07-7

4110-01

3. DESIGN FOR IMPROVING NVH

1) Dual Type Dash Panel and Engine Tunnel with Foaming Pad

Dash

panel

Deadening sheet

Dash

reinforcement

Added an additional member to the bottom of

dash panel to minimize the possibility of engine

retreat when collision.

Reinforcement for Front Floor and Rear Floor

▶
