Subaru Legacy (2005 year). Manual - part 422
ENGINE (DIAGNOSTICS)
EN(H6DO)(diag)
Page
1.
Basic Diagnostic Procedure ........................................................................2
2.
Check List for Interview...............................................................................3
3.
General Description ....................................................................................5
4.
Electrical Component Location ...................................................................8
5.
Engine Control Module (ECM) I/O Signal .................................................17
6.
Engine Condition Data ..............................................................................21
7.
Data Link Connector .................................................................................22
8.
General Scan Tool ....................................................................................23
9.
Subaru Select Monitor...............................................................................26
10.
Read Diagnostic Trouble Code (DTC) ......................................................33
11.
Inspection Mode........................................................................................34
12.
Drive Cycle................................................................................................39
13.
Clear Memory Mode..................................................................................41
14.
Compulsory Valve Operation Check Mode ...............................................42
15.
Malfunction Indicator Light ........................................................................44
16.
Diagnostics for Engine Starting Failure.....................................................53
17.
List of Diagnostic Trouble Code (DTC) .....................................................66
18.
Diagnostic Procedure with Diagnostic Trouble Code (DTC) .....................72
19.
General Diagnostic Table........................................................................269
