Engine Trouble in General

MECHANICAL

25.Engine Trouble in General

A: INSPECTION

NOTE:

The “RANK” shown in the chart shows the possibilities of the cause of trouble in order from “Very often” to

“Rarely”.

A — Very often

B — Sometimes

C — Rarely

Symptoms

Problem parts etc.

Possible cause

RANK

1. Engine does not start.



1) Starter does not turn.

Starter

Defective battery-to-starter harness

B

Defective starter switch

C

Defective starter

B

Battery

Improper connection of terminal

A

Run-down battery

A

Defective charging system

B

Friction

Seizure of crankshaft and connecting rod bearing

C

Seized camshaft

C

Seized or stuck piston and cylinder

C

Immobilizer system <Ref. to IM(diag)-2, Basic Diagnostic Procedure.>

A

2) Initial combustion does
not occur.

Starter

Defective starter

C

Engine control system <Ref. to EN(H4DOTC)(diag)-2, Basic Diagnostic Procedure.>

A

Fuel line

Defective fuel pump and relay

A

Clogged fuel line

C

Lack of fuel or insufficient fuel

B

Timing belt

Degradation, etc.

B

Defective timing

B

Compression

Incorrect valve clearance

C

Loosened spark plug or defective gasket

C

Loosened cylinder head bolt or defective cylinder head
gasket

C

Improper valve sealing

C

Defective valve stem

C

Worn or broken valve spring

B

Worn or stuck piston rings, cylinder and piston

C

Incorrect valve timing

B

Improper engine oil (low viscosity)

B

ME(w/o STI)-104

Engine Trouble in General

MECHANICAL

3) Initial combustion occurs.

Engine control system <Ref. to EN(H4DOTC)(diag)-2, Basic Diagnostic Procedure.>

A

Intake system

Defective intake manifold gasket

B

Defective throttle body gasket

B

Fuel line

Defective fuel pump and relay

C

Clogged fuel line

C

Lack of fuel or insufficient fuel

B

Timing belt

Degradation, etc.

B

Defective timing

B

Compression

Incorrect valve clearance

C

Loosened spark plug or defective gasket

C

Loosened cylinder head bolt or defective cylinder head
gasket

C

Improper valve sealing

C

Defective valve stem

C

Worn or broken valve spring

B

Worn or stuck piston rings, cylinder and piston

C

Incorrect valve timing

B

Improper engine oil (low viscosity)

B

4) Engine stalls after initial
combustion.

Engine control system <Ref. to EN(H4DOTC)(diag)-2, Basic Diagnostic Procedure.>

A

Intake system

Loosened or cracked intake duct

B

Loosened or cracked PCV hose

C

Loosened or cracked vacuum hose

C

Defective intake manifold gasket

B

Defective throttle body gasket

B

Dirty air cleaner element

C

Fuel line

Clogged fuel line

C

Lack of fuel or insufficient fuel

B

Timing belt

Degradation, etc.

B

Defective timing

B

Compression

Incorrect valve clearance

C

Loosened spark plug or defective gasket

C

Loosened cylinder head bolt or defective cylinder head
gasket

C

Improper valve sealing

C

Defective valve stem

C

Worn or broken valve spring

B

Worn or stuck piston rings, cylinder and piston

C

Incorrect valve timing

B

Improper engine oil (low viscosity)

B
