ME(H6DO)-7

MECHANICAL

General Description

3. TIMING CHAIN

(1)

Crank sprocket

(13)

Chain tensioner lever (LH)

Tightening torque: N

⋅

m (kgf-m, ft-lb)

(2)

Oil relief case

(14)

Chain tensioner (LH)

T1: 6.4 (0.65, 4.7)

(3)

Inner rotor

(15)

Water pump

T2: 7.8 (0.8, 5.8)

(4)

Outer rotor

(16)

O-ring

T3: <Ref. to ME(H6DO)-52, Cam

Sprocket.>

(5)

Chain guide (center)

(17)

Chain guide (LH)

(6)

Intake cam sprocket (RH)

(18)

Chain guide (LH: between cams)

T4: 16 (1.6, 11.8)

(7)

Exhaust cam sprocket (RH)

(19)

Timing chain (LH)

T5: 69 (7.0, 50.6)

(8)

Chain guide (RH: between cams)

(20)

Intake cam sprocket (LH)

T6: <Ref. to LU(H6DO)-8, Oil

Pump.>

(9)

Timing chain (RH)

(21)

Exhaust cam sprocket (LH)

(10)

Chain guide (RH)

(22)

Idler sprocket (lower)

(11)

Chain tensioner lever (RH)

(23)

Idler sprocket collar

(12)

Chain tensioner (RH)

(24)

Idler sprocket (upper)

ME-02380

T6

(2)

(8)

(9)

(10)

(11)

(12)

(13)

(14)

(15)

(16)

(17)

(18)

(19)

(5)

T3

T3

T5

T2

T1

T1

T1

T4

T4

T4

T4

T4

(7)

(21)

(20)

(22)

(23)

(23)

(24)

(6)

(1)

(3)

(4)

ME(H6DO)-8

MECHANICAL

General Description

4. CYLINDER HEAD AND CAMSHAFT

ME-02564

(1)

(2)

(3)

(4)

(9)

(10)

(22)

(23)

(24)

(26)

(27)

(28)

(25)

(32)

(8)

(18)

(16)

(13)

(12)

(6)

(5)

(14)

(15)

(19)

(20)

(21)

(7)

(11)

(31)

(34)

(35)

(30)

(29)

(33)

T5

T1

T6

T4

T4

T3

T2

T2

T1

T6

T4

T4

T7

T2

T2

T5

T8

T4

T8

T8

T8

(17)

(17)

T3

T4

ME(H6DO)-9

MECHANICAL

General Description

(1)

Rocker cover (RH)

(16)

Cylinder head (RH)

(32)

Front camshaft cap (LH)

(2)

Oil switching solenoid valve (RH)

(17)

Gasket

(33)

Plug

(3)

Oil switching solenoid valve holder
(RH)

(18)

Cylinder head gasket (RH)

(34)

Oil pipe (LH)

(19)

Oil switching solenoid valve (LH)

(35)

Rocker cover (LH)

(4)

Oil switching solenoid valve gas-
ket

(20)

Oil switching solenoid valve holder
(LH)

Tightening torque: N

⋅

m (kgf-m, ft-lb)

(5)

Rear chain cover

(21)

Oil switching solenoid valve gas-
ket

T1: <Ref. to ME(H6DO)-60, Cylinder

Head.>

(6)

Oil pipe (RH)

(7)

Oil flow control solenoid valve
(RH)

(22)

Cylinder head gasket (LH)

T2: <Ref. to ME(H6DO)-56,

Camshaft.>

(23)

Cylinder head (LH)

(8)

Intake camshaft cap (Center RH)

(24)

Intake camshaft (LH)

T3: <Ref. to ME(H6DO)-80, Oil

Switching Solenoid Valve.>

(9)

Intake camshaft cap (Rear RH)

(25)

Exhaust camshaft (LH)

(10)

Exhaust camshaft cap (Rear RH)

(26)

Oil flow control solenoid valve (LH)

T4: 6.4 (0.65, 4.7)

(11)

Exhaust camshaft cap (Center
RH)

(27)

Intake camshaft cap (Rear LH)

T5: 9.75 (1.0, 7.2)

(28)

Intake camshaft cap (Center LH)

T6: 16 (1.6, 11.8)

(12)

Exhaust camshaft cap (Front RH)

(29)

Exhaust camshaft cap (Rear LH)

T7: 60 (6.1, 44)

(13)

Front camshaft cap (RH)

(30)

Exhaust camshaft cap (Center
LH)

T8: 29 (3.01, 21.8)

(14)

Intake camshaft (RH)

(15)

Exhaust camshaft (RH)

(31)

Exhaust camshaft cap (Front LH)

ME(H6DO)-10

MECHANICAL

General Description

5. CYLINDER HEAD AND VALVE ASSEMBLY

(1)

Exhaust valve

(7)

Valve spring (Outer)

(13)

Exhaust valve stem seal

(2)

Intake valve

(8)

Retainer

(14)

Valve spring

(3)

Intake valve guide

(9)

Retainer key

(15)

Valve lifter (Exhaust)

(4)

Valve spring seat

(10)

Shim

(16)

Cylinder head plug

(5)

Intake valve stem seal

(11)

Valve lifter (Intake)

(17)

Cylinder Head

(6)

Valve spring (Inner)

(12)

Exhaust valve guide

ME-02024

(16)

(16)

(17)

(3)

(12)

(13)

(4)

(14)

(8)

(9)

(15)

(4)

(5)

(6)

(7)

(8) (9)

(11)

(10)

(1)

(2)
