouble Code (DTC) Detecting Criteria

GENERAL DESCRIPTION

CH:DTC P0410 SECONDARY AIR INJECTION SYSTEM

1. OUTLINE OF DIAGNOSIS

Detect NG judging from secondary air delivery pipe pressure, pulse of secondary air delivery pipe pressure

and secondary air pipe airflow amount.

2. ENABLE CONDITIONS

3. GENERAL DRIVING CYCLE

Perform diagnosis during secondary air pump operation

Secondary Parameters

Enable Conditions

Pump supply pressure check



Estimate ambient temperature

≥ 4.4 °C

Battery voltage

≥ 10.9 V

Atmospheric pressure

≥ 75 kPa (563 mmHg, 22.2 inHg)

Engine

In operation

Amount of intake air

≥ 2 g/s (0.07 oz/s)

Secondary air pump

Operating

Combination valve

Bank open (Except with both
banks closed)

Combination valve both closed pulse diagnosis



Estimate ambient temperature

≥ 4.4 °C

Battery voltage

≥ 10.9 V

Atmospheric pressure

≥ 75 kPa (563 mmHg, 22.2 inHg)

Engine

In operation

Engine load

≥ 0.2 g/rev (0.01 oz/rev)

After fuel cut

≥ 1000 ms

Combination valve changeover pressure diagnosis
Estimate ambient temperature

≥ 4.4 °C

Battery voltage

≥ 10.9 V

Atmospheric pressure

≥ 75 kPa (563 mmHg, 22.2 inHg)

Engine

In operation

Amount of intake air

> 2 g/s (0.07 oz/s)
and
< 25 g/s (0.88 oz/s)

Engine speed

< 4000 rpm

After fuel cut

≥ 1000 ms

Overflow diagnosis



Estimate ambient temperature

≥ 4.4 °C

Battery voltage

≥ 10.9 V

Atmospheric pressure

≥ 75 kPa (563 mmHg, 22.2 inHg)

Engine

In operation
