Subaru Legacy (2005 year). Manual - part 230
EN(H4SO 2.5)(diag)-205
ENGINE (DIAGNOSTICS)
Diagnostic Procedure with Diagnostic Trouble Code (DTC)
BR:DTC P2006 INTAKE MANIFOLD RUNNER CONTROL STUCK CLOSED
(BANK 1)
DTC DETECTING CONDITION:
Immediately at fault recognition
CAUTION:
After repair or replacement of faulty parts, conduct Clear Memory Mode <Ref. to EN(H4SO 2.5)(diag)-
40, Clear Memory Mode.> and Inspection Mode <Ref. to EN(H4SO 2.5)(diag)-33, Inspection Mode.>.
BS:DTC P2007 INTAKE MANIFOLD RUNNER CONTROL STUCK CLOSED
(BANK 2)
DTC DETECTING CONDITION:
Immediately at fault recognition
CAUTION:
After repair or replacement of faulty parts, conduct Clear Memory Mode <Ref. to EN(H4SO 2.5)(diag)-
40, Clear Memory Mode.> and Inspection Mode <Ref. to EN(H4SO 2.5)(diag)-33, Inspection Mode.>.
Step
Check
Yes
No
1
CHECK ANY OTHER DTC ON DISPLAY.
Is any other DTC displayed?
Inspect the rele-
vant DTC using
“List of Diagnostic
Trouble Code
(DTC)”. <Ref. to
EN(H4SO
2.5)(diag)-69, List
of Diagnostic Trou-
ble Code (DTC).>
2
CHECK TUMBLE GENERATOR VALVE RH.
1) Remove the tumble generator valve assem-
bly.
2) Check the tumble generator valve body.
Does the tumble generator
valve move smoothly? (No dirt,
no foreign material clogged)
Replace the tum-
ble generator valve
assembly. <Ref. to
FU(H4SO 2.5)-28,
Tumble Generator
Valve Assembly.>
Clean the tumble
generator valve.
Step
Check
Yes
No
1
CHECK ANY OTHER DTC ON DISPLAY.
Is any other DTC displayed?
Inspect the rele-
vant DTC using
“List of Diagnostic
Trouble Code
(DTC)”. <Ref. to
EN(H4SO
2.5)(diag)-69, List
of Diagnostic Trou-
ble Code (DTC).>
2
CHECK TUMBLE GENERATOR VALVE LH.
1) Remove the tumble generator valve assem-
bly.
2) Check the tumble generator valve body.
Does the tumble generator
valve move smoothly? (No dirt,
no foreign material clogged)
Replace the tum-
ble generator valve
assembly. <Ref. to
FU(H4SO 2.5)-28,
Tumble Generator
Valve Assembly.>
Clean the tumble
generator valve.
