EN(H4SO 2.0)(diag)-29
ENGINE (DIAGNOSTICS)
Subaru Select Monitor
7. LED OPERATION MODE FOR ENGINE
1) On the «Main Menu» display screen, select the {Each System Check} and press the [YES] key.
2) On the «System Selection Menu» display screen, select the {Engine} and press the [YES] key.
3) Press the [YES] key after the information of engine type has been displayed.
4) On the «Engine Diagnosis» display screen, select the {Current Data Display & Save}, and then press the
[YES] key.
5) On the «Data Display» screen, select the {Data & LED Display} and press the [YES] key.
6) Using the scroll key, move the display screen up or down until the desired data is shown.
• A list of the support data is shown in the following table.
Remarks
Display
Message
LED “ON” requirements
AT/MT identification signal
AT Vehicle ID Signal
ON or OFF
Illuminate (AT model)
Test mode signal
Test Mode Signal
ON or OFF
D check
Neutral position switch signal
Neutral Position Switch
ON or OFF
When neutral position signal is
entered.
Idle switch signal
Idle Switch Signal
ON or OFF
When idle switch signal is
entered.
Ignition switch signal
Ignition Switch
ON or OFF
When ignition switch is turned
ON.
Power steering switch signal
P/S Switch
ON or OFF
When power steering switch is
entered.
Air conditioning switch signal
A/C Switch
ON or OFF
When air conditioning switch is
input.
Steering wheel switch signal
Handle Switch
RHD or LHD
When handle switch Low sig-
nal is input.
Starter switch signal
Starter Switch
ON or OFF
When starter switch is input.
Rear oxygen sensor rich sig-
nal
Rear O2 Rich Signal
ON or OFF
When rear oxygen sensor mix-
ture ratio is rich.
Knocking signal
Knocking Signal
ON or OFF
When knocking signal is input.
Crankshaft position sensor
signal
Crankshaft Position Sig.
ON or OFF
When crankshaft position sen-
sor signal is input.
Camshaft position sensor sig-
nal
Camshaft Position Sig.
ON or OFF
When camshaft position sen-
sor signal is entered.
Rear defogger switch signal
Rear Defogger Switch
ON or OFF
When rear defogger switch is
turned ON.
Blower fan switch signal
Blower fan SW
ON or OFF
When blower fan switch is
turned ON.
Light switch signal
Light Switch
ON or OFF
When light switch is turned
ON.
Small light switch signal
Light Switch
ON or OFF
When small light switch is
turned ON.
Windshield wiper switch signal
Wiper Switch
ON or OFF
When windshield wiper switch
is turned ON.
A/C middle pressure switch
signal
A/C Mid Pressure Switch
ON or OFF
When A/C middle pressure
switch is turned ON.
Air conditioning relay signal
Compressor relay
ON or OFF
When air conditioning relay is
in function.
Radiator fan relay 1 signal
Radiator Fan Relay #1
ON or OFF
When radiator fan relay 1 is in
function.
Radiator fan relay 2 signal
Radiator Fan Relay #2
ON or OFF
When radiator fan relay 2 is in
function.
Fuel pump relay signal
Fuel Pump Relay
ON or OFF
ON output
AT retard angle demand signal Retard Signal
ON or OFF
When AT retard angle demand
signal is input.
AT fuel cut signal
Fuel Cut
ON or OFF
When AT fuel cut signal is
input.
