11-5

1461-01

1. SYSTEM DESCRIPTION

The starter (start motor) starts the engine with rotational power by converting the electric energy to the

mechanical energy.

When the engine is cranking, the pinion gear meshes with the ring gear. If the ring gear overruns, the

pinion gear clutch overruns to protect the pinion gear.

2. OPERATING PROCESS

1) System Layout

11-6

2) Circuit Diagram

12-3

8510-23

1. SYSTEM DESCRIPTION

1) System Description

The cruise control is an automatic speed control system that maintains a desired driving speed without

using the accelerator pedal.

The vehicle speed must be greater than 38 km/h to engage the cruise control. This feature is especially

useful for motorway driving.

The cruise control system is a supplementary system, which helps the driver to drive the vehicle at a

desired speed without using the accelerator pedal under the traffic condition where the vehicle-to-

vehicle distance meets the legal requirement.

12-4

2) Traffic Conditions for Using Cruise Control

Use the cruise control system only when the traffic is not jammed, driving on motorways or highways

where there is no sudden change in the driving condition due to traffic lights, pedestrian, etc.

Improper use of the cruise control could be dangerous.

- Do not use on winding roadsyy .

- Do not use in heavy traffic.

- Do not use on slippery, wet roads.

This could result in a loss of control, collision, and/or personal injuries.
