ME(H4SO 2.0)-71 MECHANICAL Cylinder Block 10) Install the rear oil seal using ST1 and ST2. 499597100 CRANKSHAFT OIL SEAL ST2 499587200 CRANKSHAFT OIL SEAL IN- 11) Position the top ring gap at (A) or (B) in the fig- ° on the re- verse side for the top ring gap. 13) Position the upper rail gap at (C) in the figure. 14) Align the upper rail spin stopper (E) to the side 15) Position the expander gap at 180 ° on the re- verse side of (C) that shown (F) in the figure. 16) Position the lower rail gap at 120 ° clockwise of (C) that shown (G) in the figure. CAUTION: (A) Rear oil seal (B) Flywheel attaching bolt ME-00148 ST1 ST2 (B) (A) ME-00718 (A) (B) ME-02087 (C) 25 ME-02392 (E) (D) ME-02088 (F) ME-02089 120 (C) (G) |
