IG(H6DO)-7

IGNITION

Ignition Coil

3. Ignition Coil

A: REMOVAL

Direct ignition type has been adopted. Refer to
“Spark Plug” for removal procedure. <Ref. to
IG(H6DO)-4, REMOVAL, Spark Plug.>

B: INSTALLATION

Install in the reverse order of removal.

Tightening torque:

16 N

⋅

m (1.6 kgf-m, 11.7 ft-lb)

C: INSPECTION

For inspection procedure, refer to “Diagnostics for
Engine Starting Failure”. <Ref. to EN(H6DO)(diag)-
60, IGNITION CONTROL SYSTEM, Diagnostics
for Engine Starting Failure.>

IG(H6DO)-8

IGNITION

Ignition Coil

STARTING/CHARGING SYSTEMS

SC(H6DO)

Page

1.

General Description ....................................................................................2

SC(H6DO)-2

STARTING/CHARGING SYSTEMS

General Description

1. General Description

A: SPECIFICATION

Specifications for 3.0 L DOHC non-turbo model are
included in SC(H4SO 2.0) section. <Ref. to
SC(H4SO 2.0)-2, General Description.>
