Subaru Legacy (2005 year). Manual - part 860

AC-9

HVAC SYSTEM (HEATER, VENTILATOR AND A/C)

General Description

• Manual A/C model

(1)

Dial

(5)

Heater control panel

(8)

Valve

(2)

A/C switch

(6)

Heater control base

(9)

Fan switch ASSY

(3)

FRESH/RECIRC switch

(7)

Temperature control cable

(10)

Switch base

(4)

Rear window defogger switch

AC-00910

(2)

(1)

(1)

(3)

(4)

(6)

(5)

(8)

(7)

(9)

(10)

(1)

AC-10

HVAC SYSTEM (HEATER, VENTILATOR AND A/C)

General Description

4. AIR CONDITIONING UNIT

(1)

Condenser

(5)

Compressor

Tightening torque: N

⋅

m (kgf-m, ft-lb)

(2)

Hose (High-pressure)

(6)

O-ring

T1: 7.5 (0.76, 5.5)

(3)

Hose (Low-pressure)

(7)

Clamp

T2: 10 (1.0, 7.4)

(4)

Bracket

(8)

Tube

T3: 5 (0.5, 3.7)

AC-01217

T2

(7)

(8)

(5)

(6)

(2)

T2

T3

T3

T1

(6)

(6)

(6)

(6)

(6)

(1)

T1

T1

(4)

(3)

T1

AC-11

HVAC SYSTEM (HEATER, VENTILATOR AND A/C)

General Description

5. COMPRESSOR

• H4  model

(1)

Idler pulley bracket

(5)

Compressor

Tightening torque: N

⋅

m (kgf-m, ft-lb)

(2)

Idler pulley adjuster

(6)

Compressor lower bracket

T1: 23.0 (2.35, 17.0)

(3)

Idler pulley

(7)

V-Belt

T2: 28.9 (2.95, 21.3)

(4)

Compressor upper bracket

T3: 36 (3.7, 26.6)

AC-00760

(4)

(1)

(2)

(3)

(7)

(6)

(5)

T2

T3

T3

T1

T1

T3

AC-12

HVAC SYSTEM (HEATER, VENTILATOR AND A/C)

General Description

• H6  model

(1)

Compressor upper bracket

Tightening torque: N

⋅

m (kgf-m, ft-lb)

(2)

Compressor

T1: 28.9 (2.95, 21.3)

(3)

Compressor lower bracket

T2: 36 (3.7, 26.6)

AC-00912

(1)

(2)

(3)

T1

T2

T2

T2
