ME(H6DO)-87

MECHANICAL

Engine Trouble in General

3) Initial combustion occurs.

Engine control system <Ref. to EN(H6DO)(diag)-2, Basic Diagnostic Procedure.>

A

Intake system

Defective intake manifold gasket

B

Defective throttle body gasket

B

Fuel line

Defective fuel pump and relay

C

Clogged fuel line

C

Lack of or insufficient fuel

B

Chain

Trouble

B

Defective timing

B

Compression

Incorrect valve clearance

C

Loosened spark plug or defective gasket

C

Loosened cylinder head bolt or defective gasket

C

Improper valve sealing

C

Defective valve stem

C

Worn or broken valve spring

B

Worn or stuck piston rings, cylinder and piston

C

Incorrect valve timing

B

Improper engine oil (low viscosity)

B

Trouble of tappet

C

Trouble of tappet. In case noise occurs with valve mov-
ing. Or the harness involved to oil switching solenoid
valve, variable valve lift diagnosis oil pressure switch
and variable valve lift has trouble in a past.

B

4) Engine stalls after initial
combustion.

Engine control system <Ref. to EN(H6DO)(diag)-2, Basic Diagnostic Procedure.>

A

Intake system

Loosened or cracked intake duct

B

Loosened or cracked PCV hose

C

Loosened or cracked vacuum hose

C

Defective intake manifold gasket

B

Defective throttle body gasket

B

Dirty air cleaner element

C

Fuel line

Clogged fuel line

C

Lack of or insufficient fuel

B

Chain

Trouble

B

Defective timing

B

Compression

Incorrect valve clearance

C

Loosened spark plug or defective gasket

C

Loosened cylinder head bolt or defective gasket

C

Improper valve sealing

C

Defective valve stem

C

Worn or broken valve spring

B

Worn or stuck piston rings, cylinder and piston

C

Incorrect valve timing

B

Improper engine oil (low viscosity)

B

Trouble of tappet

C

Trouble of tappet. In case noise occurs with valve mov-
ing. Or the harness involved to oil switching solenoid
valve, variable valve lift diagnosis oil pressure switch
and variable valve lift has trouble in a past.

B

Symptom

Problem parts, etc.

Possible cause

Rank

ME(H6DO)-88

MECHANICAL

Engine Trouble in General

2. Rough idle and engine
stall

Engine control system <Ref. to EN(H6DO)(diag)-2, Basic Diagnostic Procedure.>

A

Intake system

Loosened or cracked intake duct

A

Loosened or cracked PCV hose

A

Loosened or cracked vacuum hose

A

Defective intake manifold gasket

B

Defective throttle body gasket

B

Defective PCV valve

C

Loosened oil filler cap

B

Dirty air cleaner element

C

Fuel line

Defective fuel pump and relay

C

Clogged fuel line

C

Lack of or insufficient fuel

B

Chain

Defective timing

C

Compression

Incorrect valve clearance

B

Loosened spark plug or defective gasket

B

Loosened cylinder head bolt or defective gasket

B

Improper valve sealing

B

Defective valve stem

C

Worn or broken valve spring

B

Worn or stuck piston rings, cylinder and piston

B

Incorrect valve timing

A

Improper engine oil (low viscosity)

B

Trouble of tappet

C

Trouble of tappet. In case noise occurs with valve mov-
ing. Or the harness involved to oil switching solenoid
valve, variable valve lift diagnosis oil pressure switch
and variable valve lift has trouble in a past.

B

Lubrication system

Incorrect oil pressure

B

Defective rocker cover gasket

C

Cooling system

Overheating

C

Other

Evaporative emission control system malfunction

A

Stuck or damaged throttle valve

B

Symptom

Problem parts, etc.

Possible cause

Rank

ME(H6DO)-89

MECHANICAL

Engine Trouble in General

3. Low output, hesitation and
poor acceleration

Engine control system <Ref. to EN(H6DO)(diag)-2, Basic Diagnostic Procedure.>

A

Intake system

Loosened or cracked intake duct

A

Loosened or cracked PCV hose

A

Loosened or cracked vacuum hose

B

Defective intake manifold gasket

B

Defective throttle body gasket

B

Defective PCV valve

B

Loosened oil filler cap

B

Dirty air cleaner element

A

Fuel line

Defective fuel pump and relay

B

Clogged fuel line

B

Lack of or insufficient fuel

C

Chain

Defective timing

B

Compression

Incorrect valve clearance

B

Loosened spark plug or defective gasket

B

Loosened cylinder head bolt or defective gasket

B

Improper valve sealing

B

Defective valve stem

C

Worn or broken valve spring

B

Worn or stuck piston rings, cylinder and piston

C

Incorrect valve timing

A

Improper engine oil (low viscosity)

B

Trouble of tappet

C

Trouble of tappet. In case noise occurs with valve mov-
ing. Or the harness involved to oil switching solenoid
valve, variable valve lift diagnosis oil pressure switch
and variable valve lift has trouble in a past.

B

Lubrication system

Incorrect oil pressure

B

Cooling system

Overheating

C

Over-cooling

C

Other

Evaporative emission control system malfunction

A

Symptom

Problem parts, etc.

Possible cause

Rank

ME(H6DO)-90

MECHANICAL

Engine Trouble in General

4. Surging

Engine control system <Ref. to EN(H6DO)(diag)-2, Basic Diagnostic Procedure.>

A

Intake system

Loosened or cracked intake duct

A

Loosened or cracked PCV hose

A

Loosened or cracked vacuum hose

A

Defective intake manifold gasket

B

Defective throttle body gasket

B

Defective PCV valve

B

Loosened oil filler cap

B

Dirty air cleaner element

B

Fuel line

Defective fuel pump and relay

B

Clogged fuel line

B

Lack of or insufficient fuel

C

Chain

Defective timing

B

Compression

Incorrect valve clearance

B

Loosened spark plug or defective gasket

C

Loosened cylinder head bolt or defective gasket

C

Improper valve sealing

C

Defective valve stem

C

Worn or broken valve spring

C

Worn or stuck piston rings, cylinder and piston

C

Incorrect valve timing

A

Improper engine oil (low viscosity)

B

Trouble of tappet

C

Trouble of tappet. In case noise occurs with valve mov-
ing. Or the harness involved to oil switching solenoid
valve, variable valve lift diagnosis oil pressure switch
and variable valve lift has trouble in a past.

B

Cooling system

Overheating

B

Other

Evaporative emission control system malfunction

C

5. Engine does not return to
idle.

Engine control system <Ref. to EN(H6DO)(diag)-2, Basic Diagnostic Procedure.>

A

Intake system

Loosened or cracked vacuum hose

A

Other

Stuck or damaged throttle valve

A

6. Dieseling (Run-on)

Engine control system <Ref. to EN(H6DO)(diag)-2, Basic Diagnostic Procedure.>

A

Cooling system

Overheating

B

Other

Evaporative emission control system malfunction

B

Symptom

Problem parts, etc.

Possible cause

Rank
