1-6  HOW TO USE ELECTRICAL WIRING DIAGRAM

1

1

2

9

9

9

3

3

2

6. PART LOCATION ACCORDING TO PART NUMBER

Ex.)  C  1  0  2

• C : Symbol character for connector

Part Number

Engine compartment

Instrument panel

Passenger compartment, Tailgate

Underbody

…1……

…2……

…3……

…9……

Location

• 1 : Part location number

Symbol Character

Connector (Connecting part that connects two wiring harness)

Diode

Ground

Splice pack (Joint connector that connects various wiring harness)

C

D

G

S

Description

• Part number according to locating section

• In the locating section, the assignment for part number starts from

left bottom and proceeds clockwise.

• In the fuse and relay box or the instrument panel, the part number is

assigned from left top to light bottom.

• 02 : Part number

HOW TO USE ELECTRICAL WIRING DIAGRAM  1-7

SSANGYONG  REXTON XDi (LHD)

7. ELECTRIC SYMBOLS

Items

Symbols

Items

Symbols

Resistance

Rheostat

Coil, Inductance

Condenser, Capacitor

Ground, Earth

Diode

Zener Diode

Photo Diode

Light Emitting Diode

Battery

Disconnected Wire

Fuse

Motor

Speaker

Lamp

Single Bulb

Double Bulb

Transistor : PNP type

Transistor : NPN type

~Meter, ~Gauge

Voltmeter

Amperemeter

Switch

Thermistor

Junction Point

Fusible Link

Connector

Horn

M

V

SSANGYONG   REXTON XDi (LHD)

1-8  HOW TO USE ELECTRICAL WIRING DIAGRAM

Abbreviations

Air Bag

Air Cleaner

Air Conditioner

Air Duct

Auto Transmission

Automatic Brake Differential

Anti-lock Braking System

Alternating Current

Accessory

Accelerator

Auto Cruise System

Actuator

Alternator

Ampere

Antenna

Anti Slip Regulator

Assembly

Automatic Temperature Controller

After Top Dead Center

Auxiliary

Automatic Voltage Regulator

Battery

Back Up

Back Door

Back Window

Bottom Dead Center

Body in White

Before Top Dead Center

Compressor

Condenser Fan

Connector

Cigar Lighter

Cruise

Crash Pad

Canister

Contact Breaker

Cable

Catalystic Converter

A

B

C

A/BAG

A/CLNR

A/CON (A/C)

A/DUCT

A/T

ABD

ABS

AC

ACC

ACCEL

ACS

ACTR (ACT)

ALT

AMP

ANT

ASR

ASSY

ATC

ATDC

AUX

AVR

BATT

B/UP

B/DR

B/WDW

BDC

BIW

BTDC

COMP

C/FAN

CONN

C/LIGHTER

CRU

C/PAD

CANI

CB

CBL

CC

8. ABBREVIATIONS

Classification

Full words

HOW TO USE ELECTRICAL WIRING DIAGRAM  1-9

SSANGYONG  REXTON XDi (LHD)

Compact Disk - Interactive

Cooling

Clutch

Control

Converter

Coupling

Child Restraint System

Center

Diesel

Door

Down

Door Courtesy

Dimmer Switch

Direct Current

Defogger

Diaphragm

Dynamo

Drawing

Driver

Dual Pressure Switch

Engine

Electronic Control Unit

Exhaust Gas Recirculation System

Engine Spark Control

Electronic Steering & Inside Mirror Control System

Exterior

Frame

Forward

Front Left

Front Right

Fuel Pump

Fluid Leveling

Front

Fusible Link

Fuse Box

Front Door

Front Floor

Front Seat

C

D

E

F

CD-I

CLG

CLH

CONT

CONV

CPLG

CRS

CTR

DSL

DR

DN

D/CTSY

D/SW

DC

DEFOG

DIAPH

DYN

DWG

DRV

D/P SW

ENG

ECU

EGR

ESC

ESIMS

EXTR

FRM

FWD

FL

FR

F/PUMP (F/P)

F/LEVEL’G

FRT

F/LINK

F/BOX

F/DR

F/FLR

F/SEAT

Classification

Abbreviations

Full words
