Subaru Legacy (2005 year). Manual - part 474
EN(H6DO)(diag)-209
ENGINE (DIAGNOSTICS)
Diagnostic Procedure with Diagnostic Trouble Code (DTC)
BQ:DTC P0462 FUEL LEVEL SENSOR “A” CIRCUIT LOW
NOTE:
For the diagnostic procedure, refer to DTC P0463. <Ref. to EN(H6DO)(diag)-209, DTC P0463 FUEL LEVEL
SENSOR “A” CIRCUIT HIGH, Diagnostic Procedure with Diagnostic Trouble Code (DTC).>
BR:DTC P0463 FUEL LEVEL SENSOR “A” CIRCUIT HIGH
DTC DETECTING CONDITION:
Detects when malfunction occurs in 2 continuous driving cycles.
CAUTION:
After repair or replacement of faulty parts, conduct Clear Memory Mode <Ref. to EN(H6DO)(diag)-41,
OPERATION, Clear Memory Mode.> and Inspection Mode <Ref. to EN(H6DO)(diag)-34, PROCEDURE,
Inspection Mode.>.
BS:DTC P0500 VEHICLE SPEED SENSOR “A”
DTC DETECTING CONDITION:
Immediately at fault recognition
CAUTION:
After repair or replacement of faulty parts, conduct Clear Memory Mode <Ref. to EN(H6DO)(diag)-41,
OPERATION, Clear Memory Mode.> and Inspection Mode <Ref. to EN(H6DO)(diag)-34, PROCEDURE,
Inspection Mode.>.
BT:DTC P0512 STARTER REQUEST CIRCUIT
DTC DETECTING CONDITION:
Detects when malfunction occurs in 2 continuous driving cycles.
TROUBLE SYMPTOM:
Failure of engine to start
CAUTION:
After repair or replacement of faulty parts, conduct Clear Memory Mode <Ref. to EN(H6DO)(diag)-41,
OPERATION, Clear Memory Mode.> and Inspection Mode <Ref. to EN(H6DO)(diag)-34, PROCEDURE,
Inspection Mode.>.
Step
Check
Yes
No
1
CHECK ANY OTHER DTC ON DISPLAY.
Is DTC P0462 or P0463 dis-
played on the Subaru Select
Monitor?
Check the combi-
nation meter.
<Ref. to IDI-15,
Combination
Meter.>
Temporary poor
contact occurs.
Step
Check
Yes
No
1
CHECK DTC OF ABS.
Check DTC of ABS.
Is DTC of ABS displayed?
Perform the diag-
nosis according to
DTC. <Ref. to
ABS(diag)-38, List
of Diagnostic Trou-
ble Code (DTC).>
Repair the poor
contact in ECM.
