Wiring Diagram for Power Supplies 5-29 Electrical Wiring Diagram (LHD) A. CONNECTOR INFORMATION B. CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION Connector Number (Pin Number, Color) Engine Room Fuse Box - Main Engine Room Fuse Box - Main Main - ICM Box Main - Floor (LH) W/H Main W/H Main W/H Main W/H Main W/H Main C105 (22Pin, White) C108 (4Pin, Colorless) C204 (20Pin, White) C213 (22Pin, White) S204 (14Pin, Black) S205 (14Pin, Black) S206 (14Pin, Black) S207 (14Pin, Black) G204 Connecting Wiring Harness Engine Room Fuse Box Engine Room Fuse Box ICM Box (IP Relay Box) FRT TGS Lever Under the Relay Box RR Center the Cluster Upper the Right Driver Under Cover Inside the Left A/V Head Unit Inside the Right A/V Head Unit RR TGS Lever ILL CAN GND Remark Connector Position |
