Wiring Diagram for Power Supplies  5-49

Electrical Wiring Diagram

(LHD)

A. CONNECTOR INFORMATION

B. CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION

Connector Number

(Pin Number, Color)

Engine Room Fuse Box - Engine

Engine Room Fuse Box - Engine

Engine Room Fuse Box - Engine

Engine Room Fuse Box - Main

Engine Room Fuse Box - Main

Engine - Floor (RH)

Engine - Floor (RH)

Main - W/H Air-Bag

W/H Air-Bag - W/H Blower

W/H Main - W/H Air-Bag

Main - Floor (RH)

Main - Floor (RH)

W/H Main

W/H Air-bag

W/H Main

C102 (20Pin, White)

C103 (6Pin, Colorless)

C104 (20Pin, White)

C105 (22Pin, White)

C106 (18Pin, White)

C115 (15Pin, Black)

C115 (8Pin, Black)

C211 (16Pin, White)

C211A (16Pin, White)

C211B (2Pin, White)

C217 (20Pin, Green)

C221 (20Pin, Gray)

S204 (14Pin, Black)

G102

G103

Connecting Wiring

Harness

Engine Room Fuse Box

Engine Room Fuse Box

Engine Room Fuse Box

Engine Room Fuse Box

Engine Room Fuse Box

Under the Coolant Reserve Tank

Under the Coolant Reserve Tank

Behind A/V Unit

Behind RR Glove Box

Behind RR A/V Unit

Inside Passenger Side Cowl PNL

Inside Passenger Side Cowl PNL

Under the Relay Box RR Center the Cluster

Beside the SDM

RR TGS Lever

Remark

Connector Position

XDi

GSL

Manual

Power Seat (Seat Warmer)

ILL

W/H Air Bag
