Seat Leon (2022 year). Manual in english

Driving

Drive: Warning! Power is limited.
Check the manual

The warning lamp lights up yellow. Per-
formance limited. The high-voltage bat-
tery may not be sufficiently charged or
may have reached its operating temper-
ature limit, for example in very cold out-
side temperatures.

Vehicle sound: Fault! Pedestrians
cannot hear the vehicle. Visit a work-
shop

The warning lamp lights up yellow. There
is a vehicle sound fault. Drive with utmost
care, as other road users may not be
able to hear the electric vehicle. Go im-
mediately to a specialised workshop to
have the fault repaired.

Operating mode selection

Valid for: hybrid vehicles

The vehicle has different operating modes so
that it can always be optimally adjusted to
every situation while driving. Once the drive





system has been turned on, and provided
that all of the operating conditions required
for this purpose have been met, the

E-MODE

operating mode is always activated in the
first instance for electric driving.

Operating mode selection

●

Switch on the drive system

›››

page 220

●

Press button



on the control panel of the

upper centre console.

●

Press the

E-Mode

Hybrid

function but-

ton in the infotainment system.

Further information about the operating
mode can be found in



E-MODE



(electric driving)

In the E-MODE electric driving mode, the ve-
hicle basically drives in electric only mode. To
the extent possible, the vehicle's combustion
engine is not used.

All of the following conditions must be met for
E-MODE to be activated:

●

The high voltage battery has a sufficient

charge level.

●

The vehicle speed is lower than 130 km/h

(80 mph).

●

The high voltage battery temperature is

above -10°C.

If, while driving in E-MODE mode, the neces-
sary conditions are no longer met, the com-
bustion engine starts and electric driving is
suspended. In this case, the display



lights

up on the instrument cluster display.

The combustion engine starts when a

kick-

down

occurs in E-MODE. However, E-MODE

remains activated.

Hybrid



(use the battery's charge)

This is the operating mode that allows you to
save most fuel.

The operating mode control unit tries to make
the most of the battery charge. For this pur-
pose, with active directions the navigation
data are also accessed.

In this operating mode, the electric motor and
the combustion engine share the work of
driving the vehicle.

In hybrid operating mode, the power from the
battery charge is used optimally. If route
guidance is activated, the vehicle may auton-
omously recharge the high-voltage battery
using the combustion engine.

The displayed symbol varies depending on the

active operating mode and the charge level of
the high-voltage battery.

222

Start and driving

Manual control of the battery charge

Manual control of the battery charge is only
possible in

Hybrid

operating mode. The op-

tion selected by the user is only valid until the
ignition is switched off or the vehicle is switch-
ed to Hybrid mode or E-MODE.

Press the function button



and use the sym-

bols



and



to control the battery charge:

Pressing this symbol selects a higher
theoretical charge level. The vehicle
tries to reach that new theoretical high-
voltage battery charge level while driv-
ing. The vehicle is powered by the com-
bustion engine. If the combustion engine
has “excess” power, it is used to charge
the high-voltage battery. This option in-
creases fuel consumption. SEAT there-
fore recommends using the charging
socket to charge the high-voltage bat-
tery, whenever possible

›››

page 308

The high-voltage battery charge level is
kept at around the current level while
driving. If you accelerate harder or in-
crease the vehicle speed, the combus-
tion engine starts up. When permitted by
the driver’s demand for acceleration and
the vehicle speed, the vehicle switches
back to electric mode.



Pressing this symbol selects a lower the-
oretical charge level. The vehicle only
uses the battery's charge when it is
above the selected theoretical charge
level. The rest is kept until the end of the
journey.

The

Intelligent Hybrid

App allows the user to

save electrical energy until reaching home
(charging point) with just “one click”. If this
option is not selected, the maximum amount
of electrical energy will be consumed until
the selected destination is reached. If the
user has no active route, the function will offer
the activation of a predictive route and BMA
mode from the widget itself with just one
click.

Show the active operating mode

The operating mode active at any given time
is displayed on the instrument cluster display,
e.g.



WARNING

Switching to a different operating mode
while driving can distract you from traffic
conditions and cause accidents.



Note

Information about the operating mode that
is currently active is displayed on the in-
strument cluster display, along with the
charge level of the high-voltage battery.

Troubleshooting



The E-MODE operating mode is not

available

The indicator lamp lights up in white.

The E-MODE operating mode



(driving in

electric mode) cannot be used temporarily
because one or more conditions are not met.

●

The conditions must be met to use the E-

MODE operating mode

›››

page 222

Start-Stop system

Control lamps



It lights up

The Start-Stop system is available, the automatic en-

gine shutdown is active.

Not valid for PHEV hybrid vehicles.

223

Driving



It lights up

The Start-Stop system is not available or has been

disconnected.

Instructions for the driver on the instru-
ment panel display

Start-Stop system deactivated. Start
the engine manually

●

This indication shows that the Start-Stop

system

cannot

restart the engine.

This happens for 2 reasons: if the driver's door
has been opened or if the driver has unbuck-
led the seat belt.

Start-Stop system: Fault! Function
not available

●

There is a fault in the Start-Stop system.

Take the vehicle to a workshop to have the
fault repaired.

Description and operation

The Start-Stop system helps you to save fuel
and reduce CO

emissions.

In Start-Stop mode, the engine will automati-
cally switch off when the vehicle stops or is

stopping. The ignition remains switched on.
The engine automatically switches back on
when required.

In this scenario, the light of the







button stays lit.

When the ignition is switched on, the Start-
Stop function is automatically activated.

Vehicles with a manual gearbox

●

When the vehicle or when it is stopped, put

it into neutral and release the clutch pedal.
The engine will switch off. The warning lamp



will light up. The engine can be stopped

before stopping completely (approximately 7
km/h).

●

When the clutch pedal is pressed the en-

gine will start up again. The warning lamp will
switch off.

Vehicles with an automatic gearbox

●

Brake until the vehicle has come to a stand-

still, and keep your foot on the brake pedal or
activate the Auto Hold system so that the ve-
hicle remains braked. The engine will switch
off. The warning lamp



will appear in the

display. The engine can be stopped before
stopping completely (approximately 7 or 2
km/h depending on the vehicle's gearbox).

●

When you take your foot off the brake ped-

al the engine will start up again. The warning
lamp will switch off. With the Auto Hold sys-
tem, the engine will not start if you remove
your foot from the brake pedal. The car starts
when you press the accelerator pedal.

Basic requirements for the Start-Stop
mode

●

The driver door must be closed.

●

The driver's seat belt must be fastened.

●

The bonnet must be closed.

●

The engine has reached operating temper-

ature.

●

The reverse gear must not be engaged.

●

The vehicle must not be on a very steep

slope.

The engine does not turn off for various
reasons

Before stopping the vehicle, the system veri-
fies whether certain conditions are met. The
engine

does not

switch off, in the following

situations for example:

●

The engine has not yet reached the re-

quired temperature for the Start-Stop mode.

In the mHEV version (semi-hybrid), above 20

km/h.

224

Start and driving

●

The temperature selected on the climate

control has not been reached.

●

The interior temperature is very high/low.

●

Defrost function button activated

›››

page 155

●

Park assist is switched on.

●

The battery is very low.

●

The steering wheel is overly turned or is be-

ing turned.

●

If there is a danger of misting.

●

After engaging reverse gear.

●

In case of a very steep gradient.

●

In a traffic jam after stopping for the fifth

time, the engine will not stop any more.

●

With ESC disabled.

●

After emergency braking or loss of adhe-

sion.

●

With a trailer attached.

●

While the particle filter is regenerating (die-

sel engines).



is displayed on the instrument cluster

screen; it is also displayed in the driver infor-
mation system,



The engine starts by itself

When stopped, the normal system mode may
be interrupted in the following situations. The
engine restarts by itself without involvement
from the driver.

●

The interior temperature differs from the

temperature selected on the climate control.

●

Defrost function button activated

›››

page 155

●

The brake has been pressed several times

consecutively.

●

The battery is too low.

●

High power consumption.

●

The vehicle rolls forward or backward with

the engine off.

●

ESC deactivated.

●

The accelerator pedal (automatic trans-

mission), or the clutch (manual transmission)
is pressed.

●

The steering wheel turns slightly (except

mHEV version).

●

When the air conditioning is activated.

Additional information related to the auto-
matic gearbox

The engine stops when the selector lever is in
positions

and

, as well as in Tiptronic

mode. When the parking lock button

is acti-

vated, the engine will also remain off when
you remove your foot from the brake. In order
to start the engine up again the accelerator
must be pressed, or another gear engaged or
the brake released.

If the selector lever is placed in

while stop-

ped, the engine will start up again.

Additional information about vehicles with
Adaptive Cruise Control (ACC)

In vehicles with ACC function, the engine will
start up again in certain operating conditions
if the radar sensor detects that the vehicle
ahead drives off again.

WARNING

●

Never switch the engine off until the vehi-

cle is stationary. The operation of the brake
and steering will not be fully guaranteed.
More force will be needed to turn the steer-
ing wheel or to brake. You could suffer an
accident and even serious injuries.

●

To avoid injury, make sure that the Start-

Stop system is switched off when working
in the engine compartment

›››

page 226

CAUTION

The Start-Stop system must always be
switched off when driving through flooded
areas

›››

page 238

Note

●

In vehicles with an automatic gearbox,

you can control whether the engine should
switch off or not by reducing or increasing
the brake force applied. While the vehicle
remains stopped, the engine will not stop if
the brake pedal is slightly pressed, in traffic
jams with frequent stopping and starting
for example. As soon as strong pressure is

225

Driving

applied to the brake pedal, the engine will
stop.

●

When stopped, the brake pedal must be

kept pressed to ensure that the vehicle
does not move.

●

If the engine “stalls” with a manual gear-

box, it can be directly started up again by
immediately pressing the clutch pedal.

●

With an automatic gearbox, if the lever is

placed in position D, N or S after engaging
reverse gear, 10 km/h (6 mph) in a forwards
direction must be reached for the system to
be in a status to stop the engine.

Manually connecting and discon-
necting the Start-Stop system

Fig. 167

On the Infotainment system screen.:

Start-Stop system connected.



View in the

main menu.



View with the Infotainment sys-

tem off.

If you do not want to use the system, you can
disconnect it manually through the Infotain-
ment system:

●

Select



> Assistants > Smart Assistants

When the symbol



appears orange

›››

Fig. 167

the system is activated and will

stop and start. When the symbol



appears

in white the system is disconnected.

Note

The system switches on every time the en-
gine is turned off voluntarily.

Manual gearbox

Changing gears

Fig. 168

Gear shift pattern of a 6-speed man-

ual gearbox

The position of the gears is indicated on the
gearbox lever

›››

Fig. 168

●

Press the clutch pedal and keep your foot

right down.

●

Move the gearbox lever to the required po-

sition.

●

Release the clutch.

226

Start and driving

Selecting reverse gear

Engage reverse gear only when the vehicle is
stopped.

●

Press the clutch pedal and keep your foot

right down.

●

With the gearbox lever in neutral, push it

downwards, move it to the left as far as it will
go and then forwards to select reverse

›››

Fig. 168

●

Release the clutch.

Changing down gears

While driving, changing down a gear must al-
ways be done gradually, i.e. to the gear di-
rectly below and when the engine speed is
not too high

›››

. Changing down while by-

passing one or various gears at high speeds
or at high engine speeds can damage the
clutch and the gearbox, even if the clutch
pedal remains depressed

›››

WARNING

When the engine is running, the vehicle will
start to move as soon as a gear is engaged
and the clutch released. This also happens
if the electronic parking brake is switched
on.

●

Never engage reverse gear when the ve-

hicle is moving.

WARNING

If the gear is changed down inappropriate-
ly by selecting a gear that is too low, you
may lose control of the vehicle, causing an
accident and serious injuries.

CAUTION

When travelling at high speeds or at high
engine speeds, selecting a gear that is too
low can cause considerable damage to the
clutch and the gearbox. This can also oc-
cur if the clutch pedal is pressed and held
and it does not engage.

CAUTION

To prevent damage and avoid premature
wear, please observe the following:

●

Do not rest your hand on the gear lever

while driving. The pressure applied by your
hand is transmitted to the gearbox selector
forks.

●

Do not leave your foot on the clutch ped-

al; although the pressure may seem insig-
nificant, it can cause the premature wear of
the clutch plate. Use the foot rest when you
do not need to change gear.

●

Always ensure that the vehicle is com-

pletely stopped before engaging the re-
verse gear.

●

Always press the clutch to the floor when

changing gears.

●

Never hold the vehicle “on the clutch” on

hills with the engine on.

Automatic gearbox/DSG au-
tomatic gearbox

Introduction

Your vehicle is equipped with an electronical-
ly controlled manual gearbox. Torque be-
tween the engine and the gearbox is trans-
mitted via two independent clutches. They
replace the torque converter found on con-
ventional automatic gearboxes and allow for
smooth, uninterrupted acceleration of the ve-
hicle.

The

Tiptronic

system allows the driver to

change gears

manually

›››

page 229,

Changing gear in Tiptronic mode

Control lamps



It lights up green

The brake is not pressed.
To select a gear range, press the brake pedal.

227

Driving

Selector lever positions

Fig. 169

In the centre console: selector lever.

The selector lever position is shown when the
corresponding sign lights up. The engaged
gear is also displayed on the screen on the
manual gearbox positions

and

(when the ECO driving profile is selected

›››

page 234



– Parking lock

When the

button is pressed, the drive

wheels are locked. Only press

when the ve-

hicle is

stationary

›››

To press the

button you must press the

brake pedal simultaneously.



– Reverse gear

Reverse gear must be engaged only when
the vehicle is

stationary

and the engine is

idling

›››

To engage reverse gear

, you must press the

brake pedal simultaneously. The reverse
lights switch on when the reverse gear

selected and the ignition is on.



– Neutral

In this position, the gear is in neutral.

Press the brake pedal to move the lever from

D/S

when the vehicle is stationary or at

speeds below 3 km/h (2 mph)

›››



– Permanent forward drive position

The

D/S

position enables the gears to be op-

erated in normal mode (

) or sport mode (

To select Sport mode

, move the lever back-

wards. Pushing the lever again will select nor-
mal mode

. The selected driving mode is

displayed on the instrument panel screen.

normal mode

(

), the gearbox selects the

best gear ratio. This depends on the engine
load, the road speed and the dynamic gear
control programme (DCP).

Sport mode

(

) should be selected for a

sporty driving style. This setting makes use of
the engine's maximum power output. When
accelerating the gear shifts will be noticea-
ble.

Under certain circumstances (e.g. on moun-
tain roads) it can be advantageous to switch
tiptronic mode

›››

page 229

, to adapt the

gears to suit the road conditions.

WARNING

●

Take care not to press the accelerator

pedal when the vehicle is stopped. The ve-
hicle could start moving immediately (in
some cases even if the parking brake is en-
gaged) resulting in the risk of an accident.

●

Never move the lever to R position when

driving. Failure to follow this instruction
could result in an accident or failure.

●

With the lever in any position , the foot

brake must be pushed down whenever the
engine is running. This is because an auto-
matic gearbox still transmits power even at
idling speed.

●

While you are selecting a gear and the

vehicle is stopped with the engine running,
do not accelerate. Failure to follow this in-
struction could result in an accident.

●

As a driver you should never leave your

vehicle if the engine is running and a gear is
engaged. Switch on the electronic parking
brake and select the parking lock (P).

Note

●

If the lever is moved accidentally to N

when driving, release the accelerator and
let the engine speed drop to idling before
selecting gear range D or S again.

●

If the power supply is interrupted while

the P parking lock is active, it will not be
possible to move the lever. If this should
happen the manual release can be used. In

228

Start and driving

this case, you should seek professional as-
sistance.

Note

●

If a gear has been selected, the vehicle

does not move forwards or back. Proceed
to the next mode:

–

When the vehicle does not move in the
required direction, the system may not
have the gear range correctly engag-
ed. Press the brake pedal and engage
the gear range again.

–

If the vehicle still does not move in the
required direction, there is a system
malfunction. Seek specialist assistance
and have the system checked.

Changing gear in Tiptronic mode

Fig. 170

Steering wheel: automatic transmis-

sion levers

Tiptronic gives the driver the option to
change gears manually.

When you change to the Tiptronic pro-
gramme, the vehicle remains in the currently
selected gear. This is possible as long as the
system is not changing gear automatically
due to a traffic situation.

Using Tiptronic with the steering wheel
paddles

The gear shift paddles can be used when the
selector lever is in the

D/S

position.

●

Press the gearshift paddle

to select a

higher gear

›››

Fig. 170

●

Press the gearshift paddle

–

to select a

lower gear.

●

To exit the Tiptronic mode, pull the right-

hand gear shirt paddle towards the steering
wheel for approximately 1 second.

To keep Tiptronic mode permanently switch-
ed on, move the selector lever to the

posi-

tion. If the selector lever is in position

and

the gear shift paddles are not operated for
some time, the Tiptronic mode will automati-
cally be switched off.

CAUTION

●

When accelerating, if a higher gear is not

selected, it will automatically change
shortly before reaching the maximum per-
mitted RPM.

●

Also, if a lower gear is selected, the sys-

tem will not change until it detects that the
engine will not reach its maximum RPM.

Driving with an automatic gearbox

The gearbox changes gear ratios automati-
cally as the vehicle moves.

The engine can only be started with the lever
in the

position and the

button must be lit

up (the parking lock remains active).

Driving down hills

Under certain circumstances it may be ad-
vantageous to use the Tiptronic mode to se-
lect the gear manually according to driving
conditions

›››

Stop/Park

To park on flat ground, just press the

button

›››

Fig. 169

. On slopes the parking brake

should first be applied and then press the

button.

If the driver door is opened and the

button

has not been activated, the vehicle could
move. The following warning is displayed on
the instrument panel:



Gear change: se-

lector lever in the drive position!.

Additionally, a buzzer will sound.

229

Driving

Stopping on a downhill

Always

apply the brake pedal firmly to pre-

vent the vehicle from moving; if necessary,
apply the electronic parking brake

›››

Do not

accelerate while a range of gears is

engaged to prevent the car from rolling
downhill

›››

Starting off uphill with the Auto Hold func-
tion

●

Once you have engaged a gear, take your

foot off the brake pedal and gently press the
accelerator.

Starting off uphill without the Auto Hold
function

●

Pull on the electronic parking brake button.

●

Once you have engaged a gear, gently

press the accelerator and pull on the elec-
tronic parking brake button.

Back-up programme

If all the positions of the lever are shown over
a light background on the instrument cluster,
there is a system fault and the automatic
gearbox will operate with the backup pro-
gramme. It is still possible to drive the vehicle,
however, at low speeds and within a selected
range of gears.

Driving in reverse gear may

not be possible

Parking lock manual release mechanism

If, in the event of a power failure (e.g. the 12-
volt vehicle battery is drained), the vehicle
must be towed and the parking lock can be
released manually. In this case, you should
seek professional assistance.

Kick-down

The kick-down device provides maximum ac-
celeration when the gear selector lever is in
the positions

or in Tiptronic mode.

When the accelerator pedal is pressed right
down, the automatic gearbox will shift down
to a lower gear, depending on road speed
and engine speed. This takes advantage of
the maximum acceleration of the vehicle

›››

The upshift to the next higher gear is delayed
until the engine reaches maximum rpm.

WARNING

Observe the safety warnings

›››

in Selec-

tor lever positions on page 228

●

Never allow the brake to rub and do not

use the brake pedal too often or for long
periods, as the brakes can overheat. This
reduces the braking power, increases the
braking distance or even causes a brake
system fault.

●

If you have to stop on a hill, keep the vehi-

cle’s brakes applied with the brake pedal or
parking brake.

WARNING

Please note that if the road surface is slip-
pery or wet, the kick-down feature could
cause the driving wheels to spin, which
could result in skidding.

CAUTION

●

If you stop the vehicle on a gradient, do

not attempt to stop it from rolling by de-
pressing the accelerator when a gear has
been selected. This could cause overheat-
ing and damage the automatic gearbox.

●

If you allow the vehicle to roll with the

lever in position N and the engine off, the
automatic gearbox will be damaged due to
a lack of lubrication.

●

In certain driving situations or traffic con-

ditions, the gears could overheat and be
damaged! If the warning lamp



lights up,

stop the vehicle as soon as you can and
wait for the gearbox to cool

›››

page 232

●

If the gearbox operates with the backup

programme, take the vehicle to a special-
ised workshop and have the fault repaired
without delay.

Launch-control program

The Launch-control programme enables
maximum acceleration from a standstill.

230

Start and driving

Condition:

the engine must have reached op-

erating temperature and the steering wheel
must not be turned.

The engine speed for Launch-control is differ-
ent on petrol and diesel engines.

To use the Launch-control you must discon-
nect the traction control (TCS) or activate the
ESC Sport mode, using the Infotainment sys-
tem menu: press the function button



> As-

sistants > ESC menu

. The warning lamp



will remain on.

●

Press the brake pedal with your left foot

and hold it down for at least one second.

●

Set the selector lever to position

or Tip-

tronic, or select the

sport

driving profile from

the SEAT Drive Profile

›››

page 234

●

With your right foot, press the accelerator

down to the full throttle or kick-down position.
The engine speed will stabilise at about

3,200

rpm (petrol engine) or about

2,000

rpm (diesel engine).

●

Take your left foot off the brake pedal. The

vehicle starts with maximum acceleration.

WARNING

●

Always adapt your driving style to the

traffic conditions.

●

Only use the Launch control programme

when road and traffic conditions permit,
and make sure your manner of driving and

accelerating the vehicle does not incon-
venience or endanger other road users.

●

Make sure that the ESC remains switched

on. Please note that when the TCS and ESC
are deactivated, the wheels may start to
spin, causing the vehicle to lose grip. Risk
of accident!

●

After moving off, you should activate the

TCS or deactivate the ESC “sport” mode
again using the Infotainment system: func-
tion button



> Assistants.

Note

●

After using the Launch control pro-

gramme, the temperature in the gearbox
may have increased considerably. In this
case, the programme could be disabled for
several minutes. The programme can be
used again after the cooling phase.

●

Accelerating with the launch control pro-

gramme places a heavy load on all parts of
the vehicle. This can result in increased
wear and tear.

downhill assistant

Downhill speed control is activated when the
lever is in the

D/S

position and the brake is

applied. An appropriate lower gear is engag-
ed.

The assistant attempts to maintain the speed
at which the vehicle was travelling when the
brake was applied, within logical limits. It may
be necessary to correct the speed by press-
ing the brake.

The assistant can only change down as far
as 3rd gear. It is possible that on very steep
slopes you may have to switch to tiptronic
mode and thus manually change down to
2nd or 1st gear to take advantage of engine
braking and take the load off the brake sys-
tem.

Downhill speed control is deactivated as
soon as the road levels out again or you press
the accelerator pedal.

On vehicles with a cruise control system

›››

page 242

, downhill speed control is acti-

vated when you set a cruising speed.

WARNING

The downhill speed control cannot defy the
laws of physics. Therefore, speed cannot
be maintained constant in all situations. Al-
ways be prepared to use the brakes!

Inertia mode and inertia discon-
nection

The inertia mode allows you to travel certain
distances without using the accelerator,
which saves fuel.

231

Driving

When driving with the selector lever in posi-
tion

without pressing the accelerator or

brake, the vehicle rolls (coasting). The gears
will automatically disengage and the vehicle
will roll freely, without the effect of the engine
brake.

Activation of the inertia mode

Condition:

lever in position

, slopes of less

than 12 % and speeds between 20 and 130
km/h.

●

Gently take your foot off the accelerator.

The indication will be shown on the instru-
ment panel



, the engaged gear and cur-

rent consumption will disappear and the
word “

Inertia

” will be displayed.

While the vehicle rolls, the engine runs at
idling speed.

Activating the inertia disconnection

Condition:

lever in position

, slopes of less

than 12 % and speeds between 40 and 160
km/h (it is deactivated when the lever is in po-
sition

●

Gently take your foot off the accelerator.

Applying both the

inertia mode

(= prolonged

section with less energy) and

inertia discon-

nection

(= shorter section without the need

for fuel) facilitates improved fuel consumption
and emission balance. In the inertia discon-

nection mode, the engine is not only discon-
nected but also turns off.

The indications



and



will be displayed on

the instrument cluster, the selected gear will
disappear, the RPM of the combustion engine
will drop to 0 and the text “

coasting

” will ap-

pear under current consumption.

Stopping inertia mode

●

Press the brake or the accelerator pedal.

To take advantage of the engine's inertia
mode, simply remove your foot from the ac-
celerator.

If the vehicle has

SEAT Drive Profile

›››

page 234

, the inertia mode can be activa-

ted in

Normal

Eco

and

Individual

modes. In

Eco

mode, it is activated whenever the oper-

ating conditions are met, regardless of the
smoothness with which the foot is removed
from the accelerator.

WARNING

●

If the inertia mode has been switched on,

take into account, when approaching an
obstacle, that the vehicle will not deceler-
ate in the usual manner: risk of accident!

●

When using inertia mode while travelling

down hills, the vehicle can increase speed:
risk of accident!

●

If other users drive your vehicle, warn

them about inertia mode.

Note

●

The operation of the inertia mode in com-

bination with hybrid engines (MHEV and
PHEV) can cause the combustion engine to
switch off.

●

The inertia mode will be automatically

disconnected on gradients steeper than
15%.

Indications on the instrument panel
display

Clutch



Clutch overheating! Please stop!

●

The clutch has overheated and could be

damaged. Stop and wait for the gearbox to
cool with the engine idling and press the

parking lock button. When the warning lamp
and the driver message turn off, go to a spe-
cialised workshop to get the fault repaired. If
they do not turn off, do not continue driving.
Seek specialist assistance.

Faults in the gearbox



Gearbox: Fault! Stop the vehicle

and place the lever in the position
P.

●

There is a fault in the gearbox. Stop the ve-

hicle in a safe place and do not continue driv-
ing. Seek specialist assistance.

232

Start and driving



Gearbox: System fault! You may

continue driving.

●

Have the fault corrected by a specialised

workshop without delay.



Gearbox: System fault! You can

continue driving with restrictions.
Reverse gear disabled

●

Take the vehicle to a specialised workshop

and have the fault repaired.



Gearbox: System fault! You can

continue driving in D until switch-
ing off the engine

●

Park the vehicle in a safe place. Seek spe-

cialist assistance.



Gearbox: too hot. Adapt your

driving accordingly

●

Continue driving at moderate speeds.

When the warning lamp switches off, you can
continue driving in a normal manner.



Gearbox: press the brake and en-

gage a gear again.

●

If the warning was caused by the tempera-

ture of the gearbox, this driver message will
be displayed when the gearbox has cooled
again.

Gear-change recommenda-
tion

Selecting the optimal gear

Depending on the equipment on the instru-
ment panel screen, a recommendation is
shown with the gear that should be engaged
to optimise consumption.

On vehicles with

automatic transmission

, it is

only displayed when driving in Tiptronic
mode

›››

page 229

No recommendation will appear if the opti-
mal gear is engaged. The current gear will be
displayed.

Display

Meaning



Optimum gear.







Changing to a higher gear is rec-

ommended.







Changing to a lower gear is rec-
ommended.

Information regarding the “cleanliness” of
the particulate filter

When the exhaust system detects that the
particulate filter is close to saturation, this
system’s self-cleaning function recommends
the optimal gear for that function

›››

page 325

WARNING

The gear change recommendation is an
auxiliary function and in no case should be
a substitute for careful driving.

●

Responsibility for selecting the correct

gear, depending on the circumstances,
rests solely with the driver.

For the sake of the environment

Selecting the correct gear can help to save
fuel.

Note

The recommended gear indication turns off
when the clutch pedal is or when the vehi-
cle is no longer in Tiptronic mode.

Steering

Information relating to different ve-
hicle processes.

Electro-mechanical power steering adapts

electronically

to the speed of the car, torque

and steering angle.

Even if the power steering fails or the engine
is stopped, it is possible to continue to rotate
the steering wheel as long as the key remains

233

Driving

in the ignition, but more force must be ap-
plied.

Progressive steering

Depending on the vehicle’s features, it may or
may not incorporate a progressive steering
system.

city traffic

you do not need to turn so much

on parking, manoeuvring or in very tight turns.

On the

road

or on the

motorway

, progressive

steering transmits, for example, in bends, a
sportier, more direct and noticeably more dy-
namic driving sensation.

Control lamp



It lights up red

Faulty steering.

Do not continue driving

, stop the vehicle as soon as

possible and in a safe manner.

Take the vehicle to a specialised workshop and have
the fault repaired as soon as possible.



It lights up yellow

Limited steering operation.

Drive carefully to a specialised workshop to have the
steering checked.
If the warning light does not come on again after re-

starting the engine and driving a short distance, it is

not

necessary to check the steering.

OR:

The 12-volt battery was disconnected and re-

connected.
Drive a short distance at 15-20 km / h (9-12 mph).



It flashes yellow

The steering column is jammed.

When stopped, turn the steering wheel in both direc-

tions.

OR:

The steering column does not unlock or lock.

Turn off the ignition and turn it on again. Consider the
messages shown on the instrument panel display.

Do not continue driving

if the steering column re-

mains locked after switching on the ignition. Seek
specialist assistance.

The control lamp should light up for a few
seconds when the ignition is switched on. It
should go out once the engine is started.

WARNING

Never ignore the warning lamps or messag-
es.

●

If the warning lamps and the correspond-

ing messages are ignored, the vehicle may
stall in traffic, causing serious damage or
accidents and injuries.

●

Stop the vehicle at the next opportunity

and in a safe place.

SEAT Drive Profiles

Introduction

The SEAT Drive Profile enables the driver to
choose between the

Eco

Normal

Sport

and

Individual

profiles, which modify the behav-

iour of several vehicle functions, providing dif-
ferent driving experiences.

In models fitted with adaptive chassis control
(DCC)
a

Comfort

profile is also available.

The

Individual

profile can be configured ac-

cording to personal preferences. The other
profiles have a fixed configuration.

Description

Depending on the equipment fitted in the ve-
hicle, SEAT Drive Profile can operate on the
following functions:

Engine

Depending on the profile selected, the engine
responds more quickly or smoothly to the ac-
celerator being pressed. When the

Eco

234

Start and driving

profile is selected, the Start-stop function is
activated.

In vehicles with automatic transmission, the
gear change timing is changed to put the
changes at higher or lower revolutions. The

Eco

profile activates the Inertia function,

thereby reducing consumption. The rest of
the driving profiles will activate the inertia use
function when the selector lever is not in the

position, depending on how the accelerator
pedal is released

›››

page 231

. When the ve-

hicle is turned on again, the function is activa-
ted by default to reduce consumption.

With manual transmission, the

Eco

profile

changes the gear change recommendations
to facilitate more efficient driving.

Dynamic chassis control (DCC)

The DCC continuously adapts the damping
of the suspension system to the characteris-
tics of the road surface and the driving situa-
tion (speed, acceleration and steering wheel
angle) according to the selected driving pro-
file. The vehicle's dynamic behaviour is also
adapted to improve grip on curves and turn-
ing capacity. Within the

Individual

profile you

can also adjust the DCC level in a custom-
ised manner.

In the event of a fault in the DCC, the follow-
ing message is displayed on the instrument
screen

Fault: shock absorber regula-

tion

Steering

The operation of the power steering is modi-
fied and adapted to the selected profile to of-
fer the best behaviour for each situation.

Air conditioning

The Climatronic can operate in

Eco

mode

with particularly limited consumption.

Adaptive Cruise Control (ACC)

Depending on the driving profile, the perform-
ance of the ACC to allow adaptation to a
speed that is more sporty or fuel consump-
tion-friendly.

PreCrash system

The PreCrash system adapts according to
the selected configuration

›››

page 24

The

Sport

driving profile has specific settings

to adapt to driving characteristics.

SEAT Drive Profile settings

There are several ways to select a driving
profile using the infotainment system:

●

Press the function button



> Drive Profile

available profiles will be displayed.

●

OR:

Press the function button



> Vehicle

settings > SEAT Drive Profile

, available pro-

files will be displayed.

●

OR:

Press the function button



, slide your

finger horizontally across the screen to

SEAT

Drive Profile

. Press on



to change the driv-

ing profile or double press on the icon to show
the available profiles.

●

OR:

When the infotainment system is off,

pressing on the

SEAT Drive Profile

icon dis-

plays the available driving profiles.

The icon of the selected profile is displayed
at all times in the upper central part of the in-
strument panel and on the Infotainment Sys-
tem screen when it is turned off

›››

page 89

Driving pro-

file

Characteristics



Places the vehicle in a low state
of consumption, facilitating a

fuel-saving driving style that is

respectful to the environment.



Convenience

It permits more relaxed and

comfortable driving, for example

for long motorway journeys.



Normal

Offers a balanced driving experi-

ence, suitable for everyday use.



Sport

Provides a complete dynamic

performance in the vehicle, ena-

bling the user a more sporty driv-

ing style.

235

Driving

Driving pro-

file

Characteristics



Individual

It allows you to personalise the
configuration. The functions that

can be adjusted depend on the
equipment fitted in the vehicle.

Only for models fitted with adaptive chassis control

(DCC).

Kick-down

The kick-down feature allows maximum ac-
celeration

›››

page 230

If the

Eco

profile has been selected in the

SEAT Drive Profile, and the accelerator is
pressed beyond a hard point, the engine
power is automatically controlled to give
your vehicle maximum acceleration.

WARNING

When operating SEAT Drive Profile, pay at-
tention to all traffic: doing otherwise could
cause an accident.

Note

●

Regardless of the driving profile selected

when the ignition is switched off, all sys-
tems will start up Normal mode. To select a
different driving profile, use the infotain-
ment system display.

●

Your speed and driving style must always

be adjusted to visibility, weather, and traf-
fic conditions.

●

The Eco profile is not recommended

when towing a vehicle.

Driving tips

Running in

Please observe the instructions for running-in
new components.

Running-in the engine

A new engine must be driven through a run-in
period during its first 1500 kilometres (1000
miles). During its first few hours of running, the
internal friction in the engine is greater than
later on when all the moving parts have bed-
ded down.

How the vehicle is driven for the first 1500 km
(1000 miles) influences the future engine per-
formance. Throughout the life of the vehicle, it
should be driven at a moderate speed (espe-
cially when the engine is cold) this will reduce
engine wear and increase its useful life. Never
drive at extremely low engine speeds. Always
engage a lower gear when the engine works
“irregularly”.

For the first 1000 km or

600 miles, please note:

●

Do not use full throttle.

●

Do not force the engine above two thirds of

its maximum speed.

●

Do not tow a trailer.

Between 1000 and 1500 kilometres (600
to 1000 miles)

gradually

increase power

until reaching the maximum speed and high
engine speeds.

Running in new tyres and brake pads

●

Replacement of wheel rims and new tyres

›››

page 345

●

Information about brakes

›››

page 270

For the sake of the environment

If the engine is run in gently, the life of the
engine will be increased and the engine oil
consumption reduced.

Economical and environmentally
friendly driving

Fuel consumption, environmental pollution
and wear to the engine, brakes and tyres all
depend largely on driving style. Consumption
can be reduced between 10-15% with an effi-
cient driving type. The following section gives
you some tips on lessening the impact on the
environment and reducing your operating
costs at the same time.

236

Start and driving

Active cylinder management (ACT®)

Depending on vehicle equipment, the active
cylinder management (ACT®) may deacti-
vate some of the engine cylinders if the driv-
ing situation does not require too much pow-
er. The number of active cylinders can be
seen on the instrument panel display.

›››

page 70

Foresight when driving

If you think ahead when driving, you will need
to brake less and thus accelerate less. Take
advantage of the inertia of the vehicle when-
ever possible, with a

gear engaged

. This

takes advantage of the engine braking effect,
reducing wear on the brakes and tyres. Emis-
sions and fuel consumption will drop to zero.

Changing gear to save energy

An effective way of saving is to change

in ad-

vance

to a higher gear.

Manual transmission

: shift up from first to

second gear as soon as possible. Choosing
the right gear enables fuel savings. Select the
highest possible gear appropriate for the
driving situation (the engine should continue
functioning with cyclical regularity).

Automatic transmission

: accelerate gradu-

ally and without reaching the “kick-down”
position.

Avoid driving at high speed

Avoid travelling at your vehicle’s top speed,
whenever possible. Fuel consumption, emis-
sion of harmful gases and noise pollution
multiply as speed is increased. Driving at
moderate speeds will help to save fuel.

Reduce idling time

In vehicles with the Start-Stop system idling is
automatically reduced. In vehicles without
the Start-Stop system it is worth switching off
the engine, for example, at level crossings
and at traffic lights that remain red for long
periods of time. When an engine has reached
operating temperature, and depending on
the cylinder capacity, keeping it switched off
for a minimum of about 5 seconds already
saves more than the amount of fuel necessa-
ry for restarting.

The engine takes a long time to warm up
when it is idling. Mechanical wear and pollu-
tant emissions are also especially high during
this initial warm-up phase. It is therefore best
to drive off immediately after starting the en-
gine. Avoid running the engine at high speed.

Regular maintenance

Regular servicing helps in saving fuel even
before the engine is started. A well-serviced
engine gives you the benefit of

improved fuel

efficiency

as well as maximum reliability and

an enhanced resale value. A badly serviced

engine can consume up to 10% more fuel
than necessary.

Avoid short journeys

The engine and catalytic converter need to
reach their optimal

operating temperature

in order to minimise fuel consumption and
emissions.

A cold engine consumes a disproportionate
amount of fuel. The engine reaches its work-
ing temperature after about four kilometres
(2.5 miles), when fuel consumption will return
to a normal level.

Check tyre pressure

Always make sure the tyres are inflated to the
correct pressures

›››

page 347

to save fuel. If

the pressure is below half bar, fuel consump-
tion may increase by 5%. Due to the greater
rolling resistance, under-inflation

also

increa-

ses tyre wear and impairs handling.

Do not use

winter tyres

all year round as

they increase fuel consumption by up to 10%.

Avoid carrying unnecessary loads

Given that every kilo of extra

weight

will in-

crease the fuel consumption, it is advisable
make sure that no unnecessary loads are be-
ing transported.

Since the luggage rack increases the

aero-

dynamic drag

of the vehicle, you should

237

Seat Leon (2022 year). Manual in english - page 14
