6MT-19

MANUAL TRANSMISSION AND DIFFERENTIAL

General Description

398527700

PULLER ASSY

Used for removing extension case oil seal and
clutch housing oil seal.

499575500

GAUGE

Used for measuring total end play, extension end
play and drive pinion height.

398177700

INSTALLER

Used for assembling main shaft.

399893600

PLIERS

• Used for removing and installing neutral set
spring.
• Used with CLAW (18756AA000).

ILLUSTRATION

TOOL NUMBER

DESCRIPTION

REMARKS

ST-398527700

ST-499575500

ST-398177700

ST-399893600

6MT-20

MANUAL TRANSMISSION AND DIFFERENTIAL

General Description

18756AA000

CLAW

• Used for removing and installing neutral set
spring.
• Used with PLIERS (399893600).

499247400

INSTALLER

Used for installing transfer drive gear ball bear-
ing.

398497701

SEAT

Used for installing transfer drive gear ball bear-
ing.

398437700

INSTALLER

Used for installing front differential side bearing.

ILLUSTRATION

TOOL NUMBER

DESCRIPTION

REMARKS

ST18756AA000

ST-499247400

ST-398497701

ST-398437700

6MT-21

MANUAL TRANSMISSION AND DIFFERENTIAL

General Description

18632AA000

STAND ASSY

Used for disassembling and assembling trans-
mission.

18671AA000

OIL SEAL GUIDE

• Used for installing oil seal to reverse check.
• Used with INSTALLER (18657AA010).

18657AA010

INSTALLER

• Used for installing oil seal to reverse check.
• Used with OIL SEAL GUIDE (18671AA000).

18657AA000

INSTALLER

Used for installing oil seal to shift rod.

ILLUSTRATION

TOOL NUMBER

DESCRIPTION

REMARKS

ST18632AA000

ST18671AA000

ST18657AA010

ST18657AA000

6MT-22

MANUAL TRANSMISSION AND DIFFERENTIAL

General Description

18758AA000

PULLER

Used for removing extension taper roller bearing
outer race.

18831AA000

GAUGE

Used for measuring extension taper roller bear-
ing.

18631AA000

HANDLE

Used for measuring front differential backlash.

18754AA000

REMOVER

Used for removing each parts of driven gear.

ILLUSTRATION

TOOL NUMBER

DESCRIPTION

REMARKS

ST18758AA000

ST18831AA000

ST18631AA000

ST18754AA000
