Renault Megane RS (2012 year). Instruction

sun visor ................................................................(current page)

courtesy mirrors .....................................................(current page)

3.16

ENG_UD18902_3

Eclairage intérieur (X95 - B95 - D95 - Renault)

ENG_NU_837-6_BDK95_Renault_3

luggage compartment light 9

Depending on the vehicle, light 9,

comes on when the luggage compart-

ment is opened.

Sun visor

INTERIoR lIghTINg

(2/2)

/SuN VISoR

Sun visor

Lower the sun visor 7 over the wind-

screen or unclip it and turn it over the

side window.

courtesy mirrors

Slide cover 8, depending on the vehi-

cle, and the mirror is lit.

glove box light 6

Light 6 comes on when the cover is

opened.

storage compartments ..........................(up to the end of the DU)

storage compartment............................(up to the end of the DU)

fittings ...................................................(up to the end of the DU)

3.17

ENG_UD11880_3

Rangements / aménagements habitacle (X95 - B95 - D95 - Renault)

ENG_NU_837-6_BDK95_Renault_3

Passenger compartment storage space and fittings

Door pockets 1

PASSENgER coMPARTMENT SToRAgE SPAcE AND FITTINgS

(1/4)

Nothing should be placed

on the floor area in front of

the driver as such objects

may slide under the pedal

during braking manoeuvres, thus

obstructing its use.

Driver and passenger

underfloor storage

compartments 2

This storage compartment can be used

to hold the vehicle documentation, etc.

Sun visor storage 3

This can be used for storing motorway

tickets, cards, etc.

Ensure that no hard, heavy

or pointed objects are

placed in the “open” storage

compartments in such a

way that they may fall onto passen-

gers during sudden turning, braking

or in the event of an accident.

armrest:

front ..................................................................(current page)

3.18

ENG_UD11880_3

Rangements / aménagements habitacle (X95 - B95 - D95 - Renault)

ENG_NU_837-6_BDK95_Renault_3

centre console storage

compartments 6

Front centre armrest storage

compartment A

Press button 4 and lift the cover 5.

PASSENgER coMPARTMENT SToRAgE SPAcE AND FITTINgS

(2/4)

Passenger storage

compartment

Pull handle 7 to open it.
The glove box can hold A4-size docu-

ments, a large bottle of water, etc.
The storage compartment is ventilated

and refrigerated.

Ensure that no hard, heavy

or pointed objects are

placed in the “open” storage

compartments in such a

way that they may fall onto passen-

gers during sudden turning, braking

or in the event of an accident.

glove box ...............................................................(current page)

3.19

ENG_UD11880_3

Rangements / aménagements habitacle (X95 - B95 - D95 - Renault)

ENG_NU_837-6_BDK95_Renault_3

Door pockets 8

Storage compartment 9

PASSENgER coMPARTMENT SToRAgE SPAcE AND FITTINgS

(3/4)

Rear armrest storage

Lower armrest 12 and, depending on

the vehicle, lift cover 11 using unlock-

ing handle 10.

3.20

ENG_UD11880_3

Rangements / aménagements habitacle (X95 - B95 - D95 - Renault)

ENG_NU_837-6_BDK95_Renault_3

PASSENgER coMPARTMENT SToRAgE SPAcE AND FITTINgS

(4/4)

Rear centre console storage

compartments 16

Depending on the vehicle, storage

compartment 16 may be replaced

by air vents; refer to Section 3 “Air

vents”.

Front seat storage

compartments 15

clothes hooks 13

grab handle 14

This offers support and can be held

when the vehicle is being driven.
Do not use it for getting into or out of

the vehicle.

ashtray ..................................................(up to the end of the DU)

cigar lighter ...........................................(up to the end of the DU)

accessories socket ...............................(up to the end of the DU)

3.21

ENG_UD11881_2

Cendriers-Allume cigares (X95 - B95 - D95 - Renault)

ENG_NU_837-6_BDK95_Renault_3

Accessories socket

Ashtray/cigar lighter

cigar lighter 1

With the ignition on, push in cigar

lighter 1, it will spring back with a click

when it is ready. Pull it out to use. After

use, replace it without pushing it all the

way in.

AShTRAY, cIgAR lIghTER, AccESSoRIES SockET

Accessories sockets

You may use cigar lighter recess 1 or

socket 3 (depending on the vehicle).

They are designed for connecting ac-

cessories with a maximum power rating

of 120 Watts (voltage: 12V) which

have been approved by our Technical

Department.

If your vehicle is not fitted with a cigar lighter and an ashtray, these can be ob-

tained from an approved Dealer.

Ashtray 2

To open, lift the cover. To empty, pull the

ashtray towards you and it will be re-

leased from its housing.

Connect accessories

with a maximum power of

120 Watts only.
Fire hazard.

rear bench seat.....................................(up to the end of the DU)

rear seats

functions .........................................(up to the end of the DU)

3.22

ENG_UD17358_5

Banquette arrière (X95 - B95 - D95 - Renault)

ENG_NU_837-6_BDK95_Renault_3

Press button 1 and lower the

seatback(s) A.

Rear bench seat

To fold down the seatback
Ensure that the front seats are far

enough forward.
Lower the rear headrests (refer to the

information on the “Rear headrests” in

Section 1).
Place the seat belts 2 in their guides 3.

Sport tourer versions

Depending on the vehicle, seatback A

can be folded down on its own to allow

long or bulky objects to be transported.

REAR BENch SEAT

(1/3)

For safety reasons, carry

out any adjustments when

the vehicle is not being

driven.

Before moving the seat-

back, put seat belt 2 in belt

guide 3 to avoid damaging

it.

3.23

ENG_UD17358_5

Banquette arrière (X95 - B95 - D95 - Renault)

ENG_NU_837-6_BDK95_Renault_3

REAR BENch SEAT

(2/3)

luggage compartment carpet level

adjustment
To adjust the level of the luggage com-

partment carpet in line with the seat-

backs, lift carpet 4 via the rear door;

height adjuster 5 is deployed automat-

ically. Fit the luggage compartment

carpet and unfold blanking covers 6.
When refitting the bench seat, push the

booster seat in at the same time as fit-

ting the luggage compartment carpet.

when refitting the seat-

back, make sure it is cor-

rectly locked in place.

If seat covers are fitted,

make sure these do not prevent the

seatback latch from locking in.

Make sure that the seat belts are

positioned correctly.

Reposition the headrests.

3.24

ENG_UD17358_5

Banquette arrière (X95 - B95 - D95 - Renault)

ENG_NU_837-6_BDK95_Renault_3

when refitting the seat-

back, make sure it is cor-

rectly locked in place.

If seat covers are fitted,

make sure these do not prevent the

seatback latch from locking in.

Make sure that the seat belts are

positioned correctly.

Reposition the headrests.

The seat and the seatback may be

folded away to allow bulky objects to be

carried.

To fold away the seat base
Tilt seat base B against the front seats.
To fold down the seatback
After folding the seat base down,

remove the rear headrests (refer to the

section on “rear headrests”) then press

button 1 and lower the seatback(s) C.

In all situations, remove the rear

headrests (refer to the informa-

tion on the “Rear headrests” in

Section 1).

For safety reasons, carry

out any adjustments when

the vehicle is not being

driven.

REAR BENch SEAT

(3/3)

When moving the rear

bench seat, ensure that

nothing obstructs the an-

chorage points (part of the

body, a pet, gravel, cloth, toys, etc.).

tailgate ..................................................(up to the end of the DU)

3.25

ENG_UD6321_1

Coffre à bagages (X95 - B95 - D95 - Renault)

ENG_NU_837-6_BDK95_Renault_3

Tailgate

TAIlgATE

To open
Press button 1 and lift the tailgate.
To close
Pull down the tailgate using handle 2

inside the tailgate to assist you.

opening manually from

inside the vehicle

Special note:
If it is impossible to unlock the tailgate,

it can be done from inside.
– access the luggage compartment by

folding forward the seatback(s) of

the rear bench seat,

– insert a pencil or similar object in

cavity 3 and slide the unit as shown

in the illustration,

– push the tailgate to open it.

rear parcel shelf ....................................(up to the end of the DU)

tailgate ..................................................(up to the end of the DU)

rear parcel shelf ....................................(up to the end of the DU)

3.26

ENG_UD11750_2

Tablette arrière (X95 - B95 - D95 - Renault)

ENG_NU_837-6_BDK95_Renault_3

Removal

Unhook the two cords 1 (tailgate side).

Rear parcel shelf

Do not place any objects,

especially heavy or hard

objects, on the parcel shelf.

These may pose a risk to

the vehicle occupants if the driver

has to brake suddenly or if the vehi-

cle is involved in an accident.

Lift rear parcel shelf 2 slightly and pull it

towards you.
To refit it, proceed in reverse order to

removal.

REAR PARcEl ShElF

Unclip mountings 3 on either side of

the parcel shelf, then remove the parcel

shelf via the luggage compartment.
To refit it, proceed in the reverse order

to removal.

luggage compartment cover .................(up to the end of the DU)

rear parcel shelf ....................................(up to the end of the DU)

3.27

ENG_UD12306_1

Cache-bagages : versions break (X95 - B95 - D95 - K95 - Renault)

ENG_NU_837-6_BDK95_Renault_3

To remove the flexible

section of the luggage cover

Pull handle 1 gently to release the pins

from their mounting points located on

each side of the luggage compartment.
Guide the luggage cover onto the roller.

Luggage compartment cover: sport tourer versions

Removing the luggage cover

Push the luggage compartment cover

to the left (movement A) and lift the

right-hand side of the inertia reel (move-

ment B).
To refit the luggage compartment cover,

insert the left-hand side, then push it to

the left (movement A) and lower the

right-hand side of the inertia reel into its

housing.

luggAgE coMPARTMENT coVER: sport tourer versions

(1/2)

Do not place any heavy or solid objects on the luggage cover. These may

pose a risk to the vehicle occupants if the driver has to brake suddenly or

if the vehicle is involved in an accident.

3.28

ENG_UD12306_1

Cache-bagages : versions break (X95 - B95 - D95 - K95 - Renault)

ENG_NU_837-6_BDK95_Renault_3

luggage compartment cover

storage

From the rear doors, lower the bench

seat seatback (refer to information on

the “Rear bench seat” in section 3).
Lift the luggage compartment carpet 2

and secure it by attaching straps 3 onto

hooks 4.

luggAgE coMPARTMENT coVER: sport tourer versions

(2/2)

Store luggage compartment cover 6

behind the booster seat 5 in the dedi-

cated storage compartment.

storage compartments ..........................(up to the end of the DU)

tailgate ..................................................(up to the end of the DU)

3.29

ENG_UD18945_5

Rangements / aménagements coffre à bagage (X95 - B95 - D95 - Renault)

ENG_NU_837-6_BDK95_Renault_3

Anchorage points

(Three- and five-seater versions)
Hooks 2 located on each corner of the

luggage compartment, allow the load to

be secured.

Luggage compartment storage space and fittings

luggAgE coMPARTMENT SToRAgE SPAcE AND FITTINgS

(1/3)

Storage under carpet 1

(depending on vehicle)
To open, fold back carpet A.

Always place objects being trans-

ported so that the heaviest items

are resting against the back of the

rear bench seat.

Side straps

Side straps 3 are located either side of

the luggage compartment, and can be

used to store an oil can.

3.30

ENG_UD18945_5

Rangements / aménagements coffre à bagage (X95 - B95 - D95 - Renault)

ENG_NU_837-6_BDK95_Renault_3

luggAgE coMPARTMENT SToRAgE SPAcE AND FITTINgS

(2/3)

Storage under carpet

(sport tourer version)
To access storage compartments 7,

fold back section B using handle 4 and,

depending on the vehicle, lift flap 6.

Anchorage points

(sport tourer version)
Hooks 5, located on either side of the

luggage compartment, allow the load to

be secured.

3.31

ENG_UD18945_5

Rangements / aménagements coffre à bagage (X95 - B95 - D95 - Renault)

ENG_NU_837-6_BDK95_Renault_3

luggAgE coMPARTMENT SToRAgE SPAcE AND FITTINgS

(3/3)

Separating the luggage

compartment

(sport tourer version)
The loading area can be separated.
Turn locks 8 situated on either side of

the luggage compartment to the first

notch. Lift divider C using handle 4,

when the bolts make contact, push the

divider and it will lock.
Maximum weight: 20 kg.

On the back there is an elastic strip 9 to

hold small objects vertically in position.

Always place objects being trans-

ported so that the heaviest items

are resting against the back of the

rear bench seat.

Renault Megane RS (2012 year). Instruction - part 9
