Operating the menus

Applies to Infotainment Amundsen.

Fig. 121  Operating the menus

Operating the menus

» Fig. 121

Browsing the menu, list entries
Expand/reduce the menu window
Open / close the menu window
Close the menu window

Alphanumeric keyboard

Applies to Infotainment Swing, Amundsen.

Fig. 122

Example of the keyboard display

The alphanumeric keyboard is used to enter letters, numbers and characters.

A
B
C



Description of the alphanumeric keyboard

» Fig. 122

Input line
Context-dependent:

▶



 - Toggle upper case to lower case and vice versa

▶



 - Switch to special characters

▶



 - Switch to numbers

Context-dependent:

▶



 - Switch to numbers

▶



 - Switch to Latin letters

▶



 - Switch to Cyrillic letters

- Display of visited entries (the number of visited entries is displayed in the

function surface)
Erase the entered characters
Hold to display the variants of the respective letters.

Switch between keyboards with specific characters of the selected

languages

» page 99

 or

» page 105

Space
Move the cursor within the input line to the left
Move the cursor within the input line to the right
Confirmation of the entered characters

Search

While entering characters, a search is made for corresponding entries.
The entry to be searched for (such as a telephone contact) must be entered

along with any special characters (diacritics).
By tapping on the function surface  a list of matching entries opens.

Switching Infotainment on/off

Applies to Infotainment Amundsen, Swing, Blues

›

To switch Infotainment on/off, press



.

Automatic switch-on of Infotainment

If Infotainment was not switched off with



 before the ignition was switched

off, it will automatically switch on when the ignition is switched on.

Automatic switch-off of Infotainment

If the vehicle key is pulled out of the ignition lock while Infotainment is switch-

ed on, Infotainment will switch off automatically.



A
B

C









  









92

Infotainment

If the vehicle is fitted with the starter button, Infotainment will switch off au-

tomatically after the engine is switched off and the door is opened.
With the ignition off, Infotainment will automatically switch off after about 30

minutes.
Infotainment switches off automatically under certain circumstances. Infotain-

ment informs you of this via a text message on the Infotainment display.

Infotainment restart

If Infotainment stops responding (if it “freezes”), it can be restarted by press-

ing and holding



 for longer than 10 s (does not apply to Infotainment Blues).

Show time and date on the screen

Applies to Infotainment Swing, Amundsen.

Standby mode

With the ignition on and infotainment off (Standbymode), it is possible to dis-

play the time and date on the Infotainment screen.
Applies to Infotainment Amundsen

▶

To switch the time and date display on/off, press the



 button, then tap

the function surface  → Screen Show clock in standby mode.

The display mode can be changed by finger motion across the screen side-

ways.
Applies to Infotainment Swing

▶

To switch the time and date display on/off, press the



 button, then tap

the function surface Screen → Show clock in standby mode.

"Screen off" mode

With the ignition on and functions Switch off screen (in 10 seconds) and Display clock

when screen is off

» page 98

 enabled, it is possible to display the time and date

when the Infotainment screen is switched off.
The display type depends on the display mode selected in standby mode (does

not apply to the Infotainment Swing).

Adjusting the volume

Every change in volume is displayed on the screen.

Applies to Infotainment Amundsen, Swing

›

To increase the volume, turn the controller



 clockwise.

›

To decrease the volume, turn the controller



 anticlockwise.

›

To mute, turn the controller



 anticlockwise to 0.

›

or: To activate/deactivate the mute setting, press the button



 (applies

to Infotainment Swing).

Applies to Infotainment Blues

›

To increase the volume, turn the control switch

1



» Fig. 116

 on page 89

clockwise.

›

To decrease the volume, turn the control switch

1

 anticlockwise.

›

To mute, turn the controller

1

 anticlockwise to 0.

The following symbol appears on the screen when the sound is muted .
If, at the time of muting, sound is being played from a source in the Media

menu, then the playback is stopped.

CAUTION

■

High volumes can cause sound resonance in the vehicle.

■

When changing or connecting an audio source, this may cause sudden

changes in volume. Reduce the volume before changing or connecting an au-

dio source.

Infotainment menus

Applies to Infotainment Amundsen.

Fig. 123

Overview of Infotainment me-

nus: Grid display



93

Infotainment operation

Fig. 124

Overview of Infotainment me-

nus: List

›

To display the overview of Infotainment menus, press the



 button.

›

To set the display mode, press the button



, then tap the function surface



 → Screen → Menu:.

›

Select the Grid display

» Fig. 123

 or Horizont. Display

» Fig. 124

 option.

Overview of Infotainment menus

Radio menu

» page 108

Media menu

» page 112

“ŠKODA Connect” Online Services

» page 12

SmartLink menu

» page 132

With a connection established to an external device,  the actual connec-

tion is shown instead of a symbol

▶



 Android Auto

» page 133

▶



 Apple CarPlay

» page 134

▶



 MirrorLink®

» page 134

Telephone menu

» page 123

Vehicle system settings

» page 155

Navigation menu

» page 137

 (Applies to Infotainment Amundsen)

List of traffic reports (TMC) (applies to Infotainment Amundsen)

» page 152

Media Command menu (Applies to Infotainment Amundsen)

» page 121

Images menu

» page 119

- Sound settings

» page 98

Infotainment settings

» page 98

























Configuration wizard

Applies to Infotainment Swing, Amundsen.

The configuration wizard is automatically displayed if there are at least two

non-selected menu items after turning on the Infotainment.

›

For manual display in Infotainment Amundsen, press the



 button, then

tap on the function surface  → Configuration wizard.

›

For manual display in Infotainment Swing, press the



 button, then tap

the function surface Configuration wizard.

The Configuration wizard allows you to set the following menu items in se-

quence.

Time and date format
Storing the radio station with the strongest reception signal at present
Pairing and connecting a telephone to the Infotainment system
Home address (applies to Infotainment Amundsen)
Setting “ŠKODA Connect” online services

The selected menu item is marked with the



 symbol.

Operating using an application in the external device

Applies to Infotainment Amundsen, Swing.

Some Infotainment functions can be operated using an application in the sup-

ported external device.
For the complete functionality of the application, data transmission from ex-

ternal devices must be activated and, if necessary, operation of the Infotain-

ment via the application must be approved.

Applies to Infotainment Amundsen

›

Activate data transfer in Infotainment. To do this, press the



 button and

then tap function surface  → Mobile device data transfer → Activate data transfer

for ŠKODA Apps.

›

Release Infotainment operation using the application. To do this, press the



 button and then tap function surface  Tap→ Mobile device data transfer →

Operation via apps: → Confirm/Allow .

›

Connect Infotainment to an external device via WLAN

» page 130

.

›

In the external device, launch an application for Infotainment operation (e.g.

ŠKODA Media Command).













94

Infotainment

Applies to Infotainment Swing

›

Activate data transfer in Infotainment. Press the



 button and then tap on

the function surface Activate data transfer for ŠKODA apps.

Note

The description of Infotainment operation using ŠKODA Media Command is

part of the application.

Voice control

Introduction to the subject

Applies to Infotainment Amundsen.

The navigation, telephone, radio and media menus can be operated by voice

commands.
The voice control system can be used either by the driver or by the front pas-

senger.

Function requirements for voice control

Infotainment is switched on.
No telephone call is being made using a telephone connected to Infotain-

ment.
The parking aid is not active.

Requirements for optimum voice command recognition

▶

The voice commands must only be issued when the



 symbol is displayed on

the Infotainment screen and the input tone has completely faded.

▶

Speak at your normal volume without intonation and long pauses.

▶

Avoid bad pronunciation.

▶

Close the doors and windows in order to prevent environmental influences

from interfering with the function of the voice control.

▶

You are advised to speak louder at higher speeds, so that the sound of your

voice is not drowned out by the increased ambient noise.

▶

During voice control, limit additional noise in the vehicle, e.g. passengers talk-

ing at the same time.

WARNING

The emergency number should be dialled manually. Your voice commands

may not be recognised in such situations. The telephone connection may

not be established or the connection may take too much time to complete.







CAUTION

■

The messages are generated by Infotainment. Flawless clarity (e.g. road or

city name) cannot always be guaranteed.

■

For some Infotainment languages, voice control is not available. Infotainment

indicates this through a text message that is displayed on the screen after set-

ting the Infotainment language.

Note

During voice control, no navigation announcements and traffic announce-

ments are played.

Switching voice control on/off

Fig. 125

Voice control: Main menu

Switch on

›

Press the button  on the multifunction steering wheel or button



 on

the Infotainment system.

The main menu is displayed

» Fig. 125

.

Switch off

›

Press the button twice  on the multifunction steering wheel or button



on the Infotainment system.

›

or: Issue the voice command “End voice control”.

95

Infotainment operation

Operation principle

Fig. 126

Example of screen display

The voice control main menu

» Fig. 125

 on page 95 contains basic voice com-

mands for the individual menus.
Other voice commands are displayed by tapping the respective function sur-

face, if required, by issuing the name of respective command (e.g. navigation).

The screen shows the following

» Fig. 126

.

Context-dependent:

▶



 The system is waiting for a voice command

▶



 The system recognises a voice command

▶



 The system plays a message

▶



 Voice command entry was stopped

Available list entries
Possible voice commands
Displaying other possible voice commands

Voice commands that can be issued are indicated in “quotation marks”.

Note

Depending on the equipment, the voice control symbols

A



» Fig. 126

 are also

displayed on the display of the instrument cluster.

A

B
C



Voice commands

Enter

The voice commands must only be issued when the



 symbol is displayed

on the Infotainment screen and the input tone has completely faded. The in-

put tone can be switched on/off. To do this, press



 and then tap on  →

Voice control.
It is not necessary to wait for the end of message playback when Infotainment

is playing a message. The Infotainment message can be terminated by pressing

the button



 or button  on the multifunction steering wheel. Then a voice

command can be issued. Voice control is much faster as a result.

Stop

This allows more time to enter the voice command (e.g. in the list of retrieved

contacts).
The process for entering voice commands can be stopped by moving a finger

up/down across the screen or by turning the controller  .
When stopping, the symbol changes from



 to .

Restore

The procedure for entering voice commands can be restarted in one of the fol-

lowing ways.

▶

By tapping on the function surface .

▶

By pressing the button



 on the Infotainment.

▶

By pressing the button  on the multifunction steering wheel.

Not recognising a voice command

If a voice command is not recognised by the Infotainment system three times

in succession, then voice control is stopped.

Correction of a voice command input

A voice command can be corrected, modified or re-entered by pressing the

button



 or the button  on the multifunction steering wheel. However,

this is only possible as long as the



 symbol is displayed on the screen.

You do not have to wait until the voice command is recognised by Infotain-

ment.



96

Infotainment

Voice commands can be used during voice control

Voice command

Function

“Back”

Return to the previous menu

“Help”

Reproduce and display possible voice commands

Voice commands that can be used while browsing the list entries

Voice command

Function

“Next page”

Browse menu/list/directory

“Previous page”
“First page”
“Last page”

Additional information

Navigation

To the destination, you are first required to issue the command“enter ad-

dress” and then follow Infotainment instructions.
It is not necessary to spell city and street names if the entered destination is

located in a country that has no voice control available for the language.

Online POI search

When “Infotainment Online”

» page 17

 services are activated, a POI search can

also be carried out online by issuing the voice command “Find online POI”.

Radio

In order for a radio station to be selected using voice command, the station

must be stored in the list of available stations

» page 110

 or in the preset list

» page 111

.

Updating the Infotainment software

Fig. 127

Available software updates on

the ŠKODA websites

The software update ensures optimum operation of Infotainment (e.g. com-

patibility with new telephones).
Information on Infotainment compatibility can be found on the following

ŠKODA Internet pages. This is done by scanning the QR code

» Fig. 127

 or en-

tering the following address into the web browser.

http://go.skoda.eu/updateportal

Applies to Infotainment Amundsen

▶

To determine the software version, press the



 button then tap the func-

tion surface  → System information.

▶

To start the software update, press the



 button, then tap the function

surface  → System information → Update software.

Applies to Infotainment Swing

▶

To determine the software version, press the



 button, then tap the Sys-

tem information function surface.

▶

To start the software update, press the



 button, then tap the System in-

formation → Update software function surface.

97

Infotainment operation

Infotainment settings - Amundsen

Infotainment system settings

Sound settings

›

Press the



 button, then tap on function surface  .

■

Volume - Volume settings

■

Radio announcements - Volume adjustment of traffic announcements (TP)

■

Navigation announcements - Volume setting for navigation announcements

■

Voice control - Volume setting for voice output

■

Maximum switch-on volume - Set the maximum volume when switching on In-

fotainment

■

Speed dependent Speed-dep. vol.adjust. - Increases the volume as speed increa-

ses

■

Bluetooth audio: - Volume setting of the device connected via Bluetooth

®

 au-

dio profile of the connected external device

■

Quiet - Low volume

■

Medium - Medium volume

■

Loud - High volume

■

Entertainment fading while parking - Lowers the audio volume (e.g. radio volume)

when the parking aid is activated

■

Entertainment fading (Navigation) - Lowers the audio volume (e.g. radio volume)

in the event of a navigation announcement

■

Bass - Mid - Treble - Sets the equalizer

■

Balance - Fader - Sets the balance between left and right, front and rear

■

ŠKODA Surround - Switch surround sound on/off (cannot be used in Radio

mode)

■

Virtual Subwoofer -Switch virtual subwoofer on/off (cannot be used in Radio

mode)

■

Touchscreen tone - Switch audible tone when touching the screen on/off

■

No navigation announcements during calls - Switches the navigation prompts on or

off during a telephone conversation

Display settings

›

Press the



 button, then tap on function surface  Tap→ Screen.

■

Menu: Setting the Infotainment menu display

■

Horizont. Display - Horizontal display

» Fig. 124

 on page 94

■

Grid display - Grid display

» Fig. 123

 on page 93

■

Switch off screen (in 10 seconds) - Enable/disable the automatic power off func-

tion

■

Display clock when screen is off - Time and date display when the screen is

switched off

■

Brightness: - Adjusts the brightness of the screen

■

Touchscreen tone - Switch audible tone when touching the screen on/off

■

Animation when finger near screen - Switch the proximity sensors on/off (when

the function is on the bottom bar with function surfaces will be displayed e.g.

in the main Navigation menu when you move a finger towards the screen)

■

Show clock in standby mode - Time and date displayed on the screen when the

ignition is switched on and Infotainment is switched off

Time and date settings

›

Press the



 button, then tap on function surface  → Time and date.

■

Clock time source: Time source settings: manual/GPS (applies to Infotainment

Amundsen)

■

Time: - Time settings

■

Summer time - Switches summer time on/off

■

Automatic summer time - Switches the automatic switch to summer time on/off

■

Time zone: - Select the time zone

■

Time format: - Set the time format

■

Date: - Date settings

■

Date format: - Set the date format

Infotainment language settings

›

Press the



 button, then tap on function surface  → Language.

›

Select the Infotainment language.

In some languages, after selecting the function surface, Female or Male are dis-

played for the choice of Infotainment voice prompts.

Note

■

When a language is selected which does not support voice control, Infotain-

ment will indicate this with a message on the screen.

■

The messages are generated by Infotainment. Flawless clarity (e.g. road or

city name) cannot always be guaranteed.

98

Infotainment

More keypad languages settings

›

Press the



 button, then tap on function surface  → Additional keypad lan-

guages.

In this menu, a keyboard language set can be added to allow characters other

than those in the currently selected language to be entered.

Unit settings

›

Press the



 button, then tap on function surface  Tap on→ Units .

■

Distance: - Distance units

■

Speed: - Speed units

■

Temperature: - Temperature units

■

Volume: - Volume units

■

Fuel consumption: - Consumption units

■

Pressure: - Pressure units for tyre pressure

Settings for data transfer

Activated data transfer enables data transfer between the Infotainment sys-

tem and the external device or the operation of some Infotainment functions

using the applications of the external device (e.g. ŠKODA Media Command).

›

Press the



 button, then tap on function surface  → Mobile device data trans-

fer.

■

Activate data transfer for ŠKODA apps - Switch data transfer on and off

■

Use apps to operate: - Setting Infotainment operation via the applications of the

external device (applies to Infotainment Amundsen)

■

Deactivate - Deactivation of Infotainment operation via an external device

■

Confirm - Infotainment operation with required confirmation

■

Allow - Infotainment operation without required confirmation

Voice control settings

›

Press the



 button, then tap on function surface  → Voice control.

■

Example commands (Infotainment system) - Turn on/off display of the menu con-

taining voice commands in the Infotainment screen when voice control is ac-

tivated

■

Example commands (instrument cluster) - Turn on/off display of the menu contain-

ing basic voice commands when voice control is activated

■

Voice control session start tone - Activate/deactivate the audible signal when

turning on the voice control

■

Voice control session end tone - Activate/deactivate the audible signal when voice

control ends

■

Input tone in voice dialogue - Activate/deactivate the audible signal for the voice

input

■

End tone in voice dialogue - Activate/deactivate the audible signal for the voice

input

Safe removal of the external device

›

Press the



 button, then tap on function surface  Remove safely: and select

the external device to be removed.

Reset to factory settings

›

Press the



 button, then tap on function surface  → Factory settings.

In this menu, all or only selected settings can be restored.

Bluetooth

®

 settings

›

Press the



 button, then tap on function surface  → Bluetooth.

■

Bluetooth - Switch the Bluetooth

®

 function on/off

■

Visibility: Switch the visibility of the Bluetooth

®

 device for other Bluetooth

®

 de-

vices on/off

■

Name: - Changing the name of the Bluetooth

®

device

■

Paired devices - Display the list of paired Bluetooth

®

devices

■

Find devices - Search for available Bluetooth

®

 devices

■

Bluetooth audio (A2DP/AVRCP) - Activate/deactivate the ability to connect a

Bluetooth

®

 audio device (e.g. MP3 player, tablet etc...)

Wireless settings

Applies to Infotainment Amundsen.

›

Press the



 button, then tap on function surface  → WLAN.



99

Infotainment settings - Amundsen

■

WLAN - List of available hotspots of external devices

■

WLAN - Switch Infotainment WLAN on/off

■

WPS quick connection (WPS button) - Establish a secure connection to the hot-

spot of the external device using WPS (applies to Infotainment Amundsen)

■

Manual settings - Parameter settings for searching and connecting to the hot-

spot of the external device

■

Network name - Enter the Hotspot name

■

Network key - Access passkey setting

■

Security level: Security setting (WPA2 always set)

■

Connect - Establish a connection

■

Find - Search / Restore the list of available hotspots

■

Mobile hotspot - Infotainment hotspot setting (the symbol  displayed with

the number of connected external devices)

■

Mobile hotspot - Switch the Infotainment hotspot on/off

■

WPS quick connection (WPS button) - Establish a secure connection to the Info-

tainment hotspot via WPS (applies to Amundsen)

■

Hotspot (WLAN) settings - Parameter settings for connection to the Infotain-

ment hotspot

■

Security level: Security setting (WPA2 always set)

■

Network key - Input of the access password

■

SSID: ... - Name of the infotainment Hotspots

■

Do not send network name (SSID) -Turn Infotainment hotspot visibility on/off

■

Store - Storage of the parameters set for the Infotainment hotspot

Network settings

Applies to infotainment Amundsen with the connected Carstick device.

›

Press the



 button, then tap on function surface  → Network.

■

Network settings - Sets the data connection from the associated telephone

service provider (APN settings)

■

Access point name: ... - Setting of the access point name

■

User name: ... - Setting of the user name

■

Password: ... - Password setting

■

Authentication: Sets the check type

■

Normal - Without verification

■

Secure - Verification required

■

Reset Access Point (APN) - Delete the parameters for the network setting

■

Store - Saves the parameters for the network setting

■

Network provider: ... - Selection of the network provider (the menu item is visi-

ble when the SIM card is inserted in the CarStick device)

■

Data roaming - Enable/disable the use of data roaming connection

■

Current connection details - Display of information on data downloaded (tap the

function surface Reset to delete the data information)

■

Data connection: - Usage settings for the data connection (Internet connection)

of the SIM card inserted in the CarStick device

■

Off - Use of the data connection is not possible

■

Ask - Use of the data connection is only possible after it has been confirmed

■

On - Use of the data connection is possible at any time

ŠKODA Connect online services settings

›

Press the



 button, then tap on function surface  → ŠKODA Connect (Online

Services).

■

Services Management - Information on licensing of the respective online serv-

ices and the option to switch them on/off

■

Registration - Enter the registration PIN code for online services (in the user

profile on the website ŠKODA Connect Portal receive)

System information

›

Press the



 button, then tap on function surface  → System information.

The information available will be displayed, for example regarding the Infotain-

ment hardware and software, the Bluetooth

®

 software version, the navigation

database version, etc.

›

To Update the Infotainment software, Bluetooth

®

 software version, etc., tap

on the function surface Update software.

›

To Update the POI categories created in the user profile on the ŠKODA

Connect Portal website, tap on the function surface Online update.

The information on available software updates is obtained from a ŠKODA part-

ner or from the following ŠKODA Internet pages.

http://go.skoda.eu/updateportal

100

Infotainment

Radio menu settings

Settings for all broadcasting ranges

›

In the main Radio menu, tap the function surface  .

■

Sound - sound settings

■

Scan - Automatic playback of short portions of all available stations in the

current frequency range

■

Arrow buttons: - Setting the function of the function surfaces  

■

Preset list - Change between stations stored under the preset buttons

■

Station list - Change between all available stations of the selected broadcast-

ing range

■

Traffic program (TP) - Switches TP traffic program on/off

■

Delete presets - Deletes the preset buttons

■

Station logos - Manual management of station logos

■

Radio text - Switches the radio text display (FM and DAB) on and off

■

Advanced settings - Other settings that are different depending on the selected

broadcasting range (FM and DAB)

Advanced settings (FM)

›

Select the FM band in the Radio main menu and tap on the function surface


 → Advanced settings.

■

Autostore station logos- Automatic storage of the station logos

■

Region for station logo: - Setting the region for station logo

■

Automatic frequency control (AF) - Activate/deactivate the search for alternative

frequencies of the station currently being played

■

Radio Data System (RDS) - enable/disable RDS function (receiving additional in-

formation from the station)

■

RDS Regional: Switch on/off automatic tracking of related regional stations

■

Fixed - Maintains the selected regional station continuously. When the sig-

nal is lost, another station must be set manually.

■

Automatic - Auto-selects the station with the best reception at the moment.

If you lose reception in the given the region, Infotainment will automatically

set another available region.

Advanced settings (DAB)

›

In the Radio main menu, select the DAB range and tap on the function sur-

face  → Advanced settings.

■

Autostore station logos- Automatic storage of the station logos

■

DAB traffic announcements - Switch DAB traffic announcements on/off

■

Other DAB messages - Switch other announcements on/off (e.g., warnings, re-

gional weather, sports reports, financial news)

■

DAB - DAB station tracking - Activate/deactivate automatic DAB station tracking

on another frequency or in other station groups

■

Automatic DAB - FM switching - Activate/deactivate auto-switching from DAB to

the FM broadcasting range if the DAB signal is lost

Automatic change from DAB to FM

In the event of bad DAB reception, the device tries to find an FM station.
The station name is followed by () while the station is being received on the

FM band. When the corresponding DAB station is received again, the system

automatically switches from FM to DAB.
If a DAB station is also not available in the FM band due to poor reception, In-

fotainment will be switched to mute.

Media menu settings

›

In the main Media menu, tap function surface  .

■

Sound - Sound settings

■

Mix/repeat including subfolders - Activate/deactivate the title display including

subfolders

■

Bluetooth - Settings for the Bluetooth

®

 function

■

WLAN - WLAN settings (applies to Infotainment Amundsen)

■

Remove safely: - Safe removal of the external device

■

Traffic program (TP) - Switches the traffic program on/off

Image menu settings

›

In the main Images menu, tap on function surface  .

■

Image view: - Image view settings

■

Mute - Display the maximum image size while retaining the aspect ratio

■

Automatic - Full screen display

■

Display time: - Set the display time for the slideshow

■

Repeat slideshow - Switching the slideshow repeat on/off

101

Infotainment settings - Amundsen

Telephone menu settings

›

In the main Telephone menu, tap the function surface  .

■

Hands-free telephone - Switching a call to the phone/back to Infotainment (the

menu item is displayed during a call)

■

Select mobile phone - Search for available telephones/list of paired tele-

phones/select telephone

■

Bluetooth - Bluetooth

®

 settings

» page 99

■

User profile - User profile settings

■

Manage favourites - Set the function surfaces for your favourite contacts

■

Mailbox number: - Enter the mailbox phone number

■

Sort by: - Arrangement of telephone contact list

■

Surname - Sort by contact name

■

Forename - Sort by contact's first name

■

Import contacts: - Import telephone contacts

■

Select ring tone - Select the ring tone (depending on the connected tele-

phone)

■

Reminder: Remember your mobile - Turn on/off the warning mode before forget-

ting the phone in the vehicle (if the phone was connected to the device)

■

Show pictures for contacts - Activate/deactivate the display of the images as-

signed to the contacts

■

Conference call - Activate/deactivate conference calls

■

Network - Set the telephone service provider network of the SIM card inser-

ted in the CarStick device (applies to Infotainment Amundsen)

» page 100

SmartLink+ menu settings

›

In the main SmartLink menu, tap on function surface  .

■

Activate data transfer for ŠKODA apps- Activate/deactivate data transfer for

ŠKODA applications

■

MirrorLink® - Settings of the system MirrorLink

®

■

Allow MirrorLink® notification to be shown - Turn the display of Mirror link

®

 appli-

cation messages on the Infotainment screen on/off

Navigation menu settings

Route options

›

In the main Navigation menu, tap the function surface  → Route options.

■

Suggest 3 alternative routes - Switch the menu for alternative routes on/off (eco-

nomical, fast, short)

■

Route: - Setting the preferred route

■

Most frequent routes - Show/hide the menu of the most frequent routes in the

split screen

■

Dynamic route - Switch on/off dynamic route recalculation due to TMC traffic

reports or online traffic reports

■



 Avoid motorways - Activate/deactivate the non-use of motorways in the

route calculation

■



 Avoid ferries and motorail trains - Activate/deactivate the non-use of ferries

and motorail trains in the route calculation

■



 Avoid toll roads - Activate/deactivate the use of toll roads for route calcula-

tion

■



 Avoid tunnels - Switch on/off use of tunnels for route calculation

■



 Avoid routes requiring toll stickers - Activate/deactivate the use of routes re-

quiring toll stickers on/off for route calculation

■

Show available toll stickers - Selection of countries for which a valid toll sticker

is required (routes requiring toll stickers are used for route calculation)

■



 Include trailer - Turn on / off the setting to take a trailer into account for

route calculation

» page 149

Map

›

In the main Navigation menu, tap the function surface  → Map.

■

Show road signs - Switch the display of traffic signs on/off

■

Lane guidance - Activate/deactivate the display of lane guidance

■

Show favourites - Activate/deactivate the display of favourites

■

Show POIs - Activate/deactivate the display of POIs

■

Select categories for POIs - Select the categories of displayed POIs

■

Show brand logos for POIs - Activate/deactivate the company logos available

for the POIs shown

■

Traffic flow settings - Setting for the display of a traffic obstruction received

from online traffic

■

Display free-moving traffic - Activate/deactivate the display of routes with

free-moving traffic

■

Display congestion - Activate/deactivate the display of routes with heavy traf-

fic

■

Display traffic events (symbols on map) - Activate/deactivate the display of

routes with a traffic incident

102

Infotainment

Manage memory

›

In the main Navigation menu, tap the function surface  → Manage memory.

■

Sort contacts: - Setting the configuration of the phone book

■

By surname - Sorting by the contact surname

■

By first name - Sorting by the contact first name

■

Define home address - Enter the home address

■

Delete "My POIs" - Delete your own POI categories (Personal POI)

■

Update "My POIs" (SD/USB) - Import/update your own POI categories (Personal

POI)

■

Retrieve "My POIs" (online) - Online import/update of your own POI categories

created in the user profile on the ŠKODA Connect Portal website

■

Import destinations (SD/USB) - Import destinations in vCard format

■

Delete user data - Delete user data (by tapping function surface Delete and con-

firming the deletion)

■

Last destinations - Delete the last destinations

■

Dest. memory - Delete the stored destinations

■

Online destinations - Delete the stored online destinations

■

Routes - Delete saved routes

■

My points of interest (Personal POI) - Delete the custom POIs

■

Entered cities - Delete the history of places already entered via the address

■

Home address - Delete the stored home address

■

Flagged destination - Delete the flagged destination

■

Most frequent routes - Delete the most travelled routes

Navigation announcements

›

In the main Navigation menu, tap the function surface  → Navigation announce-

ments.

■

Volume - Volume control of the navigation announcements

■

Entertainment fading (Navigation) - Adjust the fading of the audio volume (e.g. ra-

dio volume) when navigation announcements are being made

■

No navigation announcements during calls - Activate/deactivate non-playback of

navigation announcements during a telephone call

■

Note:“My POIs” - Activate/deactivate an audible indication when approaching a

custom POI (if supported by the imported custom POI)

Speed limits

›

In the main Navigation menu, tap the function surface  → Speed limits.

The maximum speed limits for the current country are displayed.
When the function is switched on Note:National border crossed

» page 103

, Ad-

vanced settings, display the country-specific speed limits when crossing inter-

national borders.

Fuel options

›

In the main Navigation menu, tap the function surface  → Fuel options.

■

Select preferred fuel station - Select your preferred fuel station brand (the selec-

ted station brand will be displayed in the first three positions of the list)

■

Fuel warning – Activate/deactivate the display of a warning message with the

option to search for the nearest petrol station when the fuel level reaches

the reserve area

Version information

›

In the main Navigation menu, tap the function surface  → Version information .

A list of countries is displayed that exist for the navigation data, together with

the date of the last update.
The navigation data can be updated by tapping on the Update function surface

(SD/USB) or Online update.

The information on updating the navigation data can be obtained from a

ŠKODA partner or on the following ŠKODA websites.

http://go.skoda.eu/updateportal

Advanced settings

›

In the main Navigation menu, tap the function surface  → Advanced settings.

■

Time display: - Select the time display in the status line

■



 - Estimated arrival time at destination

■



 Estimated travelling time to the destination

■

Status line: - Selection of the destination type, for which the status line, the

route and travel time are displayed (this also determines which destination

type is displayed on the map after selecting  →  is displayed on the map)

■



 - Route destination

■



 - Next waypoint

■

Note:National border crossed - Switching the display of information on country-

specific speed limits when crossing a national border on/off



103

Infotainment settings - Amundsen

■

Demo mode - Activate/deactivate guidance in demo mode

■

Define demo mode starting point - Specify the start point of the route guidance

in demo mode by entering the address or the current vehicle position

Infotainment settings – Swing

Infotainment system settings

Sound settings

›

Press the



 or



 button, then tap the function surface Sound.

■

Volume - Volume settings

■

Maximum switch-on volume - Set the maximum volume when switching on In-

fotainment

■

Announcements - Adjustment of traffic announcements volume (TP)

■

Speed-dep. vol.adjust. - Volume increases as speed increases

■

Entertainment fading - Lowers the audio volume (e.g. radio volume) with acti-

vated parking aid

■

Entertainment fading (Navigation) - Reduction of audio volume (e.g. radio vol-

ume) for navigation announcements originating from the SmartLink appli-

cation

■

Bluetooth audio: - Volume setting of the device connected via Bluetooth

®

 au-

dio profile

■

Balance - Fader - Sets the balance between left and right, front and rear

■

Bass - Mid - Treble - Sets the equalizer

■

Touchscreen tone - Activates/deactivates the acoustic tone when touching the

screen

■

ŠKODA Surround - Switch surround sound on/off (cannot be used in Radio

mode)

■

Virtual Subwoofer -Switch virtual subwoofer on/off (cannot be used in Radio

mode)

Display settings

›

Press the



 button, then tap the function surface Screen.

■

Switch off screen (in 10 seconds) - Enable/disable the automatic power off func-

tion

■

Display clock when screen is off - Time and date display when the screen is

switched off

■

Brightness: - Adjusts the brightness of the screen

■

Touchscreen tone - Switch audible tone when touching the screen on/off

■

Show clock in standby mode - Time and date displayed on the screen when the

ignition is switched on and Infotainment is switched off

104

Infotainment

Time and date settings

›

Press the



 button, then tap the function surface Time and date.

■

Time: - Time settings

■

Time format: - Set the time format

■

Summer time - Switches summer time on/off

■

Automatic summer time - Switches the automatic switch to summer time on/off

■

Date: - Date settings

■

Date format: - Set the date format

Infotainment language settings

›

Press the



 button, then tap the function surface Language.

›

Select the Infotainment language.

More keypad languages settings

›

Press the



 button, then tap the function surface More keypad languages.

In this menu, a keyboard language set can be added to allow characters other

than those in the currently selected language to be entered.

Unit settings

›

Press the



 button, then tap the function surface Units.

■

Distance: - Distance units

■

Speed: - Speed units

■

Temperature: - Temperature units

■

Volume: - Volume units

■

Fuel consumption: - Fuel consumption units

■

Pressure: - Pressure units for tyre pressure

Activating/deactivating data transfer

Activated data transfer enables data transfer between the Infotainment and an

external device.

›

Press the



 button and then tap on the function surface Activate data trans-

fer for ŠKODA apps.

Safe removal of the external data source

›

Press the



 button, then tap the function surface Remove safely and select

the external device to be removed.

Reset to factory settings

›

Press the



 button, then tap the function surface Factory settings.

In this menu, individual settings or all settings can be restored at the same

time.

Bluetooth

®

 settings

›

Press the



 button, then tap the function surface Bluetooth.

■

Bluetooth - Switch the Bluetooth

®

 function on/off

■

Visibility: Switch the visibility of the Bluetooth

®

 device for other Bluetooth

®

 de-

vices on/off

■

Forename - Change the name of the Bluetooth

®

 unit

■

Paired devices - Display the list of paired Bluetooth

®

devices

■

Find devices - Search for available Bluetooth

®

 devices

■

Bluetooth audio (A2DP/AVRCP) - Activate/deactivate the ability to connect a

Bluetooth

®

 audio device (e.g. MP3 player, tablet etc...)

Settings of online services ŠKODA Connect

›

Press the



 button, then tap the function surface ŠKODA Connect (online serv-

ices).

■

Services Management - Information on licensing of the respective online serv-

ices and the option to switch them on/off

■

registration - Enter the registration PIN code for online services (in the user

profile on the website ŠKODA Connect Portal receive)

System information

›

Press the



 button, then tap the function surface System information.

The information available will be displayed, for example regarding the Infotain-

ment hardware and software, Bluetooth

®

 software version, etc.

›

To Update the Infotainment software, Bluetooth

®

 software version, etc., tap

on the function surface Update software.



105

Infotainment settings – Swing

The information on available software updates is obtained from a ŠKODA part-

ner or from the following ŠKODA Internet pages.

http://go.skoda.eu/infotainment

Radio menu settings

Settings for all broadcasting ranges

›

In the main Radio menu, tap the function surface  .

■

Scan - Automatic playback of short portions of all available stations in the

current frequency range

■

Sound - sound settings

■

Arrow buttons: - Setting the function of the function surfaces  

■

Presets - Change between stations stored under the preset buttons

■

Stations - Change between all available stations of the selected broadcasting

range

■

Traffic program (TP) - Switches the traffic program on/off

■

Radio text - Switches the radio text display (FM and DAB) on and off

■

Station list: - Sort types of radio stations in the station list (FM)

■

By group - Group sorting by transmitted program

■

Alphabet - Alphabetically order according to station name

■

Station logos - Manual management of station logos

■

Delete presets - Delete the stations stored under preset buttons

■

Advanced settings - Other settings that are different depending on the selected

broadcasting range (FM and DAB)

Advanced settings (FM)

›

Select the FM band in the Radio main menu and tap on the function surface


 → Advanced settings.

■

RDS Regional: Switch on/off automatic tracking of related regional stations

■

Automatic - Auto-selects the station with the best reception at the moment.

If you lose reception in the given the region, Infotainment will automatically

set another available region.

■

Fixed - Maintains the selected regional station continuously. When the sig-

nal is lost, another station must be set manually.

■

Automatic frequency control (AF) - Activates/deactivates the search for alterna-

tive frequencies of the station currently being played

■

Radio Data System (RDS) - enable/disable RDS function (receiving additional in-

formation from the station)

■

Station list: - Sort types of radio stations in the station list (FM)

■

By group - Group sorting by transmitted program

■

Alphabet - Alphabetically order according to station name

Advanced settings (DAB)

›

In the Radio main menu, select the DAB range and tap on the function sur-

face  → Advanced settings.

■

DAB traffic announcements - Enable/disable DAB announcements

■

Other DAB messages - Switch other announcements on/off (e.g., warnings, re-

gional weather, sports reports, financial news)

■

DAB - DAB station tracking - Activate/deactivate automatic DAB station tracking

on another frequency or in other station groups

■

Automatic DAB - FM switching - Enable/disable auto-switching from DAB to the

FM frequency band if the DAB signal is lost

DAB program tracking

When a DAB transmitter is a part of several broadcast stations and if the cur-

rent station group is not available on any other frequency, then when the signal

is poor, the same station will be searched in another station group.

Automatic change from DAB to FM

In the event of bad DAB reception, the device tries to find an FM station.
The station name is followed by () while the station is being received on the

FM band. When the corresponding DAB station is received again, the system

automatically switches from FM to DAB.
If a DAB station is also not available in the FM band due to poor reception, In-

fotainment will be switched to mute.

Media menu settings

›

In the main Media menu, tap function surface  .

■

Sound - Sound settings

■

Mix/repeat including subfolders - Activate/deactivate the title display including

subfolders

■

Bluetooth - Settings for the Bluetooth

®

 function

■

Traffic program (TP) - Switches the traffic program on/off

■

Remove safely: - Safe removal of the external device

106

Infotainment

Telephone menu settings

›

In the main Telephone menu, tap the function surface  .

■

Hands-free telephone - Switching a call to the phone/back to Infotainment (the

menu item is displayed during a call)

■

Select mobile phone - Search for available telephones/list of paired tele-

phones/select telephone

■

Find - Search for available phones

■

Bluetooth - Bluetooth

®

 settings

» page 105

■

User profile - User profile settings

■

Manage favourites - Set the function surfaces for your favourite contacts

■

Sort by: - Arrangement of telephone contact list

■

Surname - Sort by contact name

■

Forename - Sort by contact's first name

■

Import contacts - Import phone contacts

■

Select ring tone - Select the ring tone (depending on the connected tele-

phone)

■

Reminder: Remember your mobile - Turn on/off the warning mode before forget-

ting the phone in the vehicle (if the phone was connected to the device)

■

Simultaneous calls - Enable/disable the option to hold two concurrent calls

SmartLink+ menu settings

›

In the main SmartLink menu, tap on function surface  .

■

Activate data transfer for ŠKODA apps- Activate/deactivate data transfer for

ŠKODA applications

■

MirrorLink® - Settings of the system MirrorLink

®

■

Connect automatically via Bluetooth - Activate/deactivate the option of pairing

and connecting the external device via Bluetooth

®

■

Allow MirrorLink® notification to be shown - Activate/deactivate the display of

Mirror link

®

 application messages on the Infotainment screen

Infotainment settings – Blues

Infotainment system settings

Introduction to the subject

Individual menu items for the Infotainment settings can be accessed by press-

ing one of the buttons below.

- Sound settings

» page 107

Infotainment settings

» page 107

Settings of the currently opened Radio

» page 108

 or Media menu

» page 108

Sound settings

›

Press the



 button repeatedly.

The following menu items of the settings are displayed in sequence.

■

Bass - bass setting

■

Middle - mid-tone setting

■

Treble - treble setting

■

Balance - Sets the balance between the left and right-hand sides

■

Fader - Sets the sound focus between front/rear (applies to vehicles with rear

speakers)

Infotainment settings

›

Press the



 button repeatedly.

The following menu items are displayed in sequence.

■

GALA - Speed-sensitive volume adjustment (higher numbers indicate a steep-

er increase in the volume level)

■

On volume - Sets the maximum volume when the Infotainment is switched on

■

TP volume - Sets the volume for in-coming traffic program alerts (TP)

■

PDC audio - Lowers the audio volume (e.g. radio volume) when the parking aid

is activated

■

Low - Low volume attenuation

■

Middle - Medium volume attenuation

■

High - High volume attenuation









107

Infotainment settings – Blues
