02-3

8810-01

1. CAUTIONS FOR AIR BAG OPERATION

When there is any deployed air bag (including seat belt pretensioner), the air bag unit should be

replaced. Any DTC (Diagnostic Trouble Code) in the air bag unit should not be cleared since the

unit has data for status when the air bag was deployed as well as information related to the air bag

deployment.

Note that the used components related to the air bag, especially the air bag unit, should be

packaged in an air tight container to prevent any damage.

Do not connect a tester to any connector or component to check supply voltage or resistance of air

bag related components. The detonator may explode due to a sudden extra power supplied by the

tester.

Before removing or installing any air bag related components, disconnect the negative battery

cable.

Collision sensors, a kind of impact G (acceleration) sensor, detect the lateral and longitudinal collisions

and determine whether or not to deploy air bags. The roles of each collision sensor are as follows:

Front G sensors (inside the air bag unit)

Send signals to the front air bags (driver and passenger air bags) and the driver's and front

passenger's seat belt pretensioners. When the front collision G sensor sends out only the air bag

deployment signal, the signal deploys the two front air bags and activates their seat belt

pretensioners.

Once an air bag deploys, its repair parts vary according to the deployment situation and damage to the

vehicle from collision. Needed repairs also slightly vary between the front air bags and the curtain air

bags. The following are the differences:

Replacement parts when the front air bags deploy:

Air bag unit and its wiring (including connector), seat belt pretensioner and its wiring (including

connector), whole front air bags, instrument panel (IP)
