Seat Toledo (2019 year). Manual in english

The essentials

How it works

Unlocking and locking

Doors

Fig. 3

Remote control key: keys.

Fig. 4

Centre console: central locking switch.

Locking and unlocking the vehicle using
the key

●

Locking: press the button



›››

Fig. 3

●

Unlocking: press the button



›››

Fig. 3

●

Unlock rear lid: press the



›››

Fig. 3

button

until all the turn signals on the vehicle briefly
light up.

Locking and unlocking with the central
locking switch

●

Locking: press the button



›››

Fig. 4

. The

warning lamp on the button will light up. None
of the doors can be opened from the outside.
The doors can be opened from the inside by
pulling the inside door handle.

●

Unlocking: press the button



›››

Fig. 4

. The

warning lamp on the button will switch off.



›››

in Unlocking and locking the

vehicle on page 109



›››

page 108



›››

page 11

›››

page 12

Unlocking or locking of driver door

Fig. 5

Driver door lever: hidden lock cylinder.

If the central locking system should fail to op-
erate, the driver door can still be locked and
unlocked by turning the key in the lock.

●

Unfold the vehicle key shaft.

●

Insert the key shaft into the lower opening in

the cover on the driver door handle

›››

Fig. 5

(arrow) then remove the cover upwards.

●

Insert the key blade into the lock cylinder to

unlock or lock the vehicle.

Special characteristics

●

The anti-theft alarm will remain active

when vehicles are unlocked. However, it is not
triggered

›››



page 110

●

After the driver door is opened, you have 15

seconds to switch on the ignition. Once this
time has elapsed, the alarm is triggered.

The essentials

●

Switch the ignition on. The electronic immo-

bilizer recognises a valid vehicle key and de-
activates the anti-theft alarm system.

Note

The anti-theft alarm is not activated when
the vehicle is locked manually using the
key shaft

›››



page 110

Locking manually

Fig. 6

Rear door: emergency lock.

On the front of a door with no lock cylinder
there is an emergency locking device that is
only visible when the door is open.

Locking

●

Remove the cap

›››

Fig. 6

●

Insert the key in the slot

and turn it in the

direction of the arrow until horizontal (on the
other direction on the right-hand door).

●

Replace the cap.

Once the door has been locked, it can no
longer be opened from the outside. The door
can be opened again from the inside by pull-
ing the door handle.

Rear lid

Fig. 7

Rear lid: opening from the outside.

●

Opening the rear lid: pull on the release lev-

er and lift it up

›››

Fig. 7

. The rear lid opens

automatically.

●

Close the rear lid: hold it by one of the han-

dles on the interior lining and close it by push-
ing gently.



›››

in Opening and closing on

page 118



›››

page 117



›››

page 12

Manual release mechanism for the
rear lid

Fig. 8

Luggage compartment: access to man-

ual release.

The rear lid can be unlocked manually from
inside in the event of an emergency.

●

Insert the key in the opening in the lining of

the rear lid and move the key in the direction
of the arrow until the lock is released.

The essentials

Bonnet

Fig. 9

Unlocking the bonnet.

Fig. 10

Locking the bonnet.

Opening the bonnet

The bonnet is released from inside the vehi-
cle.

Before opening the bonnet, make sure that
the windscreen wiper arms are in place
against the windscreen.

●

Open the door and pull the lever under the

dashboard

›››

Fig. 9

●

To lift the bonnet: press the release catch

under the bonnet upwards

. The arrester

hook under the bonnet is released.

●

The bonnet can be opened. Release the

bonnet stay in the direction of the arrow

›››

Fig. 10

and secure it in the fixture de-

signed for this in the bonnet

Closing the bonnet

●

Slightly lift the bonnet.

●

Release the bonnet stay and replace it in its

support.

●

At a height of approximately 30 cm let it fall

so it locks.

If the bonnet does not close, do not press
downwards. Open it again and let it fall as
mentioned above.



›››

in Working in the engine com-

partment on page 245



›››

page 244

The essentials

Controls for the windows*

Fig. 11

Detail of the driver door: controls for

the windows.

●

Opening the window: press the button



●

Closing the window: pull the button



Buttons on the driver door

Window on the front left door
Window on the front right door
Window on the rear left door
Window on the rear right door
Safety switch for deactivating the electric
window buttons in the rear doors.



›››

in Operation of the electric win-

dows on page 119



›››

page 119

Before driving

Manually adjusting the front seats

Fig. 12

Front seats: manual seat adjustment.

Forwards/backwards: pull the lever and
move the seat.
Raising/lowering: pull/push the lever.
Tilt backrest: pull the lever back.



›››

in Introduction on page 131

Adjusting the head restraints

Fig. 13

Front seat: adjusting the head restraint.

Grab the sides of the head restraints with
both hands and push upwards to the desired
position. To lower it, repeat the same action,
pressing the

button on the side.



›››

in Head restraints on page 132



›››

page 61

›››

page 132

The essentials

Adjustment of the seat belt

Fig. 14

Positioning and removing the seat belt

buckle.

Fig. 15

Correct seat belt and head restraint

positions, viewed from front and the side.

To adjust the seat belt around your shoulders,
adjust the height of the seats.

The shoulder part of the seat belt should be
well centred over it, never over the neck. The
seat belt lies flat and fits comfortably on the
upper part of the body.

The lap part of the seat belt lies across the
pelvis, never across the stomach. The seat
belt lies flat and fits comfortably on the pel-
vis.



›››

page 64



›››

page 66

Seat belt tensioners

During a collision, the seat belts on the front
seats are retracted automatically.

The tensioner can be triggered only once.



›››

in Maintenance and disposal of

belt tensioners on page 68



›››

page 67

Adjusting the exterior mirrors

Fig. 16

Detail of the driver door: control for the

exterior mirror.

Adjusting the exterior mirrors: Turn the knob to
the corresponding position:

Turning the knob to the desired position,
adjust the mirrors on the driver side (L,

L/R

The essentials

left) and the passenger side (R, right) to
the direction desired.
Depending on the equipment fitted on
the vehicle, the mirrors may be heated
according to the outside temperature.



›››

in Exterior mirrors on page 130



›››

page 130

Adjusting the steering wheel

Fig. 17

Lever in the lower left side of the steer-

ing column.

Adjusting the position of the steering wheel:
pull the

›››

Fig. 17

lever down, move the

steering wheel to the desired position and lift
the lever back up until it locks.





›››

in Adjusting the steering wheel

position on page 59

Airbags

Front airbags

Fig. 18

Driver airbag in the steering wheel and

front passenger airbag in the dash panel

The essentials

Fig. 19

Airbag covers reacting when the front

airbags are triggered.

The front airbag for the driver is located in the
steering wheel

›››

Fig. 18



and the front pas-

senger airbag is located in the dash panel

›››

Fig. 18



. Airbags are identified by the

word “AIRBAG”.

When the driver and front passenger airbags
are deployed, the covers remain attached to
the steering wheel and dashboard, respec-
tively

›››

Fig. 19

In conjunction with the seat belts, the front
airbag system gives the driver and the front
passenger additional protection for the head
and chest in the event of a severe frontal col-
lision.

Their special design allows the controlled es-
cape of the propellant gas when an occu-
pant puts pressure on the bag. Thus, the
head and chest are protected by the airbag.
After the collision, the airbag deflates suffi-
ciently to allow visibility.



›››

in Front airbags on page 70

Deactivating the front passenger
front airbag

Fig. 20

Front passenger front airbag switch.

To deactivate the front passenger front
airbag:

●

Open the glove compartment on the front

passenger side.

●

Insert the key blade into the slot provided in

the deactivation switch.

●

Approximately ¾ of the length of the key

blade remains inserted (the maximum).

●

Turn the key blade, changing its position to



. Do not force it. If you have difficulty, en-

sure that you have inserted the key as far as it
will go.

●

Finally, check the control lamp on the in-

strument panel where it shows











the following should appear





›››

in Switch front passenger front

airbag on and off on page 73



›››

page 73

The essentials

Side airbags*

Fig. 21

Side airbag in driver's seat.

Fig. 22

Illustration of completely inflated side

airbag on left side of vehicle.

The side airbags are located in the driver's
seat and front passenger seat backrests

›››

Fig. 21

. The locations are identified by the

text “AIRBAG” in the upper region of the
backrests.

In conjunction with the seat belts, the side air-
bag system provides additional protection for
the upper body in the event of a severe side
collision

›››



page 63, The whys and

wherefores of seat belts

In a side collision, the side airbags reduce the
risk of injury to passengers to the areas of the
body facing the impact. In addition to the nor-
mal protection from the front seat belts, pas-
sengers are also held fast in the event of a
side collision, and this is how these airbags
provide maximum protection.



›››

in Side airbags* on page 71

Head-protection airbags*

Fig. 23

Location of head-protection airbags.

Fig. 24

Deployed head-protection airbags.

The head-protection airbags are located on
both sides in the interior above the doors

›››

Fig. 23

and are identified with the text “AIR-

BAG”.

In conjunction with the seat belts, the head-
protection airbag system gives the vehicle
occupants additional protection for the head
and upper body in the event of a severe side
collision

›››

page 18



›››

in Head-protection airbags* on

page 71

The essentials

Child seats

Important information regarding
the front passenger's airbag

Fig. 25

Passenger side sun blind.

Fig. 26

On the rear frame of the passenger

side door: adhesive in relation to the airbag.

A sticker with important information about the
passenger airbag is located on the passeng-
er's sun visor and/or on the passenger side
door frame.



›››

in Important information re-

garding the front passenger's airbag

on page 75



›››

page 75

Possible ways to secure child seats

You can secure a child seat to the rear seat or
front passenger seat in the following ways:

●

Child seats in groups

0 to 3

can be secured

with a seat belt.

●

Child seats for groups

0, 0+ and 1

can be

fastened without seat belts, using the “ISO-
FIX” and Top Tether* system, using the “ISO-
FIX” and Top Tether* securing rings

›››

page 20

Weight

group

Seat locations

Front

passen-

ger

Rear

outer

Rear

centre

Group 0
<10 kg

U/L

Group 0+

<13 kg

U/L

Group I

9-18 kg

U/L

Weight

group

Seat locations

Front

passen-

ger

Rear

outer

Rear

centre

Group II/III

15-36 kg

U: Suitable for universal approved restraining sys-

tems for use in this age category (universal retention

systems are those fitted using the adult seat belt).

L: Suitable for retention systems using the “ISOFIX”
and Top Tether* anchors.

Compliance with current national legislation and

the manufacturer's instructions is required when using
or installing child seats.

Move the front passenger seat as far back as possi-

ble, as high as possible and always disable the air-
bag.

The systems include the child restraint
system mounting with an upper retaining
strap (Top Tether) and lower anchoring
points on the seat.



›››

in Safety instructions on

page 76

The essentials

Securing child seats with “ISOFIX”
and Top Tether*

Fig. 27

ISOFIX securing rings.

Fig. 28

Top Tether* securing ring.

Child seats with the “ISOFIX” or Top Tether*
system can be secured quickly, easily and
safely on the rear outer seats.

When removing or fitting the child seat,
please be sure to follow the manufacturer's
instructions.

●

Move the rear seat as far to the rear as it

will go.

●

Press the child seat onto the “ISOFIX” re-

taining rings until the child seat can be heard
to engage. If the child seat is equipped with
Top Tether* anchor points, secure it to the
correspondent ring. Observe the manufactur-
er's instructions.

●

Pull on both sides of the child seat to ensure

that it is secure.

Two

“ISOFIX” retaining rings are fitted on both

outermost rear seats. In some vehicles, the
rings are secured to the seat frame and, in
others, they are secured to the rear floor. Ac-
cess to the “ISOFIX” rings is between the rear
seat backrest and the seat cushioning. The
Top Tether* rings are located at the rear of
the backrests of the rear seats (behind the
seat backrest or in the boot).

Child seats with the “ISOFIX” and Top Tether*
attachment system are available from Tech-
nical Services.



›››

in Safety instructions on

page 76

Starting the vehicle

Ignition lock

Fig. 29

Ignition key positions.

Turn on the ignition: place the key in the igni-
tion and start the engine.

Locking and unlocking the steering wheel

●

Lock the steering wheel: remove the key

from the ignition and turn the wheel until it
locks. In vehicles with automatic transmission,
in order to remove the key, move the gear
shift to the

position. If necessary, press the

gear shift blocking key and release it.

●

Unlock the steering wheel: put the key into

the ignition and turn it at the same time as the
steering wheel in the direction indicated by
the arrow. If it is not possible to turn the steer-
ing wheel, it may be because it is locked.

The essentials

Turning on/switching off the ignition, glow
plugs reheating

●

Turn on the ignition: turn the key to the

position.

●

Turn off the ignition: turn the key to the

position.

●

Diesel vehicles



: the glow plugs reheat

when the ignition is switched on.

Starting the engine

●

Manual transmission: press the clutch ped-

al all the way down and move the gearbox
lever into neutral.

●

Automatic transmission: press the brake

pedal and move the selector lever to the

position or into

●

Turn the key to the

position. The key au-

tomatically returns to the

position. Do not

press the accelerator.

Start-Stop system*

When you stop and release the clutch pedal,
the Start-Stop system* turns off the engine.
The ignition remains switched on.



›››

in Introduction on page 196



›››

page 196

Lights and visibility

Light switch

Fig. 30

Instrument console: light panel.

Turn the switch to the required position

›››

Fig. 30

Sym-

bol

Ignition

switched off

Ignition is

switched on



Fog lights, dipped

beam and side
lights off.

Light off or daytime
driving light on.



The “Coming
home” and “Leav-
ing home” guide
lights may be
switched on.

Automatic control of

dipped beam and
daytime running
light.



Side light on.



Dipped beam
headlight off

Dipped beam
switched on.



Fog lights:

move the switch to the first po-

sition, from positions









Rear fog light:

move the switch complete-

ly from positions







Turn on fog lights: push the switch or turn it to
the



position.



›››

in Introduction on page 120



›››

page 120

Turn signal and main beam lever

Fig. 31

Turn signal and main beam lever.

More the lever to the required position:

Right turn light: right-hand parking light
(ignition switched off).

The essentials

Left turn light: left-hand parking light (ig-
nition switched off).
Main beam on: control lamp



lit up on

the instrument panel.
Light flash: on with the lever pushed. Con-
trol lamp



lit up.

Lever all the way down to switch it off.



›››

page 122

Hazard warning lights

Fig. 32

Dashboard: switch for hazard warning

lights.

Switched on, for example:

●

When approaching a traffic jam

●

In an emergency

●

The vehicle has broken down

●

When towing or being towed



›››

page 125

Interior lights

Fig. 33

Detail of headliner: variant 1

Fig. 34

Detail of headliner: variant 2

Knob

Function



Switches interior lights off.



Switches interior lights on.



Switches door contact control on

(central position).

The interior lights come on automati-

cally when the vehicle is unlocked, a
door is opened or the key is removed
from the ignition.
The lights go off a few seconds after
all the doors are closed, the vehicle is
locked or the ignition is switched on.



Turning the reading light on and off



›››

page 126

The essentials

Windscreen wipers and window
wiper blade

Fig. 35

Operating the windscreen wiper and

rear wiper.

More the lever to the required position:



Windscreen wipers off.



Windscreen wipers interval wipe.
Using the control

›››

Fig. 35

adjust

the interval (vehicles without rain sen-

sor), or the sensitivity of the rain sensor.



Slow wipe.



Continuous wipe.





Short wipe. Brief press, short clean.

Hold the lever down for more time to in-

crease the wipe frequency.

More the lever to the required position:



Automatic wipe. The windscreen wash-
er function is activated by pushing the
lever forwards, and simultaneously the
windscreen wipers start.



Interval wipe for rear window. The wiper

will wipe the window approximately ev-
ery six seconds.



The rear window wash function is acti-

vated by pressing the lever, and the

rear wiper starts simultaneously.



›››

in Introduction on page 128



›››

page 128



›››

page 56

The essentials

Easy Connect

Menu settings:

Vehicle

Fig. 36

Easy Connect: Main menu.

Fig. 37

Easy Connect: CAR menu.

The actual number of menus available and
the name of the various options in these me-
nus will depend on the vehicle’s electronics
and equipment.

●

Switch the ignition on.

●

If the Infotainment System is off, switch it on.

●

Press the Infotainment button



and

then the

Vehicle

function button

›››

Fig. 36

, press the Infotainment button



to go to

the

Vehicle

›››

Fig. 37

●

Press the

SETTINGS

function button to open

the

Vehicle settings

menu.

●

To select a function in the menu, press the

desired button.

When the function button check box is activa-
ted



, the function is active.

Pressing the menu button



will always take

you to the last menu used.

Any changes made using the settings menus
are automatically saved on closing those
menus.

The essentials

Submenu

Possible setting

Description

ESC system

–

Activation of the Electronic Stability Programme (ESC)

›››

page 201

Tyres

Tyre monitor system

Tyre pressure storing (Calibration)

›››

page 260

Winter tyres

Activation and deactivation of the speed warning. Setting the speed warning
value

›››

page 261

Lights

Light assist

Motorway function, turning-on time, automatic lights when raining, one-touch
signalling.

›››

page 120

Vehicle interior lighting

Brightness of instrument panel and controls

›››

page 127

“Coming home/Leaving home”
function

Switch-on time of the “Coming home” and “Leaving home” functions

›››

page 124

Driver assistance

Front Assist (emergency brak-
ing assistance system)

Activation/deactivation: Front Assist, advance warning, distance warning dis-

play

›››

page 219

Fatigue detection

Activation/deactivation

›››

page 230

Parking and ma-
noeuvring

Parking and manoeuvring set-
tings

Automatically activate front volume, front sound treble, rear volume, rear sound
treble

›››

page 227

Ambient lighting

–

Background lighting, switch-off, colour

›››

page 127

Mirrors and wind-
screen wipers

Rear view mirrors

Activate/deactivate folding after parking

›››

page 130

Windscreen wipers

Activate and deactivate automatic wipe in case of rain, wipe when reversing

›››

page 23

Opening and clos-
ing

Electric windows control

Convenience open function, all, only driver

›››

page 119

Central locking

Unlocking doors, automatic lock when driving, interior monitoring

›››

page 110

Instrument panel

–

Current consumption, average consumption, convenience consumers, ECO
Advice, travelling time, distance travelled, average speed, digital speed dis-

play, speed warning, oil temperature, reset data “when setting off”, reset data
for “total calculation”

›››

page 28

Date and time

–

Time source, time, time zone, time format, date, date format

›››

page 100

The essentials

Submenu

Possible setting

Description

Units

–

Distance, speed, temperature, volume, fuel consumption, pressure

–

Service

–

Chassis number, date of next SEAT service inspection, date of next oil change
service

›››

page 33

Factory settings

All

Restore all settings

–

Individual

Restore factory settings for lights, driver assistance, parking and manoeuvring

WARNING

Any distraction may lead to an accident,
with the risk of injury. Operating the Easy
Connect system while driving could dis-
tract you from traffic.

Seat Toledo (2019 year). Manual in english - page 1
