Renault Zoe (2024 year). Manual in english

screen wash/wipe ......................................

(up to the end of the DU)

windscreen washer ....................................

(up to the end of the DU)

wipers ........................................................

(up to the end of the DU)

1.113

ENG_UD57724_1

Essuie-vitre / lave-vitre arrière (X10 - Renault)

REAR SCREEN WASH, WIPE

(1/2)

2 3

Efficiency of a wiper blade

Check the condition of the wiper

blades. How long they last depends

on you:
– it must remain clean: clean the

blade and the screen regularly

with soapy water;

– do not use it when the screen is

dry;

– free it from the screen when it has

not been used for a long time.

In all cases, replace it as soon as

it begins to lose efficiency: approxi-

mately once a year.

➥

5.21.

Precautions for using the

wipers

– In freezing or snowy weather

conditions, clear the screen

before starting the wipers (risk of

motor overheating);

– ensure that no objects are ob-

structing the travel of the blade.

To stop the operation, pivot ring

again.

Note:

when washing using a roller

type car wash, return the ring

on the

stalk

to the stop position to deactivate

automatic wiping.
Follow usage recommendations.

Rear screen wiper

With the ignition on, turn ring

on stalk

to align the symbol with

mark

–

switching off

– intermittent wiping

The wipers will pause for several

seconds between sweeps. Wiping

frequency varies with vehicle

speed;

–

slow continuous wiping

Do not use the wiper arm to open or

close the tailgate.

Before any action involving

the rear screen (washing

the vehicle, de-icing, clean-

ing, etc.) return stalk

the stop position.

Risk of injury and/or damage.

1.114

ENG_UD57724_1

Essuie-vitre / lave-vitre arrière (X10 - Renault)

REAR SCREEN WASH, WIPE

(2/2)

Activation/deactivation of the rear

screen wiper

Engaging reverse gear triggers inter-

mittent wiping (if the front wipers are in

operation). If your vehicle is equipped

with a vehicle settings customisation

menu, you can opt to activate or deacti-

vate this function.

➥

1.94.

For vehicles not fitted with a settings

customisation menu, you can have this

function deactivated by an authorised

dealer.

In the event of obstacles present on the

rear window (dirt, snow, etc.), the wiper

will try to sweep away all the obstacles.

If an obstacle prevents the blade from

moving, it can be stopped. Remove the

obstacle, wait for around 30 seconds

and reactivate the wiper using the wiper

stalk.

Precautions

– In the event of ice, check that the

blades are not stuck to the wind-

screen before operating the wipers.

If you activate the wiper while the

blade is blocked by ice, you risk dam-

aging both the blade and the wiping

motor.

– Do not operate the wipers on a dry

screen. This will lead to the prema-

ture wear or damage to the blades.

Rear screen wash/wipe

With the ignition on, push and

hold stalk

, then release.

Holding the stalk for longer will trigger

(in addition to the windscreen washer)

two sweeps of the wipers followed,

a few seconds later, by a third (drip

wiping function).
When the stalk is released, it returns to

the rear wipe position.

2.1

ENG_UD82782_9

Sommaire 2 (X10 - Renault)

Section 2: driving

(Advice on use relating to fuel economy and the environment)

Starting, stopping the engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.2

Gear control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.5

Electronic parking brake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.8

Environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.12

Driving advice, Eco-driving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.13

Vehicle range: advice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.16

Tyre pressure monitoring system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.18

Active emergency braking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.23

Driver correction devices and aids . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.30

Lane departure warning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.35

Lane keeping assist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.39

Blind spot warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.44

Detection of road signs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.49

Speed limiter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.53

Cruise control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.57

“AUTOHOLD” function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.62

Parking distance control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.63

Reversing camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.70

Assisted parking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.74

driving ........................................................

(up to the end of the DU)

starting .......................................................

(up to the end of the DU)

starting the engine .....................................

(up to the end of the DU)

starting the engine .....................................

(up to the end of the DU)

2.2

ENG_UD79530_4

Démarrage, arrêt du moteur (X10 - Renault)

Starting, stopping the engine

STARTING, STOPPING THE ENGINE

(1/3)

Starting the engine

The card must be inserted in detection

zone

To start

– depress the brake pedal;
– press button

. The message

READY comes on, on the instrument

panel, along with a beep.

The message disappears when the ve-

hicle speed is above approximately 3.1

mph (5 km/h).

Special features

– If one of the starting conditions is not

applied, the message “Press Brake

+ START” is displayed on the instru-

ment panel;

– in some cases, it will be necessary

to move the steering wheel whilst

pressing the start button

to help

unlock the steering column; the

message “Turn Steering Wheel +

START” will alert you.

The vehicle can only be started if

the charging cord is unplugged from

the vehicle.

2.3

ENG_UD79530_4

Démarrage, arrêt du moteur (X10 - Renault)

Operating faults

In certain cases, the hands-free card

may not work:
– the card battery is flat, the secondary

12 V battery is discharged etc.;

– near to appliances operating on the

same frequency as the card (moni-

tor, mobile phone, video game, etc.);

– vehicle located in a high electromag-

netic radiation zone.

The message “Place card on zone +

START” appears on the instrument

panel.
Press the brake pedal, then place the

card

(button side) on the placement

area

. Press the

button to start the

vehicle. The message goes out.

STARTING, STOPPING THE ENGINE

(2/3)

“Hands-free” starting with the

tailgate open

In this case, the card should not be lo-

cated in the luggage compartment, to

prevent the risk of loss.

Accessories function

(switching on the ignition)
Once you have gained access to your

vehicle, you may use some of its func-

tions (radio, navigation, wipers, etc.).
To use the other functions, with the

card in the passenger compartment,

press the

button without pressing the

pedals.

Driver’s responsibility

when parking or stopping

the vehicle

Never leave an animal,

child or adult who is not self-suffi-

cient alone in your vehicle, even for

a short time.
They may pose a risk to themselves

or to others by starting the engine,

activating equipment such as the

electric windows or locking the

doors, for example.
Also, in hot and/or sunny weather,

please remember that the tempera-

ture inside the passenger compart-

ment increases very quickly.

RISK OF DEATH OR SERIOUS

INJURY

stopping the engine ...................................

(current page)

2.4

ENG_UD79530_4

Démarrage, arrêt du moteur (X10 - Renault)

Stopping the engine

The vehicle must be at a standstill.
Press the

button: the engine stops,

the READY message goes out on

the instrument panel and the assisted

parking brake is applied. The steering

column is locked when the driver's door

is opened or the vehicle is locked.

STARTING, STOPPING THE ENGINE

(3/3)

If the card is no longer in the passen-

ger compartment or if the card’s battery

is dead, when the vehicle is stationary

and you try to switch the engine off,

the message “Keycard absent : press/

hold START” appears on the instrument

panel: press button

for longer than

three seconds.

With the engine switched off, any ac-

cessories being used (radio, etc.) will

continue to function for approximately

10 minutes.

When the driver’s door is opened, the

accessories stop working.

Never switch off the igni-

tion before the vehicle has

stopped completely. Once

the engine has stopped, the

brake servo, power-assisted steer-

ing, etc., and the passive safety de-

vices such as the airbags and pre-

tensioners will no longer operate.

Driver’s responsibility

when parking or stopping

the vehicle

Never leave an animal,

child or adult who is not self-suffi-

cient alone in your vehicle, even for

a short time.
They may pose a risk to themselves

or to others by starting the engine,

activating equipment such as the

electric windows or locking the

doors, for example.
Also, in hot and/or sunny weather,

please remember that the tempera-

ture inside the passenger compart-

ment increases very quickly.

RISK OF DEATH OR SERIOUS

INJURY

automatic gearbox (use) ............................

(up to the end of the DU)

changing gear ............................................

(up to the end of the DU)

speed control .............................................

(up to the end of the DU)

driving ........................................................

(up to the end of the DU)

gear lever...................................................

(up to the end of the DU)

reverse gear

selecting ...............................................

(up to the end of the DU)

2.5

ENG_UD79498_4

Commande de vitesses (X10 - Renault)

Gear control

GEAR CONTROL

(1/3)

: position accessible from the cur-

rent position by moving the selec-

tor lever

two notches forwards or

backwards.

The

symbols are displayed to in-

dicate the gears that can be selected. If

these symbols are absent this indicates

that the gears cannot be selected from

the current position.
The required gear will flash on the in-

strument panel if a gear is not acces-

sible from the engaged position of the

lever.

Operation

With the engine running READY mes-

sage lit on the instrument panel

➥

2.2,

the gear control is automatically in

position.
To exit position

, it is essential to de-

press the front brake pedal.
With your foot on the brake pedal

(warning light

on display

goes

out), move the lever out of position

The vehicle can only be started if

the charging cord is unplugged from

the vehicle.

Obstructions to the driver

On the driver’s side, only

use mats suitable for the

vehicle, attached with the

pre-fitted components, and check

the fitting regularly. Do not lay one

mat on top of another.

There is a

risk of wedging the pedals

Selector lever 1

reverse.

neutral.

moving off forwards normally.

moving off forwards with strong

regenerative braking.

The

indicator light displays the gear

engaged.
The following informative symbols may

appear on the instrument panel dis-

play

: position of the gear engaged;

: position accessible from the cur-

rent position by moving the selector

lever

one notch forwards or back-

wards;

2.6

ENG_UD79498_4

Commande de vitesses (X10 - Renault)

Driving in mode D

When you select position

when the

vehicle is stationary, the vehicle moves

forward as soon as you release the

brake pedal (without pressing on the

accelerator pedal).

While driving, press the accelerator

pedal to achieve the desired speed.

GEAR CONTROL

(2/3)

One-touch selector

Move the selector lever

one or two

notches forwards or backwards to

engage the desired position (

) then release the lever and it will

return to a stable position.
The selected position is displayed on

the instrument panel along with the

warning light in front of the position.
If certain conditions prevent shifting

from one position to another, the re-

quested position flashes on the instru-

ment panel.

Driving in mode B

This mode allows driving with a more

dynamic regenerative mode. When

releasing the accelerator, the vehicle

uses regenerative braking to slow down

the vehicle. Thus the motor generates

higher electrical current which allows

the traction battery to be recharged.

When you select position

when the

vehicle is stationary, the vehicle moves

forward as soon as you release the

brake pedal (without pressing on the

accelerator pedal).

mode, the regenerative braking will

be reduced if the accumulator is cold or

completely charged.

Move from D position to B or

B to D

To switch from one position to the other,

tilt the lever to one notch or two notches

backwards.

The selected position, lit up on the in-

strument panel, alongside warning

light

, will confirm the position of the

gear control.

The last selected position (

) is stored and will be the first of the two posi-

tions accessible from the current position

2.7

ENG_UD79498_4

Commande de vitesses (X10 - Renault)

Operating faults

During driving

– if the message “WARNING: Check

Gearbox” appears on the instrument

panel, this indicates a fault.
Contact your approved Dealer as

soon as possible;

– if the message “WARNING: Gearbox

Overheating” appears on the instru-

ment panel, stop as soon as possi-

ble to allow the gearbox to cool down

and wait for the message to disap-

pear.

GEAR CONTROL

(3/3)

In the event of an impact to

the underside of the vehicle

(e.g.: striking a post, raised

kerb or other street furni-

ture), this may result in damage to

the vehicle (e.g.: twisted axle), the

electrical circuit or the traction bat-

tery.
Do not touch the circuit elements or

any fluids or liquids.
To prevent any risk of accident,

have your vehicle checked by an

authorised dealer.

Risk of serious injury or electric

shock and risk to life.

To select reverse gear

With the vehicle stationary, engine run-

ning,

position,

engaged, de-

press the brake pedal and move for-

ward the lever by two notches,

lights

up on the instrument panel.
The reversing lights will illuminate as

soon as reverse gear is selected (igni-

tion on) and, depending on the vehicle,

the reversing camera

➥

2.70.

Note:

with the engine running, the ve-

hicle moving between 0 and 5 mph

(8 km/h) and position

engaged, it

is not necessary to depress the brake

pedal to engage the position

. This is

useful when parking manoeuvres re-

quire alternating forward and reverse

gearing.

Parking the vehicle

With the vehicle stationary, stop the

engine. Neutral position is engaged

and the electronic parking brake is ap-

plied automatically.

When the door is opened, the mes-

sage “Select NEUTRAL N” is dis-

played on the instrument panel

if the gear control is in a position

other than

and the engine is not

switched off.

The

position of the lever

does not mechanically lock

the drive wheels, make

sure it is immobilised before

leaving the vehicle.

stopping the engine ...................................

(up to the end of the DU)

driving ........................................................

(up to the end of the DU)

ignition switch ............................................

(up to the end of the DU)

handbrake..................................................

(current page)

parking brake .............................................

(up to the end of the DU)

electronic parking brake ............................

(up to the end of the DU)

indicators:

instrument panel ..................................

(up to the end of the DU)

instrument panel messages.......................

(up to the end of the DU)

instrument panel ........................................

(up to the end of the DU)

2.8

ENG_UD78576_6

Frein de parking assisté (X10 - Renault)

Electronic parking brake

ELECTRONIC PARKING BRAKE

(1/4)

Assisted operation

Applying the electronic parking

brake
With the vehicle

stationary, the elec-

tronic parking brake can be used to im-

mobilise the vehicle:

–

by pressing the engine start/stop

button

;

– when

the driver’s seat belt is un-

fastened

;

– when

the driver’s door is opened

;

– when

the engine is stopped

To confirm that the electronic parking

brake is applied, the message “Parking
Brake ON” and warning light

}

on the instrument panel and warning

light

on the switch

light up.

After the engine is switched off, indi-

cator light

goes out several minutes

after the assisted parking brake has
been applied and indicator light

}

goes out when the vehicle is locked.

Before leaving the vehicle, check that the electronic parking brake is fully
applied. Warning light

on switch

and warning light

}

on the in-

strument panel light up to show that the parking brake is applied but go

out when the doors are locked.

2.9

ENG_UD78576_6

Frein de parking assisté (X10 - Renault)

ELECTRONIC PARKING BRAKE

(2/4)

Manually releasing the electronic

parking brake

Press switch

without pressing the

pedals to switch the ignition on. Press

the brake pedal then press switch

: in-

dicator light

on the switch and indica-

tor light

}

displayed on the instru-

ment panel go out.

Manual operation

You can apply the electronic parking

brake manually.

Manually applying the electronic

parking brake

Pull switch

. Warning light

and warn-

ing light

}

on the instrument panel

light up.

Assisted operation

(continued)

Note:

in some situations (electronic

parking brake failure, manual release of

the parking brake, etc.), a beep sounds

and the message “WARNING: Apply

Parking Brake” appears on the instru-

ment panel to warn you that the elec-

tronic parking brake has been released.

– with the engine running: when the

driver’s door is opened;

– with the engine off: when a front door

is opened.

In this case, pull and release switch

apply the assisted parking brake.

Assisted release of the parking

brake

The brake will be released as soon as

the vehicle starts and accelerates.

Before leaving the vehicle, check that the electronic parking brake is fully applied. Warning light

on switch

and

warning light

}

on the instrument panel illuminate to show that the parking brake is applied but switch off when

the doors are locked.

2.10

ENG_UD78576_6

Frein de parking assisté (X10 - Renault)

ELECTRONIC PARKING BRAKE

(3/4)

Brief stop

To apply the electronic parking brake

manually (when stopping at a red light,

or stopping when the engine is running,

etc.): pull and release the switch

. The

brake is released as soon as the vehi-

cle is started up again.

Hill parking

When parking on a slope, pull the

switch

for a few seconds to enable

maximum application of the parking

brake.

To park, without applying the electronic

parking brake (if there is a risk of freez-

ing, for example):
– stop the engine by pressing the

engine Start/Stop button

;

–  release the driver’s seat belt;
–  open the driver’s door;
–  if necessary, position a chock in front

of or behind the wheels to ensure

that the vehicle is immobilised;

– manually release the electronic park-

ing brake (please see the informa-

tion on “Manually releasing the elec-

tronic parking brake” on the previous

page). The message “WARNING:

Apply Parking Brake” is displayed on

the instrument panel accompanied

by a beep to warn you that it is re-

leased (this is normal);

– close the driver’s door and lock the

vehicle.

When parking on a slope

in conditions such as mud,

snow or ice, it is possi-

ble that the vehicle may

become displaced. Turn the wheels

so that the vehicle comes to rest

against a robust object (pavement

kerb, etc.).

operating faults ..........................................

(current page)

controls

gear ......................................................

(current page)

faults

operating faults ....................................

(current page)

2.11

ENG_UD78576_6

Frein de parking assisté (X10 - Renault)

Operating faults

– If there is a fault, the

warning

light illuminates on the instrument

panel accompanied by the mes-

sage “Check Parking Brake” and in
some cases the

}

warning light

appears. Contact your approved

Dealer straight away.

– If there is an assisted parking brake

fault, the warning light

comes on, along with the message

“WARNING: Braking System”, a

beep and, in some cases, the warn-
ing light

}

This means that you must stop as

soon as traffic conditions allow.

Never leave your vehicle

without moving the selec-

tor lever to position

, ap-

plying the handbrake and

switching off the engine. This is be-

cause when the vehicle is stationary

with the engine running and a gear

engaged, the vehicle may begin to

move if you accelerate.

There is a risk of accidents.

If no lights or sounds are ap-

parent, this indicates a fault

in the instrument panel. This

indicates that it is essential

to stop immediately (as soon as traf-

fic conditions allow). Ensure that the

vehicle is correctly immobilised and

contact an approved Dealer.

If the message “WARNING:

Electric System” or “Check

battery” is displayed, you

must immobilise the vehicle

by pulling the switch

for approxi-

mately 10 seconds. If the slope and

the conditions require it, chock the

wheels of the vehicle.

Risk of loss of immobilisation of

the vehicle.

Call an approved Dealer.

ELECTRONIC PARKING BRAKE

(4/4)

For safety reasons, automatic release

is deactivated when the driver’s door

is open or not shut properly and the

engine is running (in order to prevent

the vehicle from moving without the

driver). The “Release Parking Brake

Manually” message appears on the

instrument panel when the driver de-

presses the accelerator.

environment ...............................................

(up to the end of the DU)

2.12

ENG_UD82776_2

Environnement (X10 - Renault)

Environment

ENVIRONMENT

Your vehicle has been designed with

respect for the

environment

in mind for

its entire service life: during production,

use and at the end of its life.

Manufacture

Your vehicle has been manufactured at

a factory which complies with a policy

to reduce the environmental impact

on the surrounding areas (reduction of

water and energy consumption, visual

and noise pollution, atmospheric emis-

sions and waste water; sorting and re-

using waste).

Emissions

Your vehicle has been designed to

emit fewer greenhouse gases (CO2)

while in use, and therefore to consume

less fuel (e.g. 160.9 g/mile (100 g/km),

equivalent to 67.25 mpg (4.2 l/100 km)

for a petrol vehicle). Our vehicles are

also equipped with an emission control

system including a catalytic converter,

an oxygen sensor and an active carbon

filter (the latter prevents vapour from

the fuel tank being released into the

open air).

Please make your own

contribution towards

protecting the environment

too

– Parts and vehicles at the end of their

life must not be thrown away. They

must be handed to a legal entity that

complies with environmental stand-

ards.

– Worn parts replaced in the course of

routine vehicle maintenance (vehi-

cle battery, oil filter, air filter, batter-

ies, etc.) and oil containers (empty or

filled with used oil) must be disposed

of at dedicated collection points.

– To optimise the recycling of your ve-

hicle at the end of its life, you can

contact an authorised dealer or visit

the manufacturer’s website to be di-

rected to collection points that guar-

antee respect for the environment

complying with local laws.

Recycling

Your vehicle is 85% recyclable and

95% recoverable.
To achieve these objectives, many of

the vehicle components have been de-

signed to enable them to be recycled.

The materials and structures have

been carefully designed to:
– allow these components to be easily

removed and reprocessed by spe-

cialist companies;

– promote a circular economy (re-use,

recycling, recovery, etc.).

This is particularly true for electrified

vehicle batteries.
In order to preserve raw material re-

sources, your vehicle also includes

many parts made from recycled plas-

tics or renewable materials.

range of the traction battery.......................

(up to the end of the DU)

vehicle range .............................................

(up to the end of the DU)

driving recommendations ..........................

(up to the end of the DU)

ECO driving ...............................................

(up to the end of the DU)

charge meter .............................................

(current page)

energy saving ............................................

(up to the end of the DU)

energy

range ....................................................

(up to the end of the DU)

energy

charge meter (function) ........................

(current page)

2.13

ENG_UD74755_3

ECO conduite (X10 - Renault)

Driving advice, Eco-driving

DRIVING ADVICE, ECO-DRIVING

(1/3)

Optimum use zone 0

Indicates nil consumption.

Green “recommended

consumption” B usage zone

The traction battery supplies the elec-

trical energy required for the motor to

move the vehicle.

“Consumption not recommended”

white use zone C

Indicates high energy consumption.

Charge meter

(on the instrument panel)
The charge meter gives the driver a

real-time view of the vehicle’s energy

consumption.

Blue “Energy recovery” A usage

zone

When driving, if you lift your foot off the

accelerator pedal or apply the brake,

the motor generates electrical current

during deceleration, and this energy is

used to slow down the vehicle and re-

charge the traction battery.

Consumption in real time depends on

vehicle usage conditions, equipment

fitted and the user’s driving style. To op-

timise fuel consumption, please refer to

the following advice.
Depending on the vehicle, you will be

provided with functions which enable

you to lower the energy consumption:

– charge meter;

– the driving style indicator;

– the journey record and eco-driving

advice via the multimedia screen;

– ECO mode, activated by the

ECO

button.

If fitted on the vehicle, the navigation

system provides additional information.

The presence and display of this in-

formation depends on the type of

ambiance selected

➥

1.82.

2.14

ENG_UD74755_3

ECO conduite (X10 - Renault)

Press the

switch to access the

indicator menu, then confirm by press-

ing

“

”.

Journey record

For vehicles fitted with this, once the

engine is switched off, a Journey

Record is displayed on the multimedia

screen

. This record shows the infor-

mation relating to your last journey:

– average energy consumption;

– number of miles/kilometres travelled;

Driving style indicator

Informs you about the driving style

adopted in real time. This is shown by

indicator light

The more petals displayed on

, the

more your driving is flexible and eco-

nomical.

If you regularly monitor this indicator,

you will reduce your vehicle’s fuel con-

sumption.

To activate/deactivate

the driving style

indicator, press switch

as many times

as necessary to reach the Data tab.

DRIVING ADVICE, ECO-DRIVING

(2/3)

– an overall grade taking into account

acceleration, braking anticipation

and your skill in managing speed;

– advice to enable you to improve your

rating.

For more information, refer to the equip-

ment user guide.

Navigation system

Using the information available on your

navigation system (traffic information,

nearest charging station, etc.) makes it

easy to manage your journey.

Renault Zoe (2024 year). Manual in english - page 8
