SsangYong Stavic / SsangYong Rodius (2005 year). Manual - part 350

CHANGED BY

EFFECTIVE DATE

AFFECTED VIN

7

TOD

STAVIC - 2004.09

4D

Signal Flow

Instrument Panel

4WD Switch

TOD Control

Unit

Output

Input

Rear Speed

Manetic Clutch

Motor

Front Speed

Front Output

CHANGED BY

EFFECTIVE DATE

AFFECTED VIN

8

TOD

STAVIC - 2004.09

4D

Rear Axle
(Rear Wheel)

Front Axle

(Front Wheel)

Transmission

Power Flow

4H Mode (4WD Drive - High Speed)

Transmission

Input Shaft

Driving Sprocket

Chain

Rear Propeller

Shaft

Front Speed

Sensor

Rear Speed

Sensor

Throttle Open

Rate

(TPS Value)

Front Propeller

Shaft

TOD Control Unit

Magnetic Clutch

Force Distribution Unit

BALL RAMP

Multi-Plate Clutch

Output Shaft

CHANGED BY

EFFECTIVE DATE

AFFECTED VIN

9

TOD

STAVIC - 2004.09

4D

Rear Axle
(Rear Wheel)

Front Axle

(Front Wheel)

Transmission

Driving Sprocket

Chain

Front Propeller

Shaft

Front Speed

Sensor

Rear Speed

Sensor

Throttle Open

Rate

(TPS Value)

Transmission

Input Shaft

Output Shaft

Rear Propeller

Shaft

Planetary Gear

(2.483)

Force Distribution Unit

BALL RAMP

Multi-Plate Clutch

TOD Control Unit

Magnetic Clutch

MAX DUTY

4H Mode (4WD Drive - Low Speed)

CHANGED BY

EFFECTIVE DATE

AFFECTED VIN

10

TOD

STAVIC - 2004.09

4D

High

Low

Specification

Capacity

Change interval

Normal operating

range

CAN communication

IG switch OFF

IG switch ON

Motor OFF

Motor ON

Specifications

TOD

TOD

control

unit

Model

Overall length

Weight (including oil)

Shifting mode

Gear ratio

Oil specification

Maximum torque (front)

Voltage

Current (below maximum

operating voltage)

Maximum operating

current

Description

TOD transfer case

343.0 mm

37.9 kg

4H and 4L

1:1

2.48:1

Ssangyong genuine oil

(ATF S-3, S-4 or Dexron II/III)

 1.4

Check at every 15,000 km,

replace at every 60,000 km

Approx. 76 kg•m

9 ~ 16 V

6 ~ 16 V

2 mA

1 A

7 A

20 A

Specification
