SSAMGYONG MY2002
3A-24 FRONT AXLE
KAA3A580
KAA3A570
4. Degrease the tripot assembly.
Installation Notice
•
Fill the tripot housing with 185 to 205 g (6.53 to
7.23 ounces) of the recommended grease.
Repack the tripot with 185 to 205 g (6.53 to
7.23 ounces) of the recommended grease.
5. Remove the shaft retaining ring using the snap
ring plier J-8059.
6. Remove the tripot and the tripot joint retaining ring
from the front drive shaft.
7. Remove the tripot joint seal from the front drive
shaft.
KAA3A560
INNER TRIPOT SEAL
Tools Required
J-8059 Snap Ring Plier
Disassembly and Assembly Procedure
1. Remove the front drive shaft from the vehicle.
Refer to “Front Drive Shaft” in this section.
2. Remove the large seal retaining clamp.
3. Remove the small seal retaining clamp.
