Operating weight

Engine

Transmission

Operating weight (kg)

1.0 ltr./85 kW TSI

MG

1340

DSG

1361

1.5 l/110 kW TSI

MG

1378

DSG

1387/1393

a)

DSG 4x4

1510

2.0 l/140 kW TSI

DSG 4x4

1565

1.6 l/85 kW TDI CR

MG

1447

DSG

1462

2.0 l/105 kW TDI CR

DSG

1455

2.0 l/110 kW TDI CR

MG

1461

MG 4x4

1561

DSG 4x4

1591

2.0 l/140 kW TDI CR

DSG 4x4

1610

a)

Applies to cars with the EU6AG emission standard.

Note

If required, you can find out the precise weight of your vehicle at a specialist

garage.

Payload

It is possible to calculate the approximate maximum payload from the differ-

ence between the permissible total weight and the operating weight.
The payload consists of the following weights.

▶

The weight of the passengers.

▶

The weight of all items of luggage and other loads.

▶

The weight of the roof load including the roof rack system.

▶

The weight of the equipment that is excluded from the operating weight.

▶

Trailer bearing load for trailer towing

» page 252

.

Measurement of fuel consumption and CO

2

 emissions according to

ECE Regulations and EU Directives

The data on fuel consumption and CO

2

 emissions were not available at the

time of going to press.
The valid specifications for your vehicle can be found in the technical vehicle

documentation (e.g. vehicle approval documentation, the COC document) or

at a ŠKODA partner.

Note

■

The emission and fuel consumption values have been determined in accord-

ance with rules and under conditions set out by legal or technical requirements

for determining operational and technical data for motor vehicles.

■

Depending on the range of equipment, style of driving, traffic situation,

weather influences and vehicle condition, consumption values may deviate

from the indicated values.

301

Technical data

Dimensions

Fig. 356  Vehicle dimensions

The vehicle dimensions given in the vehicle's technical documentation always take precedence over the details in the Owner's Manual.
The dimensions listed below are for the basic model without any optional equipment.

Vehicle dimensions for operating weight without driver (in mm)

» Fig. 356

Specification

Value

A

Height

1603- 1607

a)

B

Front track

1576

C

Width

1841

D

Rear track

1541- 1547

a)

E

Width including exterior mirror

2025

F

Clearance

-

b)

G

Wheel base

2638- 2630

a)

H

Length

4382

a)

Applies to Karoq 4x4 vehicles.

b)

The valueswere not available at the time of going to press.

302

Technical data

Overhang angle

Fig. 357

Overhang angle

Angle

» Fig. 357

Approach angle
Departure angle

The values shown indicate the maximum incline of an embankment, up which

the vehicle can drive at a slow speed without collision of the bumper or under-

body. The values listed represent the maximum axle load at the front and rear.

Overhang angle (°)

Approach angle

Departure angle

18.4- 18.8

a)

18.7- 19.5

a)

a)

Applies to Karoq 4x4 vehicles.

A
B

303

Technical data

Vehicle-specific details per engine type



Introduction

The values given have been determined in accordance with the rules and conditions specified in statutory or technical regulations for determining operational

and technical data for motor vehicles.
The exhaust gas standard is specified in the vehicle's technical documentation, as well as in the declaration of conformity (in so-called COC document). The

declaration of conformity (the so-called. COC document) can be obtained from a ŠKODA Partner (only valid for some countries and some models).

1.0 ltr./85 kW TSI engine

Output (kW at 1/min)

85/5000-5500

Maximum torque (Nm at rpm)

200/2000-3500

Number of cylinders/displacement (cm

3

)

3- 999

Transmission

MG

DSG

Top speed (km/h)

with the mentioned gear engaged

187

(5)

186

(6)

Acceleration 0-100 km/h (s)

10.6

10.7

1.5 l/110 kW TSI engine

Output (kW at 1/min)

110/5000-6000

Maximum torque (Nm at rpm)

250/1500-3500

Number of cylinders/displacement (cm

3

)

4- 1498

Transmission

MG

DSG

DSG 4x4

Top speed (km/h)

with the mentioned gear engaged

204

(5)

203

(5)

196

(6)

Acceleration 0-100 km/h (s)

8.9

9.0

9.1

304

Technical data

2,0 ltr./140 kW TSI engine

Output (kW at 1/min)

140/4200-6000

Maximum torque (Nm at rpm)

320/1500-4100

Number of cylinders/displacement (cm

3

)

4- 1984

Transmission

DSG 4x4

Top speed (km/h)

with the mentioned gear engaged

211

(6)

Acceleration 0-100 km/h (s)

7.0

1.6 l/85 kW TDI CR engine

Output (kW at 1/min)

85/3250-4000

Maximum torque (Nm at rpm)

250/1750-3200

Number of cylinders/displacement (cm

3

)

4- 1598

Transmission

MG

DSG

Top speed (km/h)

with the mentioned gear engaged

186

(5)

186

(7)

Acceleration 0-100 km/h (s)

11.0

11.1

2.0 l/105 kW TDI CR engine

Output (kW at 1/min)

105/3500-4000

Maximum torque (Nm at rpm)

320/1750-3000

Number of cylinders/displacement (cm

3

)

4- 1968

Transmission

DSG

Top speed (km/h)

with the mentioned gear engaged

202

(6)

Acceleration 0-100 km/h (s)

9.1

305

Technical data

2.0 l/110 kW TDI CR engine

Output (kW at 1/min)

110/3500-4000

Maximum torque (Nm at rpm)

340/1750-3000

Number of cylinders/displacement (cm

3

)

4- 1968

Transmission

MG

MG 4x4

DSG 4x4

Top speed (km/h)

with the mentioned gear engaged

205

(6)

196

(6)

195

(6)

Acceleration 0-100 km/h (s)

9.0

8.9

8.8

2.0 l/140 kW TDI CR engine

Output (kW at 1/min)

140/3500-4000

Maximum torque (Nm at rpm)

400/1750-3250

Number of cylinders/displacement (cm

3

)

4- 1968

Transmission

DSG 4x4

Top speed (km/h)

with the mentioned gear engaged

211

(6)

Acceleration 0-100 km/h (s)

7.4

306
