SsangYong Rodius (2013 year). Manual - part 83
15-3
0000-00
1. ENGINE DATA LIST
Data
Unit
Value
Coolant temperature
℃
130℃~-40℃
Intake air temperature
℃
-40 to 130℃ (varies by ambient air
temperature or engine mode)
Idle speed
rpm
750 ± 50 (P/N)
Engine load
%
18~25%
Mass air flow
kg/h
16 to 25 kg/h
Throttle position angle
°TA
0° (Full Open) to 78° (Close)
Engine torque
Nm
varies by engine conditions
Injection time
ms
3 to 5ms
Battery voltage
V
13.5 V to 14.1 V
Accelerator pedal position 1
V
0.4. to 4.8V
Accelerator pedal position 2
V
0.2 to 2.4 V
Throttle position 1
V
0.3 to 4.6 V
Throttle position 2
V
0.3 to 4.6 V
Oxygen sensor
V
0 to 5 V
A/C compressor switch
1=ON / 0=OFF
-
Full load
1=ON / 0=OFF
-
Gear selection (A/T)
1=ON / 0=OFF
-
Knocking control
1=ON / 0=OFF
-
Brake switch
1=ON / 0=OFF
-
Cruise control
1=ON / 0=OFF
-
