Beamsetter

SEG-IV DLLX

Digital lux meter, broadband visor, Fresnel lens, laser positioning aid, spirit level/eccentric shaft for levelling,

rotatable column for the optical case alignment, suitable for rails, compatible with CSC tool, can be calibrated

using manufacturer's alignment unit
Scope of supply

Roller base of polymer concrete

Order no

9007 732 311

Beamsetter

SEG V

Digital lux meter, broadband viewfi nder, Fresnel lens, level/eccentric axis for tilt adjustment, rotating column

for lens box alignment, suitable for runners, 8.4" touch display, vehicle identifi cation with car history, USB

port, WLAN preparation, update-capable, compatible with CSC tool, rolling foot of polymer concrete, can be

calibrated with manufacturer's adjustment device
Scope of supply

incl. rolling feet

Order no

9007 732 312

Workshop equipment

| 307

Tec

hnical eq

uipment and accessor

ies

Workshop-pit lifters

hydropneumatic

Rapid and precise air hydraulics with fast up and down travel, with operating panel at the ergonomically correct working height, maintenance unit as standard, laterally

moveable lift cylinder with spring-mounted ball bearings
Piston stroke 800 mm

Height, max.

1820 mm

Height, min.

1020 mm

Cylinder-∅

60 mm

Scope of supply

With suspension
Many modern vehicles must today be raised at 2 points. Check the use of axle traverses!

Model

Load capacity

Order no

GD 100-1

10 t

5322 520 135

GD 150-1

15 t

5322 520 136

GD 200-1

20 t

5322 520 137

When ordering, please complete the dimensions sheet!

Workshop equipment

308 |

Tec

hnical eq

uipment and accessor

ies

2-pillar lift

TPL9000

Stationary, electro-hydraulic, 4 telescopic articulated arms, variable entry width (standard 2500 mm), lifting columns without cross-connections at top and bottom, space-

saving articulated arm arrangement, compact pushing together of arms, telescopic arm on roller bearings for easy sliding, insensitive and almost maintenance-free

hydraulic drive, sturdy construction, minimal bending and twisting, double load protection (hydraulic and mechanical), mechanical locking at every lifting height

– HydroLock: hydraulic, infi nitely variable articulated arm locking

– RadiusPlus: swivelling articulated arm extensions with low support height (optional)

– SoftStart: for load-protecting positioning of the load

– SoftControl: exact and infi nitely variable synchronisation control

– VarioSpeed: variable driving speeds, fast/slow

– Tube: wear-free tube guide for the lifting carriage
Load capacity

9 t

Stroke

1900 mm

Lifting height

2050 mm

Height

2500 mm

Height, max.

4400 mm

Lift time

60 sec

Lowering time

60 sec

Motor power

2.2 kW

Connection voltage 400 V

Fuse protection

16 A

Protection class

IP54

Colour

orange

Surface

powder-coated

Weight

1800 kg

Support plate diameter 120 mm

Engine output/column 2.2 kW

Support arm length at front and back 485-1530 mm

Longitudinal spacing of the supports, max. 4460 mm

Permissible load capacity in accordance with CE1493, for uneven load distribution front:rear = 1:3/3:1

Floor quality C25, 180 mm minimum
Application range

Light trucks, vans, cars, camper vans, trailers

Order no

9539 500 600

Workshop equipment

| 309

Tec

hnical eq

uipment and accessor

ies

Mobile Column Lifts

HydroLift S2

Fully hydraulic, with double load security, battery driven, wireless communication with the individual lifting units based on IEEE 802.15.4, the "Up" "Down" and

"Emergency/Off" can be selected from each lifting column, built-in synchronisation control, easy to operate using pictograms, with FS profi le to protect the wheel hub,

HYDRO Protect System to protect the raising cylinder and a VARIO fork to accept different tyre sizes without the need for additional wheel adapters, can be enlarged

from 4 to up to 8 pillars
Version

with 3 kW elect. motor

Lift time

78 sec

Lowering time 54 sec
Scope of supply

With removable forklift adapters

Load capacity

Weight

Width

Height

Lifting height

Order no

4 x 6,2 t

600 per column kg

1092 mm

2260 mm

1759 mm

9534 004 290

4 x 8,2 t

720 per column kg

1156 mm

2590 mm

1753 mm

9534 004 292

6 x 6,2 t

600 per column kg

1092 mm

2260 mm

1759 mm

9534 004 291

6 x 8,2 t

720 per column kg

1156 mm

2590 mm

1753 mm

9534 004 293

Workshop equipment

310 |

Tec

hnical eq

uipment and accessor

ies

Jack

air-hydraulic

EUROPART own-brand car jacks are manufactured from special materials which guarantee their function, quality and breaking strength, even in the most extreme

situations.
Pressure range 8-10 bar
Scope of supply

2 adapters, 60 mm

Model

Load capacity

Lifting height

Weight

Fig.

Order no

EP 214 mobil

20/10 t

140-306 mm

15 kg

9539 650 200

EP 215 N

40/20 t

150-300 mm

39 kg

9539 650 201

EP 222 N

60/30 t

220-450 mm

71 kg

9539 650 202

EP 312

60/30/15 t

120-255 mm

50 kg

9539 650 203

EP 330 N

80/50/25 t

310-824 mm

103 kg

9539 650 204

* portable

Description

Fig.

Order no

Saddle, load capacity 80 t

9539 650 205

V fi fth wheel, load capacity 80 t

9539 650 206

Accessories

Workshop equipment

| 311

Tec

hnical eq

uipment and accessor

ies

Description

Suitable for

Fig.

Order no

Retrofi t set pneumatic wheels

trolley Jack EP 40Q, EP50HLQ, EP 60Q, EP 100Q

9539 360 550

Extension 100 mm

mobile jack EP 20, EP 20Q, EP 13HLQ, EP 20HLQ

9539 360 551

Extension 125 mm

mobile jack EP 40Q, EP 60Q, EP 100Q, EP 120Q, EP 50HLQ

9539 360 552

Axle traverse load capacity 1 t

mobile jack EP 20, EP 20Q, EP 13HLQ, EP 20HLQ

9539 360 553

Rubber coating

trolley Jack EP 20, EP 20Q, EP 13HLQ, EP 20HLQ

5322 520 152

Accessories

Trolley Jack

hydraulic

Sturdy frame structure with reinforcements for heavy-duty tasks, safe and precise control during lifting and lowering, double movement during lowering (fi rst pulling then

turning) provides extra safety against unintentional lowering, directly controlled trigger, compact design, ergonomically shaped handle

Model

Load capacity

Lifting height

Version

Weight

Fig.

Order no

EP 13HLQ

1,3 t

80-735 mm

long stroke, quick-lift foot pedal

39 kg

9539 111 005

EP 20

2 t

80-495 mm

31 kg

9539 111 000

EP 20Q

2 t

80-495 mm

quick lift foot pedal

31 kg

9539 111 001

EP 20HLQ

2 t

80-795 mm

long stroke, quick-lift foot pedal

49 kg

9539 111 006

EP 40Q

4 t

140-600 mm

quick lift foot pedal

95 kg

9539 111 002

EP 50HLQ

5 t

150-975 mm

long stroke, quick-lift foot pedal

170 kg

9539 111 007

EP 60Q

6 t

140-600 mm

quick lift foot pedal

96 kg

9539 111 003

EP 100Q

10 t

150-585 mm

quick lift foot pedal

118 kg

9539 111 004

Workshop equipment

312 |

Tec

hnical eq

uipment and accessor

ies

Battery tester

with integrated thermal printer

The optional use of a clip-on ammeter is supported by the tester and also improves the test results, voltage

measurement and temperature measurement functions, integrated thermal printer presents all measurements

clearly in text and graphically in the chosen menu language, customer-specifi c data can be entered separately,

USB port for downloading test results to a PC and for future updates, 6 menu languages
Standard

JIS, EN, DIN, SAE, IEC

CCA

25-3000 CC A

Operating temperature 0-40 °C

Width

130 mm

Height

65 mm

Depth

265 mm

Application range

EFB (Enhanced Flooded Battery), AGM (Absorbent Glass Mat), 6/12 V starter batteries (lead/acid, gel and

fl eece batteries/AGM), starting/charging system tests for 12/24 V equipment

Order no

9682 202 404

Description

Order no

Printer paper roll, 5 rolls

9682 202 403

Accessories

Battery charger

MXT 14

CTEK charger, electronic, SUPPLY – special mode in which the device can be used as a power supply unit if the

battery is removed (radio code), Regeneration mode – special mode in which exhaustively discharged batteries

can be regenerated and returned to full capacity, with 8-stage, fully-automatic IIUoUp charging characteristics

without voltage peaks

MAN approval issued.
Voltage

220-240 V AC

Charge voltage

27.2 V, 28.8 V, 31.6 V, nominal 24 V

Charge current, max. 14 A

Protection class

IP44

Cable length

1,85 m

Length

235 mm

Width

130 mm

Height

65 mm

Weight

1.9 kg

Battery capacity: 28-300 Ah (charge), 28-500 Ah (maintain)

Battery types: open, maintenance-free AGM, gel and lead-calcium

Reverse current: < 1 mA

Charging time for a 60 Ah battery: 4 hrs at 14 A

Order no

9539 640 145

Workshop equipment

| 313

Tec

hnical eq

uipment and accessor

ies

Start booster

ASF 12-24/3200

Professional external starting unit, maximum starting power through extremely deep-cycle resistant AGM battery (replaceable), voltage peak free starting, lifetime for

max. 50% start discharge: 1000 cycles, manual voltage selection, correct use protects the electronic components of the vehicle, integrated voltmeter which displays the

charging status of the batteries and the correct functioning of the charging equipment and alternator, built-in socket, high-quality, internally bridged crocodile clips with

a very wide opening angle, impact-resistant one-piece housing with lifetime guarantee, charging through electronic battery charger with pulse charging preservation or

using a cable (to be ordered separately) through the alternator at the vehicle's cigarette lighter.
Voltage

12/24 V

Cable cross-section 70 mm²

Cable length

1,95 m

Weight

38 kg

Starting current: 12 V at 3200 A, 24 V at 1600 A

Peak current: 12 V at 7750 A, 24 V at 3875 A
Scope of supply

IUU charger

Order no

9539 640 168

Brake maintenance unit

VARIO 5 II, DOT version

Portable and space-saving, pulsing fl uid fl ow, leak test of the brake system in the low pressure range, electronic

fi nal shut-down, self-bleeding
Suitable for

Brake fl uid container 5 l

Operating liquid

DOT

Pressure range

0-3,5 bar

Width x height x depth 320 x 430 x 340 mm

Weight

10 kg

Application range

Ideal for smaller workshops, for all ABS systems (including EDS, ESP systems) and hydraulic clutches
Scope of supply

Standard adapter no. 20 for European vehicles, without fl uid container

Order no

9539 500 035

Workshop equipment

314 |

Tec

hnical eq

uipment and accessor

ies

Filling and bleeding station

Vario 5-20 MO II, mineral oil version

One-main operation, intelligent technology with automatic control mechanisms, suitable for hydraulic clutches

and gearshift control, stepless adjustment of pressure control range, with electronic deactivation
Pressure range

0-3,5 bar

Temperature range

0 to +45 °C

Length of fi lling hose

3,5 m

Length of mains cable 5 m

Order no

9539 500 045

Illustration also shows optional accessories

Workshop equipment

Tyre infl ation gauge

RF 80 G

Ergonomic composite housing: cold-insulating, slip-resistance and low-vibration for comfortable work, simple

operation with precision pressure gauge, over-pressure protected, handle with non-slip soft-grip surface,

offi cially calibrated (including calibration fee) for use in commercial businesses, with torque connector, large

pressure gauge diameter 80 mm for easy legibility, pressure gauge with rubber coating as protection against

mechanical infl uences.
Working pressure 0,5-10 bar

Hose length

1000 mm

Order no

9506 022 350

| 315

Tec

hnical eq

uipment and accessor

ies

Workshop equipment

Tyre mounting machine

ATH 7226

Clamping device with 4 clamping arms, hydraulic lifting arm and lateral fi tting carriage, the fi tting arm can be manually moved on the carriage and can also be turned and

folded out, electric drive for the rotational movement of the clamping arms, one fi tting speed
Version

Electrohydraulic

Clamping range

14-26"

Motor power

1,5 kW

Operating pressure 150-170 bar

Wheel ∅, max.

1500 mm

Voltage

400 V

Weight

700 kg

3 phase ~ 400 V/50 Hz
Application range

Light truck and truck tyres with a maximum rim diameter of 26"
Scope of supply

1 x bead clamp for steel rims

1 x mounting lever

1 x grease gun

1 x grease cartridge

Order no

9539 000 650

316 |

Tec

hnical eq

uipment and accessor

ies

Workshop equipment

Wheel balancing machine

W102

Manual wheel balancer, 5 balancing programs (car or truck mode), mobile version for use directly at the vehicle or near a tyre changer, no additional lever required for

tyres, as the entire balancing unit can simply be raised with the clamped-on wheel, equipped with manual hand brake, compact dimensions
Rim dia.

12-24"

Wheel width

4-15"

Wheel weight, max. 200 kg

Wheel ∅, max.

1200 mm

Balancing accuracy 10 g

Shaft dia.

40 mm

Voltage

230 V

Application range

Truck, bus, van and car tyres
Scope of supply

Cone set, quick-release nut, weight pliers, 100 g weight for car calibration, 200 g weight for truck calibration, rim width gauge (trucks),

electrical connection via 230 V, 50 Hz

Order no

9539 000 102

LED work lamp

VEGA 4000

Diffused anti-glare and comfortable working light, uniform light intensity, wide light scattering, adjustable foot

made of powder-coated steel allows direct mounting on a stand, LED diodes produce no heat and therefore no

fi re hazard, sturdy impact-resistant plastic casing
Voltage

230 AC V

Power

48 W

Lighting power

4000 lm

Cable length

5 m

Protection class IP54
Scope of supply

2 x Euro-style grounded mains sockets

Order no

9539 640 487

| 317

Tec

hnical eq

uipment and accessor

ies

Assembly creeper

Sturdy construction, ergonomically shaped, storage trays on both sides for small

parts, 6 oil-resistant and smooth-running 3" rollers, soft padded head support
Load, max.

130 kg

Length x width x height 990 x 470 x 110 mm

Order no

9539 111 050

Workshop equipment

LED inspection lamp

MAG

LED rechargeable working lamp and flash light in a high-power, two times stronger light output, ergonomic and

user-friendly grip, with three built-in and powerful magnetic holders, two retractable suspension hooks, lamp

head can be turned to 180°, strong spot and main light, with USB charging
Charging time

4 h

Rechargeable battery Li-Ion (3,7 V/1200 mAh)

Lighting power

120/50 lm

Lighting duration

4/4 h

Protection class

IP20

Order no

9539 640 482

LED head lamp

COB LED I-VIEW

Light, ergonomic headlamp with sensor system for contactless on/off switching, illuminates the entire working area, 2 lighting levels (level 1: 50 %, level 2: 100 %),

easy to operate – even with thick gloves, Lithium-polymer battery (3.8 V/1600 mAh), water and dust proof, black woven headband
Power

2 W

Lighting power

80/160 lm

Lighting duration

6/3 h

Charging time

4 h

Working temperature -10 to +40 °C

Protection class

IP65

Order no

9539 640 419

318 |

Tec

hnical eq

uipment and accessor

ies

Rim brush

Application range

Rim and paint cleaning in tight spaces
Scope of supply

With inclined, soft bristles and ergonomic handle

Order no

9500 705 252

Hand washing brush

with long handle

with red/green polyester bristles

Order no

9014 000 030

Rim brush

Application range

For removing stubborn dirt from aluminium rims

Order no

9014 000 130

Rim brush

Application range

For removing stubborn dirt from aluminium rims

Order no

9507 910 000

Workshop equipment

| 319

Tec

hnical eq

uipment and accessor

ies

Working pressure

30-200 bar

Rate of delivery

500-1000 l/h

Connection voltage 400 V

Hose length

10 m

Length

1330 mm

Width

750 mm

Height

1060 mm

Consumption under full load: 6.4 kg heating oil/h

Order no

9301 086 902

Hot water high-pressure cleaner

HDS 10/20-4 M

Durable, water-cooler 4-pole electric motor, for continuous use, commercial eco-efficiency level, two cleaning

agent tanks, easy-press gun with soft grip insert and stepless pressure and water quantity control (servo

control), stainless steel tube, KÄRCHER power nozzle

Cold water high-pressure cleaner

HD 10/23-4 SX Plus

EASY!Force high-pressure spray gun and EASY!Lock quick-release connections, 4-pin, water-cooled electric

motor, hose storage on both sides, integrated electronics for device monitoring, shut-down in the event of

overvoltage or undervoltage, shut-down in the event of leak or phase failure, large rubber wheels for rough

terrain, stairs or steps, proven handcart principle for simple, ergonomic transport
Working pressure 230 bar

Pressure, max.

253 bar

Rate of delivery

1000 l/h

Connected rating

7,8 kW

Length

560 mm

Width

500 mm

Height

1090 mm

Power supply: 3 phase 400 V 50 Hz

Order no

9562 102 340

Workshop equipment

320 |

Tec

hnical eq

uipment and accessor

ies

Abrasive/suction machine

B 40 C Bp Fleet + 70Ah + R45 + AutoFill

With roller brushes, auto-fill function, Kärcher Fleet, KIK key system and maintenance-free battery
Voltage

24 V

Capacity

70 Ah

Area output, max. 1800 (MKH)

Length

1249 mm

Width

520 mm

Height

1145 mm

Brushes working width 450 mm

Suction working width 850 mm

Power input 1100 W

Fresh/dirty water tank 40/40 l

Brush pressure 160 g/cm²

Brush speed 1200 rpm
Scope of supply

KIK key (yellow and grey)

Order no

9503 002 570

Sweeper/vacuum machine

KM 75/40 W G

Hand-guided, with reliable, powerful Honda 4-stroke petrol engine, high user-friendliness due to EASY operation

concept and mobile sweepings container with trolley handle, efficient filter system with mechanical filter

cleaning, tool-free change of filter and sweeping cylinder for flexible location-independent maintenance,

high degree of manoeuvrability due to compact dimensions and traction drive
Area output, max. 3375 (MKH)

Working width

550 mm

Filter area

1,8 m²

Driving power

3,3 kW

Length

1430 mm

Width

780 mm

Height

1180 mm

Working width with 1 side brush 750 mm

Sweepings container 40 l

Climbing power 15 %

Working speed 4,5 km/h
Application range

Ideal for thorough and dust-free cleaning of outdoor surfaces from 600 m²

Order no

9501 049 205

Workshop equipment

| 321

Tec

hnical eq

uipment and accessor

ies

Wet/dry vacuum cleaner

ASA 32 L

With commercial approval, automatic switch-off (when sucking up liquids, the suction current is interrupted

as soon as the maximum fill level of the container is reached), special air cooling system for long motor life,

built-in socket with automatic switch-on, sturdy and washable folded filter, easy and fast filter changing, cable

rewinding, practical accessory storage and tray
Air quantity

3600 l/min

Filter area

3.600 cm²

Container volume 32 l

Power, max.

1.200 W

Hose length

3,2 m

Hose-∅

35 mm

Vacuum

200 mbar

Application range

For vacuuming away dust and swarf on electric tools and for cleaning site, workshop, vehicle and much more,

certified for the vacuuming up of dusts in dust class L (AGW value > 1 mg/m³), also suitable for vacuuming up

non-flammable liquids
Scope of supply

Vacuum hose (∅ 35 mm / 3.2 m), 2 vacuum pipes, folded filter made of cellulose, crevice nozzle, pipe holder,

floor nozzle (260 mm wide), suction nozzle (120 mm wide)

Order no

9500 002 013

Wet/dry vacuum cleaner

NT 40/1 Tact Te L

With Tact filter cleaning system as well as 40 l container with bumper for long, uninterrupted work, suction hose

connection in device head, case storage and fixing possibilities, moisture-resistant PES flat-fold filter, integrated

device socket
Air quantity

74 l/s

Power

1380 W

Sound pressure level 68 dB(A)

Container volume

40 l

Voltage

220-240 V

Length

560 mm

Width

370 mm

Height

655 mm

Scope of supply

– Suction hose, 4 m

– Suction pipe, stainless steel 2 x 0.55 m

– Filter bag, fleece

– Wet/dry floor nozzle, 360 mm

– Tile nozzle

– Flat-fold filter, PES

Order no

9562 114 831

Workshop equipment

Scania Truck (2017 year). Spare parts and accessories - 20
