5AT(diag)-19

AUTOMATIC TRANSMISSION (DIAGNOSTICS)

Subaru Select Monitor

NOTE:
For details concerning operation procedure, refer to the SUBARU SELECT MONITOR OPERATION MAN-
UAL.

3. CLEAR MEMORY MODE

NOTE:
To clear the previous DTC, use {Clear Memory},
and to clear the learned value, use {Clear Memory
2}.
1) Check that the select lever is in “P” range.
2) On the «Main Menu» display screen, select the
{Each System Check} and press the [YES] key.
3) On the «System Selection Menu» display
screen, select the {Transmission} and press the
[YES] key.
4) Press the [YES] key after the information of
transmission type is displayed.
5) On the «Transmission Diagnosis» display
screen, select the {Clear Memory} and press the
[YES] key.

NOTE:
If {Clear Memory 2} is selected and performed,
DTC may not be cleared.
6) When the “Done” are shown on the display
screen, turn off the Subaru Select Monitor and turn
the ignition switch to OFF. To turn the ignition
switch ON again, wait for more than 10 seconds.

NOTE:
For details concerning operation procedure, refer
to the SUBARU SELECT MONITOR OPERATION
MANUAL.

Low Coast Brake Fluid Pressure Switch Input Signal

LC/B Fluid Pressure

ON or OFF

Low Coast Brake Solenoid Input Signal

LC/B Solenoid

ON or OFF

Item

Display

Unit of measure

5AT(diag)-20

AUTOMATIC TRANSMISSION (DIAGNOSTICS)

Read Diagnostic Trouble Code (DTC)

7. Read Diagnostic Trouble

Code (DTC)

A: OPERATION

Refer to “Subaru Select Monitor” for information
about how to obtain and understand the DTC.
<Ref. to 5AT(diag)-17, OPERATION, Subaru Se-
lect Monitor.>

NOTE:
DTC can not be read by SPORT indicator light.

5AT(diag)-21

AUTOMATIC TRANSMISSION (DIAGNOSTICS)

Inspection Mode

8. Inspection Mode

A: PROCEDURE

WARNING:
Observe the traffic law during actual driving.

1) Shift the select lever to “D” range, and then drive
the vehicle with changing the gear from 1st to 5th.
2) When driving the vehicle at 5th speed of “D”
range, set the gear to manual mode and drive the
vehicle with shifting down using “

−” of steering

switch or “

−” of select lever from 5th → 4th, 4th →

3rd, 3rd

→ 2nd, 2nd → 1st.

NOTE:
At shifting down, drive the vehicle at least 10 sec-
onds in each speed.
3) Shift the select lever to “R” range and drive the
vehicle for more than 2 seconds.

5AT(diag)-22

AUTOMATIC TRANSMISSION (DIAGNOSTICS)

Clear Memory Mode

9. Clear Memory Mode

A: OPERATION

Use “Subaru Select Monitor” to clear DTC. <Ref. to
5AT(diag)-19, CLEAR MEMORY MODE, OPERA-
TION, Subaru Select Monitor.>

NOTE:
DTC cannot be cleared without using Subaru Se-
lect Monitor.
