Scania Truck (2017 year). Spare parts and accessories

290 |

Tec

hnical eq

uipment and accessor

ies

Socket wrench set

With forged, heat-treated sockets, manually operated hexagon socket inserts, with actuation tools made of

vanadium-steel 31CrV3
Drive form Hexagon

Drive

3/4"

Scope of supply

Sizes 22/24/27/30/32/36/38/41/46/50/55/60, fi nely toothed reversible ratchet, in blue sheet steel case

Version

Order no

16-piece

9240 071 699

Steel tape pliers

For assembly of spring hose clamps up to 70 mm nominal size, can be used for standard, space-saving and

wire clamps as well as spring rings, maximum opening up to 80 mm – more than 40 mm clamping distance,

open by push of a button, fi ne-adjustment for optimal adaptation to different clamp sizes, rotatable, universal

gripper inserts for secure hold in any position, slender head, low head width, rotatable gripper inserts, ideal tool

in cramped spaces, power-saving due to extremely good translation ratio, box-joint: high stability due to double

guide, clamp protection prevents crushing injuries
Length

250 mm

Version

Forged, oil hardened

Material Chrome vanadium electric steel

Order no

9533 551 251

Hose clip pliers

Rotatable grip inserts for safe manipulation of clamps in any position, good leverage: clamps can be safely

and easily opened and closed again without applying any great force, hoses gently released using the serrated

gripping jaw, narrow head, minimal head width
Length

250 mm

Version

Forged, oil hardened

Material Chrome vanadium electric steel
Application range

For opening and closing Click clamps, for convenient working, for instance on fuel lines, vacuum lines and

intakes

Order no

9533 551 252

Tools

| 291

Tec

hnical eq

uipment and accessor

ies

Pliers wrench

Replaces a set of wrenches (metric and imperial), smooth jaws for gentle fi tting of surface-coated fi ttings – work

directly on chrome is possible, adjustable screwdriver, also ideally suited to gripped, holding, pressing and

bending workpieces, no edge damage on sensitive fi ttings due to zero-play, full-surface contact, push-button

adjustment directly on the workpiece, infi nitely variable gripping of all spanner widths up to specifi ed capacity by

means of parallel guided jaws, safe engagement of the hinge bolt: no accidental adjustment, stroke between the

gripper jaws enables rapid tightening and loosening of screw connections based on the ratchet principle, high

clamping force due to 10x hand force reinforcement, forged, oil-hardened, plastic-coated handles

Version

14 adjustment positions

Material Chrome vanadium electric steel

Surface

Chrome-plated

Version

Spanner size

Length

Order no

14 adjustment positions

150 mm

9533 008 603

13 adjustment positions, extremely narrow gripper jaws

1 3/8"

180 mm

9534 810 689

17 adjustment positions

1 3/4"

250 mm

2300 064 178

22 adjustment positions

2 3/8"

300 mm

9538 603 300

Robust cutting edges, inductively hardened, forged stop with comfortable damper, good accessibility thanks to

very fl at head and joint area, arm ergonomically angled for fatigue-free work, robust and very non-slip, two-tone

multi-component handle sleeves, accurate adjustment (12x) and readjustment through eccentric bolts, high

cutting performance with low force requirement due to optimal coordination of cutting angle and translation

ratio, bolted blade head, replaceable, blade: Chrome vanadium high-performance steel, forged, oil hardened,

joint: Special tool steel, forged, shaft: Steel pipe, powder-coated, grey atramentised head, handles with multi-

component sleeves
Length

910 mm

Blade hardness 62 (HRC)
Cutting performance HRC 19: 13 mm, HRC 40: 10 mm, HRC 48: 9 mm

Order no

9507 172 910

Bolt cutter

Tools

292 |

Tec

hnical eq

uipment and accessor

ies

Type

Version

Standard

Form

Suitable for

Fig.

Order no

straight, with opening spring

DIN/ISO 5254

dia. 10-25 mm

9534 810 926

straight, with opening spring

DIN/ISO 5254

dia. 19-60 mm

9534 810 918

straight, with opening spring

DIN/ISO 5254

dia. 40-100 mm

9534 810 923

A21

90° bent, with opening spring

DIN/ISO 5254

dia. 19-60 mm

9534 810 920

A31

90° bent, with opening spring

DIN/ISO 5254

dia. 40-100 mm

9534 810 927

straight

DIN/ISO 5256

dia. 12-25 mm

9534 810 928

straight

DIN/ISO 5256

dia. 19-60 mm

9534 810 922

straight

DIN/ISO 5256

dia. 40-100 mm

9534 810 925

J11

90° bent

DIN/ISO 5256

dia. 12-25 mm

9534 810 924

J21

90° bent

DIN/ISO 5256

dia. 19-60 mm

9534 810 917

J31

90° bent

DIN/ISO 5256

dia. 40-100 mm

9534 810 916

for assembly of outer circlips (DIN 471 and DIN 983) on shafts in the range from dia. 3-140 mm

² for assembly of inner circlips (DIN 472 and DIN 984) on shafts in the range from dia. 8-140 mm

Circlip pliers

Surface blackened, ground front

Tools

Circlip pliers set

for inner and outer rings

Roll-up case made of durable polyester fabric
Suitable for dia. 19-60 mm
Application range

For assembly of circlips for shafts and bores of dia. 19-60 mm
Scope of supply

1 circlip pliers DIN/ISO 5254, A2 straight, design A (for outer circlips)

1 circlip pliers DIN/ISO 5254, A21 90° bent, design B (for outer circlips)

1 circlip pliers DIN/ISO 5256, J2 straight, design C (for inner circlips)

1 circlip pliers DIN/ISO 5256, J21 90° bent, design D (for inner circlips)

Version

Order no

4-piece

9534 810 921

| 293

Tec

hnical eq

uipment and accessor

ies

Universal pliers

with bevel and cutter

Long, precise cutter, non-slip ribbing for flat and toothed burner hole for round material, with bevel for improved

accessibility
Overall length 180 mm

Standard

DIN/ISO 5746

Surface

fine-polished, matt chrome-plated

Cutting values for medium-hard wire up to dia. 2.8 mm, hard wire up to dia. 2.5 mm
Application range

For soft and hard wire (H)

Order no

9534 810 909

Radio/telephone nippers

Round-head, fine ribbed jaws with cutter
Overall length

200 mm

Blade hardness 60 (HRC)

Standard

DIN/ISO 5745

Surface

fine-polished, matt chrome-plated

Cutting values for medium-hard wire up to dia. 2.8 mm, hard wire up to dia. 1.8 mm
Application range

For precision work and wire cutting

Form

Fig.

Order no

straight

9534 810 912

bent, 40°

9534 810 913

Side cutting nipper

Precise cutting for versatile use, Swedish design
Overall length 160 mm

Standard

DIN/ISO 5749

Surface

fine-polished, matt chrome-plated

Cutting value for medium-hard wire up to dia. 3.0 mm, hard wire up to dia. 2.3 mm, piano wire up to dia. 1.6 mm
Application range

For soft and hard wire (H)

Order no

9534 810 903

Tools

294 |

Tec

hnical eq

uipment and accessor

ies

Water pump pliers

Robust design, permanently reliable thanks to box joint design, self-locking on pipes and nuts for secure and

power-saving work
Standard DIN/ISO 8976

Material

Chrome-vanadium steel

Surface

polished

Overall length

Clamping width

Version

Fig.

Order no

240 mm

10-36 mm

9534 810 901

250 mm

6-38 mm

pushbutton mechanism

9534 810 902

Power side nipper

Power hinge and precise cutting for toughest, continuous workload
Standard DIN/ISO 5749

Surface

fine-polished, matt chrome-plated

Cutting value for medium-hard wire up to dia. 4.2 mm, hard wire up to dia. 3.0 mm, piano wire dia. 2.5 mm
Application range

For soft and piano wire (P)

Overall length

Order no

180 mm

9534 810 906

200 mm

9534 810 907

Power universal pliers

AnglePlus

Ribbed jaws with long cutter and non-slip 4-point burner hole, rounded back for easier access and for levering,

40% easier cutting
Overall length 190 mm

Standard

DIN/ISO 5743

Surface

fine-polished, matt chrome-plated

Cutting value for medium-hard wire up to dia. 3.5 mm, hard wire up to dia. 2.5 mm, piano wire up to dia. 2.0 mm

Order no

9534 810 930

Pliers set

Surface fine-polished, matt chrome-plated
Scope of supply

1 universal pliers, length 180 mm

1 side cutter, length 160 mm

1 water pump pliers, length 240 mm

Version

Order no

3-piece

9534 810 929

Tools

| 295

Tec

hnical eq

uipment and accessor

ies

VDE radio/telephone nippers

Round-head, fine ribbed jaws with cutter
Version

VDE-insulated up to 1000 V

Overall length

200 mm

Blade hardness 60 (HRC)

Standard

DIN/ISO 5745

Surface

high gloss polished, chrome-plated

Cutting values for medium-hard wire up to dia. 2.8 mm, hard wire up to dia. 1.8 mm
Application range

for precision work and wire cutting

Form

Fig.

Order no

Straight

9534 810 914

Bent, 40°

9534 810 915

VDE side cutting nipper

Precise cutting for versatile use, Swedish design
Overall length 160 mm

Standard

DIN/ISO 5749

Surface

high gloss polished, chrome-plated

Cutting value for medium-hard wire up to dia. 3.0 mm, hard wire up to dia. 2.3 mm, piano wire up to dia. 1.6 mm
Application range

For soft and hard wire (H)

Order no

9534 810 904

VDE power side nipper

Power hinge and precise cutting for toughest, continuous workload
Overall length 200 mm

Standard

DIN/ISO 5749

Surface

high gloss polished, chrome-plated

Cutting value for medium-hard wire up to dia. 4.2 mm, hard wire up to dia. 3.0 mm, piano wire up to dia. 2.5 mm
Application range

For soft and piano wire (P)

Order no

9534 810 908

VDE stripping side cutting nippe

Multifunctional tool for electrical installation, precision cutter with recesses for stripping wires 1.5 and 2.5 mm²

and for cutting soft copper to hard steel wires
Overall length 160 mm

Standard

DIN/ISO 5743

Surface

high gloss polished, chrome-plated

Order no

9534 810 905

Tools

296 |

Tec

hnical eq

uipment and accessor

ies

VDE power universal pliers

with long cutter

Extra-long, precise cutter, non-slip ribbing for fl at and toothed burner hole for round material, power hinge with

up to 40% power saving
Overall length 200 mm

Standard

DIN/ISO 5746

Surface

high gloss polished, chrome-plated

Cutting value for medium-hard wire up to dia. 3.8 mm, hard wire up to dia. 2.7 mm, piano wire up to dia. 2.3 mm
Application range

For soft and piano wire (P)

Order no

9534 810 911

Crimping tool

MultiCrimp

Only one tool for the most common crimping applications, quick and easy changing of the crimping dies without any additional tools, safe and protected storage of the

replaceable dies in a round magazine, convenient, powerful crimping pliers in professional quality, reliable crimping results as for fi xed crimping dies, constant high

quality through precision dies and locking device (unlockable)
Version

oil hardened

Overall length 250 mm

Material

Chrome-Vanadium electro-steel in special material

Application range

For uninsulated, open plug-in connectors (4,8 and 6,3 mm connector width) from 0,5 to 6,0 mm², insulated cable lugs, plug-in connectors and butt connectors from 0,5 to

6,0 mm² and insulated and uninsulated end ferrules from 0,25 to 6,0 mm²
Scope of supply

3 replaceable dies

Order no

9562 973 301

Version

oil hardened

Overall length 250 mm

Material

Chrome-Vanadium electro-steel in special material

Surface

gun-metal fi nish

Application range

For uninsulated open plug-in connectors (4,8 and 6,3 mm connector width) from 0,5 to 6,0 mm², insulated cable lugs, plug-in connectors and butt connectors from 0,5 to

6,0 mm², insulated and uninsulated end ferrules from 0,25 to 6,0 mm², for insulated and uninsulated end ferrules with 10, 16 and 25 mm² and for uninsulated crimp, tube

and clench cable lugs to DIN 46234 and DIN 46235 as well as uninsulated crimp, butt and clench connectors to DIN 46341 and DIN 46267
Scope of supply

5 replaceable dies

Order no

9533 606 304

Tools

| 297

Tec

hnical eq

uipment and accessor

ies

Crimping tool

PreciForce

Constantly high quality crimps due to precision dies and locking device (unlockable), crimping pressure is precisely set in the factory (calibrated) and can be adjusted,

force amplifi cation with toggle lever for low-fatigue working, good handling through convenient handle position, low weight, short design and ergonomically shaped

handles
Overall length 220 mm

Application range

Working range

Version Fig.

Order no

Uninsulated crimp, tube and clench cable lugs to DIN 46234 and DIN 46235 and uninsulated crimp, butt and

clench connectors to DIN 46341 and DIN 46267

0,5-10,0 mm²

4 profi les 1

9500 156 904

Uninsulated open plug-in connectors (2,8 and 4,8 mm connector width)

0,1-2,5 mm²

4 profi les 2

9500 156 905

Uninsulated open plug-in connectors (4,8 and 6,3 mm connector width)

0,5-6,0 mm²

3 profi les 3

9562 975 235

Insulated cable lugs, plug-in connectors and butt connectors

0,5-6,0 mm²

3 profi les 4

9537 951 864

Uninsulated clenched connectors to DIN 46267

1,5-4,0/6,0+10,0 mm² 3 profi les 5

9562 975 230

Crimping tool

For solderless electrical connections, up to 30% reduction in hand force compared to customary crimping pliers

because of leverage ratio, constantly high quality crimps due to precision dies and locking device (unlockable),

crimping pressure is precisely set in the factory (calibrated) and can be adjusted, two-handed operation for easy

crimping of larger cable cross-sections, good handling due to balanced location of centre of gravity, angled

head and ergonomically shaped handles
Version

3 nests, oil hardened

Material Chrome-Vanadium electro-steel in special material

Length

250 mm

Application range

For uninsulated open plug-in connectors (4,3 and 6,3 mm connector width)

Order no

9562 975 205

Tools

298 |

Tec

hnical eq

uipment and accessor

ies

Crimping tool

for replaceable crimping dies

Precise factory-set crimping pressure, adjustable, force amplifi cation through leverage, ergonomically shaped handle, various positioning aids for exact determination of

the location
Length

200 mm

Version

Oil hardened

Material Chrome-Vanadium electro-steel in special material

Surface

gun-metal fi nish

Scope of supply

Order no

Without crimping insert, without case

9562 974 321

In plastic case, with mounting tool (Allen key), bolts and nuts

9562 974 320

Crimp insert

Application range

Working range Version Fig.

Order no

For uninsulated open plug-in connectors (4,8 and 6,3 mm connector width)

0,5-6,0 mm²

3 profi les 1

9562 974 905

For insulated cable lugs, plug-in connectors and butt connectors

0,5-6,0 mm²

3 profi les 2

9562 974 906

For uninsulated crimp, tube and clench cable lugs to DIN 46234 and DIN 46235 and uninsulated crimp, butt and clench

connectors to DIN 46341 and DIN 46267

0,5-10 mm²

4 profi les 3

9562 974 914

For uninsulated cable lugs and cable connectors

16+25 mm²

2 profi les 4

9562 974 923

For spark plug caps and distributors (quick-fi t sleeves, saw-tooth sleeves, threaded sleeves, ignition cable sleeves and

distributor sleeves)

5 profi les 5

9562 974 935

Tools

| 299

Tec

hnical eq

uipment and accessor

ies

Crimping tool

For cable cutting, for the stripping of wires and crimping of insulated cable lugs and plug-type connectors, with

thread holes for cutting off Cu and Ms threaded pins M2.6/3/3.5/4/5, pivot bolt for high stability and smooth

running, handles with two-coloured, multi-component sleeves
Width

62 mm

Height

25 mm

Material Special steel

Surface

Painted black

Number of profi les 3
Application range

For insulated cable lugs and cable connectors

Working range

Order no

0,75-6,0 mm²

9534 825 853

1,5-6,0 mm²

9562 973 224

This fi gure corresponds to 9534 825 853

Crimping tool

self-adjusting, for end ferrules

Narrow handle width and improved ergonomics, self-adjusting to the required end ferrule size, with side feed (patent pending), constant high crimp quality due to locking

device (unlockable), crimping pressure is precisely set in the factory (calibrated), force amplifi cation with toggle lever for low-fatigue working, good operating comfort

through convenient design and low weight
Length

180 mm

Material Chrome-Vanadium electro-steel in special material, oil hardened

Surface

Gun-metal fi nish

Application range

For crimping end ferrules according to DIN 46228 part 1 + 4

Version

Fig.

Order no

Square crimping up to 16 mm², for all twin end ferrules to 2 x 6 mm² or 2 x AWG 8

9533 605 132

Hexagonal crimping up to 10 mm², for all twin end ferrules to 2 x 4 mm² or 2 x AWG 10

9562 975 314

Tools

300 |

Tec

hnical eq

uipment and accessor

ies

Crimping tool

self-adjusting, for end ferrules (patented)

Self-adjusting fi t to the required end ferrule size: no crimping faults caused by using the incorrect crimping

insert, front feed of the end ferrule into the tool, constant high crimp quality due to locking device (unlockable),

crimping pressure is precisely set in the factory (calibrated) and can be adjusted, force amplifi cation with toggle

lever for low-fatigue working, good operating comfort through convenient design and low weight

Length

190 mm

Version

Crimping of 0,08 to 10,0 mm² in one profi le, for all twin end ferrules to 2 x 4 mm² or 2 x AWG 10, oil

hardened

Material Chrome-Vanadium electro-steel in special material

Surface

Gun-metal fi nish

Application range

For crimping end ferrules according to DIN 46228 part 1 + 4

Order no

2300 011 025

Crimping tool

for end ferrules

Easy crimping through optimised gear ratio, light and slim design, crimping in identifi ed half-round profi les for

the secure connection of sleeves and cables, 9 especially deep profi les with tapered sides
Length

180 mm

Version

Forged, oil hardened

Material Special tool steel
Application range

For crimping end ferrules according to DIN 46228 part 1 + 4

Order no

9537 951 890

Tools

| 301

Tec

hnical eq

uipment and accessor

ies

Diagnosis unit

AXONE Nemo with Navigator TXTs

Robust, splash water-protected, high-performance hardware, software IDC5 Premium Truck including integration software IDC5 Premium AGRI, can be extended via

TEXA App Store, with operating system, no problems with computer viruses or compatibility issues of a normal PC, magnetic connections, fast connection of additional

modules is possible
– Intel

Quad Core N3160

– HD 250 GB

– RAM 8 GB

– Monitor 12” Ultra Wide

– Resolution 2160 x 1440

– Ambient light sensor

– Area sensors: Gyroscope, altimeter, barometer, acceleration sensor, compass

– GPS antenna

– Dual Band antenna, WiFi/BT

– Lithium batteries

– Mini Docking

– 2 x 5 megapixel photo camera (front and rear)

– Speaker

– Microphone

– ON/OFF button

– 10-30 VDC power supply connector

– Status LED: ON, OFF, charging

– Active input pen

– Rubber protective sleeve

– Connections for expansion modules
Scope of supply

– With EOBD cable, USB cable, Bluetooth antenna, strap and device case

– Texpack Truck contract for annual subscription to software updates for 12 months

– Tex@info contract for technical notifications for 12 months

– Tex@info contract for Call Centre for 12 months

– Tex@info contract for Google

"fixed bugs" search function for 12 months

Order no

9539 003 640

Workshop equipment

302 |

Tec

hnical eq

uipment and accessor

ies

Workshop equipment

Diagnosis set

Low pressure

Simple and professional inspection of the complete low pressure circuit Pressure test can be carried out at any desired point in the supply and return (even during travel).

Transparent hoses enable a visual inspection, e.g. for air bubbles, impurities or fuel fl ow in the supply and return. The return quantity measurement is implemented at the

respective injection using the connection method (rail sealing plugs), error causes (incorrect delivery/return pressures, air bubbles/impurities in fuel system, is any diesel

at all being pump). Defective injectors, high pressure pumps, lines, delivery pumps, etc. can be diagnosed quickly and easily.
Application range

For Common Rail diesel engines in commercial vehicles, construction machinery and industrial engines
Scope of supply

1 x adapter hose, 6 mm, 2 m long

3 x pressure gauges, 1-3/1-5/1-15 bar

12 x T-pieces, 8 x 20 mm red, 8 x 30 mm yellow, 9.5 x 20 mm grey, 10 x 20 mm green, 10 x 30 mm blue, NG8 type 246 white, diameter 6 mm brown,

diameter 8 mm orange, diameter 10 mm purple, 11.8 x 25 mm light blue, NG12, type 246 pink, diameter 12 mm, black

1 x adapter hose, 8 mm PVC, 2 m

2 x measuring cups and lids, 250 ml, 1000 ml

5 x ring eyelets with plug nipple, M8, M10, M12, M14, M16

5 x double hollow screws, M8 x 1, M10 x 1, M12 x 1.5, M14 x 1.5, M16 x 1.5

2 x hollow screws, M12 x 1.5, M14

2 x screw-in connectors, M12 x 1, M22

1 x angle connector, NG8

1 x connector, 16 x 22 mm

1 x adapter with plug nipple, 16 x 22 mm

1 x connector, NG12

1 x self-sealing coupling, 11.8 x 25 mm

1 x self-sealing grommet, 11,8 x 25 mm

4 x sealing cones, 2 x M14 x 1.5, M16 x 1.5, M20

4 x sealing plugs, M12, M14, M16, M18

4 x pipe plugs, M12, M14, M16, M18

1 x screw-in adapter, M14 x 1.5

4 x angled screw connections, M12, M14, M16, M18

4 x straight screw connections, M12, M14, M16, M18

5 x screw-on connection pieces, M12, M14, M16, M18, M22

3 x screw-in adapters, M8 x 1.5 x 10/20/30

1 x cap nut, M14 x 1.5

1 x T-piece, K-S-K, 30 cm

in plastic case with foam insert

Order no

9500 012 342

| 303

Tec

hnical eq

uipment and accessor

ies

Diesel emissions tester

AVL DiTEST MDS 305

– convenient and fast solution for exhaust testing in the workshop

– space-saving, tidy storage of the exhaust station without a workshop trolley

– faster exhaust testing procedure with intuitive guidance through the application

– easy vehicle search from the databases

– an exhaust test can be performed by one person on all commercial vehicles

– novel radio concept enables the maximum freedom of movement during measurement

– wear-free, wireless connection to PC

– short warm-up times < 2 Min.

– small, easy to handle OBD module

– fl exible, sturdy and effi cient to use in the day-to-day business

– innovative workshop-orientated solution for fi tting to the vehicle to be measured
Application range

For trucks, buses and cars
Scope of supply

– AVL DiSmoke 480 Bluetooth diesel exhaust module

– AVL DiTEST OBD 1000 OBD interface

– AVL DiTEST AUX 2000 Bluetooth engine speed/temperature recording

– wall bracket suitable for the workshop
including guideline 5

Order no

9539 006 030

Description

Order no

Service contract for exhaust gas tester, AVL DiTEST Basic-Support Diesel

9682 550 911

Accessories

Workshop equipment

Oscilloscope

Scope 1200

Digital 2-channel scope module, display of the measurements on PC or Tablet, active probe supply with colour

guide, voltage measurement to 600 V AC/DC, current measurement 1 mA to 1800 A AC/DC, resistance

measurement from 0,1 Ω to 15M Ω, 2 differential oscilloscope measurement channels each with 40 MS/s,

galvanically separated inputs
Version 2-channel oscilloscope
Scope of supply

– Scope module 1200

– current clamp 100 mA to 1800 A

– 2 x cable set (measuring cables, test probes, test clamps (black/red)

in equipment case

Order no

9539 006 051

304 |

Tec

hnical eq

uipment and accessor

ies

Air-conditioning service unit

Konfort 760 R 2 GAS READY

Menu guided and fully automatic execution of the air conditioning service on all vehicles, hermetically closed container protects fresh oil and additives against moisture

penetration, refrigerant scales locked during transportation and monitoring for internal leaks
Tank contents 20 kg
Application range

For trucks, small buses, cars and for use on hybrid vehicles
Scope of supply

PAG oil container, UV container, used oil container, cover hood, mains connection cable, operating instructions
with truck, passenger car and agricultural database on SD card and manual

Description

Order no

Air-conditioning service unit prepared for R 134a refrigerant

9539 004 072

Air-conditioning service unit Prepared for refrigerant R 1234yf

9539 004 073

Workshop equipment

| 305

Tec

hnical eq

uipment and accessor

ies

Laser axle measuring system

TL10

Easy to use, attached to the measuring heads between the wheel bolts by a magnetic attachment on steel rims or with a special brace on aluminum rims. That means

that the vehicle does not need to be lifted, it is also possible to use the tool without the wheels being fi tted. The system can also be used on cars with the use of the

additional accessories set. Because of the wide range of applications, the system provides a quick repayment of the initial cost
Application range

For trucks, buses, semi-trailers, trailers, vans, cars
Scope of supply

2 x measuring heads each with 1 pivoting battery diode laser

1 x set magnetic spacers, short

1 x set magnetic spacers, long

1 x clamping device for aluminium rims

2 x specially mounted rotating/sliding plates with brake

1 x track scale

2 x magnetic scales

1 x electronic inclination gauge with quick clamping device

1 x battery charger

1 x measurement log fi le

1 x sturdy, mobile storage cabinet with service stand

Order no

9682 202 520

Workshop equipment

Scania Truck (2017 year). Spare parts and accessories - 19
