EN(H4DOTC)(diag)-29

ENGINE (DIAGNOSTICS)

Read Diagnostic Trouble Code (DTC)

10.Read Diagnostic Trouble

Code (DTC)

A: OPERATION

1. SUBARU SELECT MONITOR (NORMAL
MODE)

1) On the «Main Menu» display screen, select the
{Each System Check} and press the [YES] key.
2) On the «System Selection Menu» display
screen, select the {Engine} and press the [YES]
key.
3) Press the [YES] key after the information of en-
gine type has been displayed.
4) On the «Engine Diagnosis» screen, select the
{Diagnostic Code(s) Display}, and then press the
[YES] key.
5) On the «Diagnostic Code(s) Display» screen,
select the {Current Diagnostic Code(s)} or {History
Diagnostic Code(s)}, and then press the [YES] key.

NOTE:
• For detailed operation procedure, refer to the
SUBARU SELECT MONITOR OPERATION MAN-
UAL.
• For details concerning DTCs, refer to the List of
Diagnostic Trouble Code (DTC). <Ref. to
EN(H4DOTC)(diag)-62, List of Diagnostic Trouble
Code (DTC).>

2. SUBARU SELECT MONITOR (OBD
MODE)

1) On the «Main Menu» display screen, select the
{Each System Check} and press the [YES] key.
2) On the «System Selection Menu» display
screen, select the {Engine} and press the [YES]
key.
3) Press the [YES] key after the information of en-
gine type has been displayed.
4) On the «Engine Diagnosis» display screen, se-
lect the {OBD System} and press the [YES] key.
5) On the «OBD Menu» display screen, select the
{Diagnostic Code(s) Display} and press the [YES]
key.
6) Make sure DTC is shown on the screen.

3. GENERAL SCAN TOOL

Refer to the data denoting emission-related power-
train DTC.
For details concerning DTCs, refer to the List of Di-
agnostic Trouble Code (DTC). <Ref. to
EN(H4DOTC)(diag)-29, Read Diagnostic Trouble
Code (DTC).>

NOTE:
Refer to the general scan tool manufacturer’s oper-
ation manual to access powertrain DTC (MODE
$03).

EN(H4DOTC)(diag)-30

ENGINE (DIAGNOSTICS)

Inspection Mode

11.Inspection Mode

A: PROCEDURE

Carry out trouble diagnosis shown in the following DTC table.
When performing trouble diagnosis which is not shown in the DTC table, refer to the next item Drive cycle.
<Ref. to EN(H4DOTC)(diag)-35, Drive Cycle.>

DTC

Item

P0031

HO2S Heater Control Circuit Low (Bank 1 Sensor 1)

P0032

HO2S Heater Control Circuit High (Bank 1 Sensor 1)

P0037

HO2S Heater Control Circuit Low (Bank 1 Sensor 2)

P0038

HO2S Heater Control Circuit High (Bank 1 Sensor 2)

P0102

Mass or Volume Air Flow Circuit Low Input

P0103

Mass or Volume Air Flow Circuit High Input

P0107

Manifold Absolute Pressure/Barometric Pressure Circuit Low Input

P0108

Manifold Absolute Pressure/Barometric Pressure Circuit High Input

P0112

Intake Air Temperature Sensor 1 Circuit Low

P0113

Intake Air Temperature Sensor 1 Circuit High

P0117

Engine Coolant Temperature Circuit Low

P0118

Engine Coolant Temperature Circuit High

P0122

Throttle/Pedal Position Sensor/Switch “A” Circuit Low

P0123

Throttle/Pedal Position Sensor/Switch “A” Circuit High

P0131

O2 Sensor Circuit Low Voltage (Bank 1 Sensor 1)

P0132

O2 Sensor Circuit High Voltage (Bank 1 Sensor 1)

P0137

O2 Sensor Circuit Low Voltage (Bank 1 Sensor 2)

P0138

O2 Sensor Circuit High Voltage (Bank 1 Sensor 2)

P0222

Throttle/Pedal Position Sensor/Switch “B” Circuit Low

P0223

Throttle/Pedal Position Sensor/Switch “B” Circuit High

P0230

Fuel Pump Primary Circuit

P0245

Turbo/Super Charger Wastegate Solenoid “A” Low

P0261

Cylinder 1 Injector Circuit Low

P0264

Cylinder 2 Injector Circuit Low

P0267

Cylinder 3 Injector Circuit Low

P0270

Cylinder 4 Injector Circuit Low

P0327

Knock Sensor 1 Circuit Low (Bank 1 or Single Sensor)

P0328

Knock Sensor 1 Circuit High (Bank 1 or Single Sensor)

P0335

Crankshaft Position Sensor “A” Circuit

P0340

Camshaft Position Sensor “A” Circuit (Bank 1 or Single Sensor)

P0345

Camshaft Position Sensor “A” Circuit (Bank 2)

P0350

Ignition Coil Primary/Secondary Circuit

P0365

Camshaft Position Sensor “B” Circuit (Bank 1)

P0390

Camshaft Position Sensor “B” Circuit (Bank 2)

P0458

Evaporative Emission System Purge Control Valve Circuit Low

P0500

Vehicle Speed Sensor “A”

P0512

Starter Request Circuit

P0513

Incorrect Immobilizer Key

P0519

Idle Air Control System Performance

P0600

Serial Communication Circuit

P0604

Internal Control Module Random Access Memory (RAM) Error

P0605

Internal Control Module Read Only Memory (ROM) Error

P0607

Control Module Performance

P0638

Throttle Actuator Control Range/Performance (Bank 1)

P0700

Transmission Control System (MIL Request)

EN(H4DOTC)(diag)-31

ENGINE (DIAGNOSTICS)

Inspection Mode

1. PREPARATION FOR THE INSPECTION
MODE

1) Check that the battery voltage is more than 12 V
and fuel remains half [20 — 40

2 (5.3 — 10.6 US

gal, 4.4 — 8.8 Imp gal)].
2) Lift-up the vehicle using a garage jack and place
it on rigid racks, or drive the vehicle onto free roll-
ers.

WARNING:
• Before lifting-up the vehicle, ensure parking
brakes are applied.
• Do not use a pantograph jack in place of a rig-
id rack.
• Secure a rope or wire to the front or rear tow-
ing hooks to prevent the lateral runout of front
wheels.

• Do not abruptly depress/release clutch pedal
or accelerator pedal during works even when
the engine is operating at low speeds since this
may cause vehicle to jump off free rollers.
• In order to prevent the vehicle from slipping
due to vibration, do not place any wooden
blocks or similar items between the rigid racks
and vehicle.

P0851

Park/Neutral Switch Input Circuit Low

P0852

Park/Neutral Switch Input Circuit High

P1160

Return Spring Failure

P1518

Starter Switch Circuit Low Input

P1560

Back-up Voltage Circuit Malfunction

P1570

Antenna

P1571

Reference Code Incompatibility

P1572

IMM Circuit Failure (Except Antenna Circuit)

P1574

Key Communication Failure

P1576

EGI Control Module EEPROM

P1577

IMM Control Module EEPROM

P1578

Meter Failure

P2088

Intake Camshaft Position Actuator Control Circuit Low (Bank 1)

P2089

Intake Camshaft Position Actuator Control Circuit High (Bank 1)

P2090

Exhaust Camshaft Position Actuator Control Circuit Low (Bank 1)

P2091

Exhaust Camshaft Position Actuator Control Circuit High (Bank 1)

P2092

Intake Camshaft Position Actuator Control Circuit Low (Bank 2)

P2093

Intake Camshaft Position Actuator Control Circuit High (Bank 2)

P2094

Exhaust Camshaft Position Actuator Control Circuit Low (Bank 2)

P2095

Exhaust Camshaft Position Actuator Control Circuit High (Bank 2)

P2101

Throttle Actuator Control Motor Circuit Range/Performance

P2102

Throttle Actuator Control Motor Circuit Low

P2103

Throttle Actuator Control Motor Circuit High

P2109

Throttle/Pedal Position Sensor “A” Minimum Stop Performance

P2122

Throttle/Pedal Position Sensor/Switch “D” Circuit Low Input

P2123

Throttle/Pedal Position Sensor/Switch “D” Circuit High Input

P2127

Throttle/Pedal Position Sensor/Switch “E” Circuit Low Input

P2128

Throttle/Pedal Position Sensor/Switch “E” Circuit High Input

P2135

Throttle/Pedal Position Sensor/Switch “A” / “B” Voltage Correlation

P2138

Throttle/Pedal Position Sensor/Switch “D” / “E” Voltage Correlation

P2228

Barometric Pressure Sensor Circuit Low

P2229

Barometric Pressure Sensor Circuit High

DTC

Item

EN(H4DOTC)(diag)-32

ENGINE (DIAGNOSTICS)

Inspection Mode

• Since the rear wheels will also rotate, do not
place anything near them. Also, make sure that
nobody goes in front of the vehicle.

2. SUBARU SELECT MONITOR

1) After clearing the memory, check for any remain-
ing unresolved trouble data. <Ref. to
EN(H4DOTC)(diag)-37, Clear Memory Mode.>
2) Idle the engine.
3) Prepare the Subaru Select Monitor kit. <Ref. to
EN(H4DOTC)(diag)-7, PREPARATION TOOL,
General Description.>

4) Connect the diagnosis cable to Subaru Select
Monitor.

5) Insert the cartridge to Subaru Select Monitor.
<Ref. to EN(H4DOTC)(diag)-7, PREPARATION
TOOL, General Description.>

6) Connect the test mode connector (A) located at
the lower portion of glove box.

7) Connect the Subaru Select Monitor to data link
connector located in the lower portion of the instru-
ment panel (on the driver’s side).

CAUTION:
Do not connect any scan tools except Subaru
Select Monitor or general scan tool.

(A) Rigid racks

(B) Free rollers

EN-00041

(A)

(B)

EN-00038

EN-00039

(A)

EN-01983

EN-02097
