Skoda Karoq (2019 year). Manual - part 4

If the boot lid is closed after locking the vehicle and the key with which the

vehicle was locked remains in the luggage compartment, the lid is automatical-

ly unlatched (partially opened). After automatically unlocking, the turn signal

lights will flash four times. The boot lid remains unlatched (partially opened);

the other doors remain locked.

CAUTION

Some types of gloves can affect the unlocking or locking device via the sen-

sors in the door handle.

Deactivating KESSY



Read and observe   and   on page 59 first.

›

Lock the vehicle with the button  on the key.

›

Within 5 s, touch the sensor on the door handle with your finger

» Fig. 49

 on

page 60 - . Deactivation is confirmed by a single flash of the direction indi-

cators.

›

To check the deactivation, wait at least 10 seconds and then pull the door

handle. The door must remain locked.

The KESSY system is activated again automatically after the vehicle is un-

locked.

Locking/unlocking the vehicle with the central locking button

Fig. 50

Central locking button



Read and observe   and   on page 59 first.

Conditions for the locking/unlocking using the central locking button.

The vehicle is not locked from the outside.
All doors are closed.





›

Tolock, press the button  Press

» Fig. 50

Locking is displayed in the button by the illumination of the



 symbol.

The following applies after locking.

▶

Opening the doors and the boot lid from the outside is not possible.

▶

The doors can be unlocked and opened from the inside by a single pull on the

opening lever of the respective door.

WARNING

Doors locked from the inside make it difficult for rescuers to get into the

vehicle in an emergency – risk to life!

SafeLock



Read and observe   and   on page 59 first.

SafeLock prevents the doors from behind opened from inside as well as win-

dow operation. This makes it more difficult for anyone to break into the vehi-

cle.

Switching on

SafeLock switches on when the vehicle is locked.
This function is enabled after switching off the ignition with the message Check

safe lock.! Log book! In the instrument cluster display.

Switch-on display

With the activated SafeLock, the warning light in the driver´s door flashes for

2 seconds in rapid succession, this then starts to flash at longer intervals.

Switching off

▶

By locking twice within 2 seconds.

▶

or: by deactivating the interior monitor and the towing protection

» page 64

.

The warning light in the driver´s door flashes fast for about 2 seconds, goes

out and starts to flash at longer intervals after about 30 seconds.
If the vehicle is locked and the safe securing system is switched off, the door

can be opened separately from the inside by a single pull on opening lever.
The safelock switches on the next time the vehicle is locked.



61

Unlocking and opening

WARNING

If the car is locked and the safe securing system activated, no people must

remain in the car as it will then not be possible to either unlock a door or

open a window from the inside. The locked doors make it more difficult for

rescuers to get into the vehicle in an emergency – risk to life!

Individual settings



Read and observe   and   on page 59 first.

The following central locking functions can be set individually in Infotainment

in the menu



/  →  → Opening and closing.

All doors

The function allows you to unlock all doors, the boot lid and the fuel filler flap.

Single door

The function allows you to unlock only the driver's door and the fuel filler flap

with the radio remote control. KESSY allows the unlocking of a single door

which is in the vicinity of the key, as well as the fuel filler flap. The other doors

and the boot lid are only unlocked once the door handle is unlocked or

touched.

Doors on a vehicle side

This function enables you to unlock both doors on the driver's side and the fuel

filler flap with the radio remote control unit. KESSY allows the unlocking of

both doors which are in the vicinity of the key, as well as the fuel filler flap. The

other doors and the boot lid are only unlocked once the door handle is un-

locked or touched.

Automatic locking/unlocking

This function enables the locking of all doors and the boot lid from a speed of

15 km/h. Opening the doors and the boot lid from the outside is not possible.
The renewed unlocking of the doors and the boot lid is carried out when the

ignition key is removed or when the door is opened from inside (depending on

the individual setting for the central locking system).

Note

The individual adjustment of the central locking system is stored (depending

on the Infotainment type) in the active user account personalisation

» page 57

.

Open / close door

Fig. 51  Door handle/door opening lever



Read and observe   and   on page 59 first.

›

To open from outside, unlock the vehicle and pull the door handle

A

 in the

direction of arrow

» Fig. 51

.

›

To open from inside, pull on the door opening lever

B

 and push the door

away from you.

›

To close from inside, grip the handle

C

 and close the door.

WARNING

■

The door must be closed properly, otherwise it could open whilst driving -

risk of death!

■

Only open and close the door when no one is located in the opening/clos-

ing range – risk of injury!

■

Never drive with the doors open - it can be fatal!

■

An opened door can close automatically if there is a strong wind or the

vehicle is on an incline – risk of injury!

62

Operation

Child safety lock

Fig. 52  Rear door: Child safety system switch on / off

Fig. 53

Child safety lock with electric

operation



Read and observe   and   on page 59 first.

The child safety lock can be operated manually or electrically depending on

equipment.
The child safety lock prevents the rear door from being opened from the in-

side. The door can only be opened from the outside.

Manually controlled parental settings

›

To switch on, turn the parental control with the vehicle key in position 

» Fig. 52

.

›

To switch off, turn the parental control with the vehicle key in position .

Child safety lock with electric operation

›

To switch on/off the child safety lock in the left rear door, press the button

A

 in the driver's door

» Fig. 53

.

›

To switch on/off the child safety lock in the right rear door, press button

B

in the driver's door.

Locking is displayed in the button by the illumination of the symbol .
When with electric operation in addition to the electric window is blocked in

the respective door.

Malfunctions



Read and observe   and   on page 59 first.

Synchronising the remote control

If the buttons on the remote control key have been operated several times be-

yond the effective range of the system or the battery in the remote control

key has been replaced and the vehicle cannot be unlocked using the remote

control, the key must be synchronised.

›

Press any button on the remote control key.

›

Unlock the door with the key in the lock cylinder within 1 minute of pressing

the button.

Fault with the central locking

If the warning light in the driver's door initially flashes quickly for around 2 sec-

onds, and then illuminates for 30 seconds without interruption before flashing

again slowly, you will need to seek the assistance of a specialist garage.
A fault in the central locking system means the vehicle doors and the boot lid

cannot be emergency locked or emergency unlocked

» page 289

.

Failure of the system KESSY

If there is a fault in the KESSY system, the appropriate error message is dis-

played in the instrument cluster.

Low voltage of the key battery

If the voltage of the key battery is too low, a message appears in the display of

the instrument cluster referring to the need to replace the battery. Replace the

battery

» page 288

.

Anti-theft alarm system



Introduction

The alarm system triggers audible and visual signals if an attempt is made to

break into the vehicle (hereafter referred to as alarm).



63

Unlocking and opening

The alarm system is activated automatically approximately 30 seconds after

the vehicle is locked. This is automatically disabled after release.

CAUTION

Before leaving the vehicle, it must be checked that all of the windows, doors

and the sliding/tilting roof are locked in order to ensure the full functionality of

the anti-theft alarm system.

Note

The alarm system has its own power source, service life of which is 5 years. In

order to ensure functionality of the alarm system, we recommend that you get

the alarm checked after this time by a specialist garage.

Alarm trigger



Read and observe   on page 64 first.

The alarm is triggered when one of the following unauthorised actions is acti-

vated on the vehicle with an activated warning system.

▶

Opening the bonnet.

▶

Opening the boot lid.

▶

Opening the doors.

▶

Manipulation of the ignition lock.

▶

Towing the vehicle.

▶

Movement in the vehicle.

▶

Sudden and significant voltage drop of the electrical system.

▶

Uncoupling the trailer.

An alarm is triggered also when the driver's door is unlocked and opened by

the lock cylinder.
The alarm is switched off by pressing the  button on the key or switching on

the ignition.

Interior monitor and towing protection



Read and observe   on page 64 first.

The interior monitor detects movements inside the locked vehicle and then

triggers the alarm.
The anti-towing detects tilts in the locked vehicle and then triggers the alarm.

These functions should be deactivated if there is a possibility that the alarm

will be triggered by movements (e.g. by people or animals) within the vehicle

interior or if the vehicle has to be transported (e.g. by train or ship) or towed.

Disable both functions once

▶

In the infotainment system, in menu



/  →  → Open and close,

▶

By locking twice within 2 seconds.

Safelock is switched off during deactivation

» page 61

.

CAUTION

The opened glasses storage compartment reduces the effectiveness of the in-

terior monitor. To ensure the full functionality of the interior monitor, the

glasses storage compartment must always be closed before locking the vehi-

cle.

Manually operated tailgate



Introduction

WARNING

■

Never drive with the boot lid open or ajar, as otherwise exhaust gases

may get into the interior of the vehicle – risk of poisoning!

■

Ensure that the lock is properly engaged after closing the lid. Otherwise,

the lid might open suddenly while the vehicle is moving, even if the lid was

locked – risk of accident!

■

Make sure that when closing the boot lid, no body parts are crushed -

there is danger of injury!

■

Do not press on the rear window when closing the boot lid, it could crack

– risk of injury!

64

Operation

Open/close boot lid

Fig. 54  Opening / closing tailgate



Read and observe   on page 64 first.

›

To open, press the

A

 button in the direction of arrow

1

» Fig. 54

.

›

Raise the lid in the direction of the arrow

2

.

›

To close, grab the mount

B

 and pull in the direction of arrow

3

.

Note

Button

A



» Fig. 54

 is deactivated when starting or at a speed of more than 5

km/h. The button is activated again after the vehicle has stopped and a door is

opened.

Setting the delayed locking of the boot lid



Read and observe   on page 64 first.

If the boot lid is unlocked with the  button on the key, the lid is automatical-

ly locked again after closing.
The period after which the boot lid is locked automatically can be extended by

a specialist garage.

CAUTION

There is a risk of unwanted entry into the vehicle before the boot lid is locked

automatically.

Electric boot lid



Introduction

The boot lid (hereinafter as lid) can be operated electrically and manual in the

event of an emergency

» page 67

.

WARNING

■

Ensure that the lock is properly engaged after closing the lid. Otherwise,

the lid might open while the vehicle is moving - risk of accident.

■

Never drive with the lid open or unlatched, as otherwise exhaust gases

may get into the interior of the vehicle – risk of poisoning!

■

Only open and close the lid when no one is located in the opening/closing

range – risk of injury!

■

Make sure that no limbs are caught or crushed when closing the lid - risk

of injury!

CAUTION

■

Do not attempt to close the lid manually during electrical motion - there is a

risk of damaging the electric lid operation.

■

Lock the vehicle before driving through a car wash (or with the central lock-

ing button). In some car washes the boot lid might open automatically due to

the pressure action of the washing brushes - there is a risk of damage to the

vehicle interior, as well as to the objects being transported.

CAUTION

■

Before opening / closing the flap, check that there are no objects in the

opening / closing area that could damage the flap, and if there are any objects

in the immediate vicinity of the vehicle that could damage the vehicle interior

and the objects being transported.

■

In certain circumstances, if the lid is loaded (e.g. by a thick layer of snow), the

opening process of the lid can be interrupted. Remove the snow from the lid to

re-enable the electrical operation.

■

If the lid closes automatically (e.g. under load of snow), you will hear an inter-

mittent beep.

■

The flap is always to be close before disconnecting the battery.

65

Unlocking and opening

Description of operation

Fig. 55  Lid operation



Read and observe   and   on page 65 first.

Ways to open the lid

▶

By pressing the handle

A



» Fig. 55

.

▶

By pulling the button

C

.

▶

By holding the button

D

 on the key.

If the lid hits an obstacle when closing, it stops and an audible signal sounds.

Ways to close the lid

▶

By pressing the button

B



» Fig. 55

.

▶

By holding the button

D

 on the key (applies to vehicles with the KESSY key-

less unlocking system). The key must be located at a maximum distance of 2

m from the lid.

▶

By pressing the handle

A

.

▶

By pulling and holding the button

C

. The opening process stops when one

releases the button.

▶

By briefly pressing the lid downwards.

If the flap meets an obstacle when it is closed, it stops, an acoustic signal

sounds and the flap moves back a few centimetres.

Ways to stop the lid movement

▶

By pressing the button

B



» Fig. 55

.

▶

By pulling on the button

C

 or by releasing the button.

▶

By holding the button

D

 on the key.

▶

By pressing the handle

A

.

Audible signals

An acoustic signal is sounded when opening/closing the lid by means of the

button

C

 or

D

.

Note

■

Button

A



» Fig. 55

 is deactivated when starting or at a speed of more than 5

km/h. The button is activated again after the vehicle has stopped and a door is

opened.

■

If you rapidly enter the vehicle during the opening or closing process of the

lid, the whole vehicle may jerk and, as a result, the movement of the lid can be

interrupted.

Set the top position of the lid



Read and observe   and   on page 65 first.

The top position of the lid can be adjusted (e.g. in a limited space to open the

lid due to the garage height or for a more comfortable operation, depending

on the height of the person).

Adjusting the top position of the lid

›

Stop the lid in the desired position.

›

Press and hold button

B



» Fig. 55

 on page 66 until you hear an acoustic sig-

nal.

Adjusting the top starting position of the lid

›

Carefully raise the flap manually to the limit.

›

Press and hold button

B



» Fig. 55

 on page 66 until you hear an acoustic sig-

nal.

Note

The top position which is reached when the lid opens automatically, is always

lower than the maximum top position which can be reached when the lid is

opened manually.

66

Operation

Malfunctions



Read and observe   and   on page 65 first.

Examples of operational malfunctions

Description of the malfunc-

tion

Remedy

The lid cannot be opened

Unlocking the lid

» page 290

The lid does not react to an

opening signal

Removing a possible obstacle (e.g. snow), re-

opening the lid

» page 66



Press handle

A



» Fig. 55

 on page 66 and pull

the lid upwards

The lid remains in the top

position

Manual closing of the lid

The lid is open and the bat-

tery was disconnected

Close manually

Close the door slowly, push down the lid, push in the lock on the centre of the

edge, above the ŠKODA logo.

Operating contactless boot lid

Fig. 56

Opening the boot lid



Read and observe   and   on page 65 first.

Depending on equipment the boot lid can be operated without contact.
The ignition must be switched off and you have to have the vehicle key on

your person.

›

To open/close, move one foot in the sensor area below the rear bumper

quickly in the direction of the arrow

» Fig. 56

.

The flap opens / closes automatically. When opening the fully closed flap, the

brake light in the rear window lights up. An acoustic signal is sounded when

closing the lid.
If the lid does not move, then repeat the operating process after a few sec-

onds.
The lid movement can be stopped by a rapid swinging of the foot. Swinging

the foot again will continue the lid movement.

The function can be activated/deactivated in Infotainment in the menu



/ 

→  → Opening and closing → “Easy Open”.
We recommend that the function is deactivated in the following cases:

▶

Installation of a roof rack.

▶

Connecting a trailer (accessory) to the towbar.

▶

Manual vehicle wash.

▶

Maintenance and repair work in the back of the vehicle.

When connecting a device to the trailer socket the deactivation of the func-

tion takes place.

Note

With heavy rain or a dirty rear bumper, under certain circumstances that there

may be limitations, or the automatic deactivation of the contactless opening

function of the boot lid may occur.

Window operation



Introduction

WARNING

■

Always close the window carefully and controlled. Doing so may may

cause yourself or fellow passengers considerable crushing injuries.

■

The system is fitted with a force limiter

» page 69

. If there is an obstacle

(e.g. In the event of a body part becoming trapped) the closing process is

stopped and the window goes down by several centimetres. However, the

windows should be closed carefully – risk of injury.



67

Unlocking and opening

CAUTION

■

Keep the windows clean to ensure the correct functionality of the electric

power windows.

■

Always close the windows before disconnecting the battery.

Note

If the windows are opened, dust and other dirt can get into the vehicle and the

wind noise is more at certain speeds.

Open / close Window

Fig. 57  Power window buttons

Fig. 58

Button of the window lifter on

the passenger side



Read and observe   and   on page 67 first.

All windows can be operated from the driver's seat. The window in the front

passenger door and the windows in the rear doors are operated via the button

in each door.

Power window buttons

» Fig. 57

Front door left
Front door right
Rear door, left
Rear door, right
Deactivate/activate the buttons in the rear doors (the deactivation may be

advantageous if, for example, children are transported on the rear seats)
Deactivation / activation of the key in the rear door left (part of the child

safety lock with electric operation)
Deactivation / activation of the key in the back door right (part of the child

safety lock with electric operation)

Open/close window

›

To open, lightly press the appropriate button down and hold it until the win-

dow has moved into the desired position.

›

or: Press the button to the stop; the window automatically opens fully. Re-

newed pressing of the button causes the window to stop.

›

To close, pull gently on the top edge of the corresponding button and hold

until the window has moved into the desired position.

›

or: Pull the button briefly to the stop, the window automatically closes fully.

Renewed pulling of the button causes the window to stop immediately.

Disable / enable buttons in the rear doors

›

To deactivate/activate the buttons in the rear doors, press the

E

 button. If

the buttons in the rear doors are deactivated, the warning light



 illuminates

in the

E

 button.

›

or: On vehicles with child safety lock with electric operation, press the re-

spective key

F

 or

G

. If the buttons in the rear doors are deactivated, the

warning light



illuminates in the respective button

F

 or

G

.

Note

■

After switching off the ignition, the windows can still open and close for

about 10 minutes.

■

After the driver or front passenger door is opened, the operation of the win-

dow is only possible with the button

A

» Fig. 57

, in which case this is pressed

or pulled for approx. 2 seconds.

A
B
C
D

E

F

G

68

Operation

Force limiter



Read and observe   and   on page 67 first.

The electrical power windows are fitted with a force limiter.
If there is an obstacle, the closing process is stopped and the window goes

down by several centimetres.
If the obstacle prevents the window from being closed during the next 10 sec-

onds, the closing process is interrupted once again and the window goes down

by several centimetres.
If you attempt to close the window again within 10 seconds of the window be-

ing moved down for the second time, even though the obstacle was not yet

been removed, the closing process is only stopped. During this time it is not

possible to automatically close the window. The force limiter is still switched

on.
The force limiter is only not operational if you attempt to close the window

again within the next 10 seconds – the window will now close with full force!
If you wait longer than 10 seconds, the force limiter is switched on again.

Window convenience operation



Read and observe   and   on page 67 first.

The convenience operation for the window offers the option to open/close all

the windows at once (or only the window in the driver's door). The conven-

ience operation function can be adjusted individually in Infotainment in the

menu



/  →  → Opening and closing.

Opening

›

Press and hold the  button on the key.

›

or: Switch off the ignition, open the driver's door and hold the key

A

 until it

stops in the open position

» Fig. 57

 on page 68.

Closing

›

Press and hold the  button on the key.

›

or: Switch off the ignition, open the driver's door and hold the key

A

 until it

stops in the closed position

» Fig. 57

 on page 68.

›

In the KESSY system, hold your finger on the sensor on the outside of the

door handle of the front door

» Fig. 49

 on page 60.

The convenience operation will only function correctly if all the windows auto-

matically open/close properly.
Convenience opening or closing the window using the key in the driver's door

locking cylinder is only possible within 45 seconds of locking the vehicle.
The movement of the window is stopped immediately when the respective

button is released.

Note

The settings for the window convenience operation are stored (depending on

the Infotainment type) in the active user account personalisation

» page 57

.

Malfunctions



Read and observe   and   on page 67 first.

Repeatedly opening and closing the window can cause the window mechanism

to overheat and become temporarily blocked. You will be able to operate the

window again as soon as the operating mechanisms has cooled down.
After disconnecting the vehicle battery, automatic opening / closing the win-

dow can be deactivated. In this case the system must be activated as follows.

Activate window operation

›

Switch on the ignition.

›

Pull the top edge of the button and close the window.

›

Release the button.

›

Pull up the respective button and hold for 1 second.

Panoramic tilting / sliding sunroof



Introduction

The panorama sliding/tilting roof (hereinafter referred to as sliding/tilting roof)

can only be operated when the ignition is turned on and when the outdoor

temperature is no lower than -20 °C.
The sliding/tilting roof can still be operated for approx. 10 minutes after

switching the ignition off. After opening the driver or front passenger door, it

is no longer possible to operate the sliding/tilting roof.



69

Unlocking and opening

WARNING

When operating the sliding/tilting roof and the sunshade, proceed with

caution to avoid causing crushing injuries – risk of injury!

CAUTION

■

During the winter, remove any ice and snow in the vicinity of the sliding/tilt-

ing roof before opening it to prevent any damage to the opening mechanism.

■

Always close the sliding/tilting roof before disconnecting the battery.

Operation

Fig. 59  Operation of the sliding/tilting roof



Read and observe   and   on page 70 first.

Operation of the sliding/tilting roof

» Fig. 59

Gradual opening
Complete opening
Gradually reset
Fully reset
Gradual opening
Fully opening

After the first press, the sliding/tilting roof stops in the position where the

intensity of the wind noise is low (at speeds of approx. less than 80 km/h).

Press again and the sliding/tilting roof goes to the stop.
Gradual closing
Complete closing

1

2
3
4
5
6

7
8

Force limiter



Read and observe   and   on page 70 first.

The sliding/tilting roof is fitted with a force limiter.
If there is an obstacle, the closing process is stopped and the glass pane re-

tracts by several centimetres.

WARNING

If the sliding/tilting roof is closed by holding down the switch

7

 /

8

,

» Fig. 59

 on page 70and the closing process is hindered by an obstacle, then

when attempting to close for a third time, the force limiter is rendered in-

operable (if the period of 5 s is not reached between the individual at-

tempts to close). The sliding/tilting roof closes with full force - it may cause

injury.

Convenience operation of the sliding / tilting roof



Read and observe   and   on page 70 first.

The convenience operation makes it possible to open or close the sliding/tilt-

ing roof using the key or the KESSY system via the sensor in the door handle

of the front door.

›

To open out, press and hold the button on the key.

›

To close, press and hold the button (with KESSY, hold your finger on the

sensor on the outside of the door handle of the front door).

By interrupting the locking process, the closing operation is interrupted.

70

Operation

Activate operation of the sliding/tilting roof

Fig. 60

Operation of the sliding/tilting

roof



Read and observe   and   on page 70 first.

If the operation of the sliding/tilting roof is deactivated (e.g. after disconnect-

ing and connecting the battery), then operation will have to be activated.

›

Switch on the ignition, pull the switch on the recess all the way down in the

direction of arrow

1



» Fig. 60

 and hold.

The sliding/tilting roof opens/closes again after around 10 seconds.

›

Release the lever.

Electrically operated sunshade

Fig. 61

Button for operating the sun-

shade



Read and observe   and   on page 70 first.

Operation of the sunblind

» Fig. 61

Open - by pressing (press again - sunshade stops moving)
Close - by pressing (press again - sunshade stops moving)





The sunshade can also be operated by pressing and holding the appropriate

button (starts movement of the sunshade) and releasing it when the sunshade

reaches the desired position.

Activating operation of the sunshade



Read and observe   and   on page 70 first.

If the operation of sunshade is deactivated (e.g. after disconnecting and con-

necting the battery), then the operation will have to be activated.

›

Switch on the ignition, press and hold the 

» Fig. 61

 on page 71 button.

The sunshade opens and closes again after around 10 seconds.

›

Release the button.

71

Unlocking and opening

Lights and visibility

Light



Introduction

Unless otherwise stated, the lights only work when the ignition is switched on.
For the basic position of the light switch, use position .

Note

The headlights may mist up temporarily. When the light is switched on, the

light-emitting surface demists after a short period of time.

Operating the lights

Fig. 62

Light switch

To switch on/off the lights, turn the

A



» Fig. 62

 switch to one of the following

positions (equipment-dependent).

Switching off lights (except daytime running lights)

Switching the light on/off automatically

» page 73

Switching on the parking lights or parking lights on both sides

» page 76

Switching on the low beam

Headlight range control of the Halogen headlights

The headlight range can be set in Infotainment in the menu



/  →  → Light.

The range of the halogen headlights can be set on the screen, in accordance

with the vehicle load, to the following basic settings.

Front seats occupied, boot empty
All seats occupied, boot empty













All seats occupied, boot loaded
Driver seat occupied, boot loaded

In the event of another vehicle loading condition, the setting for positions . . 

can be used.
The LEDFront headlights s automatically adjust to vehicle loading and driving

conditions, so they do not have manual headlight range control.

WARNING

Always adjust the headlight range control to comply with the following

conditions and prevent accidents.

■

The vehicle does not dazzle other road users, especially oncoming vehi-

cles.

■

The beam range is sufficient for safe driving.

Note

■

If, with a dipped beam, the ignition is turned off, then the dipped beam will

automatically switch off and the parking lights will come on. Does not apply to

the position , as long as the conditions are met for the COMING HOME

function . The parking lights are switched off when the ignition key is removed

(for vehicles with the KESSY system, after opening the driver's door).

■

If there is a fault in the light switch, the low beam comes on automatically.

Daytime running lights

The daytime running lights illuminate the area in front of and to the rear of the

vehicle (only applicable for some countries).
The lights are switched on automatically if the following conditions are

met.

The ignition is switched on.
The light switch is in the position  or .
or: the light switch is in the position , and visibility has not become

worse.

WARNING

Always switch on the low beam when visibility is poor.











72

Operation

Turn signal and main beam

Fig. 63

Operating lever: Turn signal and

main beam operation

Control stalk positions

» Fig. 63

Switch on the right turn signal
Switch on the left turn signal
Switch on main beam (spring-tensioned position)

Switch off main beam / headlight flasher on (spring-tensioned position)

The main beam can only be switched on when the low beam lights are on.
The headlight flasher can be used even if the ignition is switched off.
The turn signal switches off automatically depending on the steering angle af-

ter turning.
Use the control stalk to switch on/off the headlight assistant

» page 74

.

Comfort indicating

When the control talk is pressed slightly up or down, the respective turn signal

indicates three times.
If during the convenience turn signal, the operating lever is pressed in the op-

posite direction, the indicating will stop.
Convenience signalling can be activated/deactivated in Infotainment in the

menu



/  →  → Light/

WARNING

Only turn on the main beam or the headlight flasher if other road users will

not be dazzled.









Note

The setting (activation/deactivation) of the convenience turn signal is stored

(depending on the Infotainment type) in the active user account personalisa-

tion

» page 57

.

Automatic driving light control

Fig. 64

Light switch: Position 

If the light switch is in position 

» Fig. 64

, then the lights are automatically

switched on/off to suit current light or weather conditions (rain), depending on

the equipment.
If the light switch is in position , the lettering



 illuminates next to the

light switch. If the light is switched on automatically, the symbol



 also illumi-

nates next to the light switch.

Automatic driving light control in the rain (referred to as function in the

following)

The dipped beam is switched on automatically if the following conditions are

met.

The function is activated.
The light switch is in the position .
The windscreen wipers are on for more than 30 s.

The light turns off automatically about 4 minutes after turning off the wipers.

Setting, activation/deactivation

The following functions can be set or activated/deactivated in Infotainment in

the menu



/  →  → Light.

▶

Sensitivity adjustment of the sensor for determining the lighting conditions

for automatic driving light control

▶

Automatic driving light control during rain









73

Lights and visibility

WARNING

The automatic driving lamp control (position ) only operates as a sup-

port and does not release the driver from his responsibility to check the

lights and, if necessary, to switch on the light depending on the prevailing

light conditions.

CAUTION

Poorer visibility is detected by a sensor mounted below the windscreen in the

holder of the inside mirror or in the control panel. Do not cover the sensor -

the system can be affected.

Note

The setting (activate/deactivate) of the automatic driving light control during

rain is stored (depending on the Infotainment type) in the active user account

personalisation

» page 57

.

LED headlights

The LED headlights (hereinafter referred to as just system) use the journey da-

ta to automatically ensure the best possible light cone in front of the vehicle.
The system operates automatically in the following modes: urban, remote, mo-

torway and bad weather.
A component of the system is the static side light. This light is used in some

light modes, e.g. for bend illumination during reversing.
The system works as long as the light switch is in position .

WARNING

If there is a system malfunction the headlights are automatically lowered to

the emergency position, which prevents a possible dazzling of oncoming

traffic. This reduces the cone of light in front of the vehicle. Seek help from

a specialist garage.

Light Assist

Fig. 65  Installation location versions of the sensor / system on/off

The system automatically switches the high beam on/off in accordance with

the existing traffic (other vehicles) and environmental conditions (e.g. driving

through a lit village).
The high beam on/off is controlled by a sensor or a camera

» Fig. 65

.

The system can be activated/deactivated in Infotainment in the menu



/ 

→  → Light → Light Assist.
Conditions for the system function

The system is activated.
The light switch is in the position .
The vehicle speed is over 60 km/h or for some countries more than 40

km/h.
The windscreen is clean in the sensor area.

Switch on the system

›

Push the lever into the sprung position

A



» Fig. 65

. The following indicator

light  lights up in the instrument cluster display.

Switch off the system

›

If the high beam is switched on automatically, move the lever into the sprung

position

B

. The warning light  goes out. The high beam turns off.

›

If the high beam is is not switched on automatically, move the lever into the

sprung position

A

. The warning light  goes out. The high beam turns on.

The high beam switches off automatically when the speed falls below 30 km/h

(but the system remains switched on).











74

Operation

If there is a fault, the error message will appear in the instrument cluster dis-

play. Seek help from a specialist garage.

WARNING

The system is used only for support, thus the driver is not released from his

obligation to manually adjust the main or low beam according to the given

ambient conditions (e.g. in unfavourable lighting and weather conditions, as

when passing poorly lit road users, if necessary, when the area in front of

the sensor is covered by an obstacle).

CAUTION

Do not cover the sensor and keep the front screen clean - system functionality

can be impaired.

Note

The setting for the high-beam assistant in Infotainment is stored (depending

on the Infotainment type) in the active user account for personalisation

» page 57

.

Fog lights/rear fog light

Fig. 66

Light switch – switch on front

and rear fog lights

Switching on the fog lights/rear fog lights is possible under the following

conditions.

The lights switch is in position ,  or 

» Fig. 66

.

›

To switch on the fog lights, turn the light switch to position

1

; the warning

light



 illuminates in the instrument cluster.

›

To switch on the rear fog lights, pull the light switch to position

2

; the

warning light



 illuminates in the instrument cluster.

If the vehicle is not equipped with fog lights, the rear fog lights can be switch-

ed on by pulling the light switch to the only possible setting.



Switch off the fog lights/rear fog lights in reverse order.

Note

If an accessory is connected to the trailer socket, the rear fog lamp does not

light up on the vehicle.

function CORNER

The CORNER function automatically switches on the fog lights on the respec-

tive side of the vehicle (e.g. when cornering or steering), if the following condi-

tions are fulfilled.

The turn signal is turned on or the front wheels are severely locked (in the

event of conflict between the two versions, has turn signal has the higher

priority).
The vehicle speed is below 40 km/h.
The low beam is switched on.
The fog lights are not switched on.

The two fog lights are switched on when you shift into the reverse gear.

COMING HOME / LEAVING HOME

The function COMING HOME ensures that the vehicle's environment is illumi-

nated after switching off the ignition and opening the driver's door.
The function LEAVING HOME ensures that the vehicle's environment is illumi-

nated after unlocking the vehicle with the radio remote control unit.
The function switches the light on only if there is poorer visibility and the light

switch is in the position .

The two functions can be used in Infotainment in the menu



/  →  → Light

(activated/deactivated and adjusted).

CAUTION

■

Poorer visibility is evaluated by a sensor mounted below the windscreen in

the holder of the rear-view mirror. Do not cover the sensor - the system can

be affected.

■

If this option is always enabled, then the battery is heavily loaded.

Note

The setting of the two functions is stored (depending on the Infotainment

type) in the active user account personalisation

» page 57

.









75

Lights and visibility

Hazard warning light system

Fig. 67

Button for hazard warning light

system

›

To switch on/off, press the



 button

» Fig. 67

.

When switching on, all the turn signal lights as well as the warning light



 in

the button flash simultaneously with the control lights







 in the instrument

cluster.

The hazard warning light system can also be operated if the ignition is switch-

ed off.
If one of the airbags is deployed, the hazard warning light system will switch

on automatically.
The automatic activation of hazard warning lights can take place during a

heavy braking. After starting or accelerating the hazard warning system is au-

tomatically switched off.
When the hazard warning system is on and the turn signal is switched on, the

hazard warning lights are switched off temporarily and only the turn signal

flashes on the relevant side of the vehicle.

Parking light

The side light is provided for lighting of the parked vehicle.

Switching on the side light  on one side

›

Switch off the ignition.

›

Press the control lever all the way into position or until it stops

» Fig. 63

on page 73.

The parking lights on the respective side of the vehicle are turned on.

Switching on the side light on both sides 

›

Turn the ignition on and turn the light switch to position 

» page 72

.

›

Switch off the ignition and lock the car.

After removing the ignition key and opening the driver's door, an audible warn-

ing sounds. After a few seconds, or after closing the driver's door, the acoustic

warning signal stops.

CAUTION

■

Turning on the parking light means the battery is heavily loaded.

■

The parking lights may switch off automatically due to a low battery charge.

If the two-sided parking lights are switched on when the ignition is off, the

parking lights will not switch on automatically.

Entry space lighting

The lighting is positioned on the lower edge of the exterior mirror and illumi-

nates the entry area of the front door.
The lighting switches on after unlocking or opening the vehicle door (depend-

ing on the lighting conditions).
The lighting switches off after around 30 seconds after closing the front door

or switching on the ignition.

Driving abroad

When driving in countries with opposing traffic system (traffic on the

left/right), headlights may dazzle oncoming traffic.
Therefore, the LEDFront headlight setting must be adapted by turning on trav-

el mode in infotainment in the



/  →  → Light menu. In this mode, no auto-

matic beam adjustment is made ahead of the vehicle.

Interior lighting



Introduction

The inner lighting also works if the ignition is switched off. With the ignition

off (or after a door is opened),the lights will automatically switch off after ap-

proximately 10 minutes.

76

Operation
