Renault Koleos (2018 year). Instruction - part 5

1.66

ON-BOARD COMPUTER: trip settings

(3/5)

The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.

Examples of selections

Interpreting the display selected

On-board computer with mileage-

before-service message

c) Mileage before service or oil change.

Mileage before service

With the ignition switched on, the engine not running and

the display set to “Service Intervals”, press button OK for ap-

proximately 5 seconds to display the mileage before service (dis-

tance or time to the next service). When the range approaches

its limit, there are several possible scenarios:

–

distance/time remaining less than 900 miles (1,500 km) or

one month: the message “Service due in” is displayed along

with the nearest limit (distance or time);

–

range equal to 0 km/miles or service date reached: the

message “Service required” is displayed accompanied by
warning light

The vehicle requires a service as soon as possible.

Service Intervals

Service in

30 000 Kms / 12 mo

Service due in

300 Kms / 24 days

Service required

Resetting: to reset the distance before service, press and hold button 2 for approximately 10 seconds until the display shows

the mileage permanently.
NB: if a service is performed without changing the engine oil, only the mileage before the next service should be reset. In the

event of an oil change, both the distance before the next service and the next oil change should be reset.

1.67

The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.

ON-BOARD COMPUTER: trip settings

(4/5)

Examples of selections

Interpreting the display selected

On-board computer with distance before

next service message (cntd.)

c) Mileage before service or oil change.

Mileage before service

With the ignition switched on and the engine not running,

and the selected display is “Mileage before service”, press

button OK for about 5 seconds to display the mileage before

the next service, then press button 2 to view the mileage before

the next oil change (distance or time remaining before the next

service). When the range approaches its limit, there are several

possible scenarios:

–

distance/time remaining less than 900 miles (1,500 km) or

one month: the message “Service due in” is displayed, ac-

companied by the nearest term (distance or time);

–

range equal to 0 km/miles or service date reached: the

message “Service required” is displayed accompanied by
warning light

The vehicle requires an oil change as soon as possible.

Service Intervals

Oil change in

30 000 Kms / 24 mo

Service due in

300 Kms / 24 days

Service required

Depending on the vehicle, the mileage before an oil change varies according to the driving style (frequent driving at low speed,

door-to-door journeys, extensive use at idling speed, towing a trailer, etc.). The distance remaining until the next oil change can

therefore decrease more quickly in some cases than the actual distance travelled.
Resetting: to reset the mileage before a service, press and hold button 2 for approximately 10 seconds until the display shows

the range permanently.

NB: if a service is performed without changing the engine oil, only the mileage before the next service should be reset. In the

event of an oil change, both the distance before the next service and the next oil change should be reset.

1.68

ON-BOARD COMPUTER: trip settings

(5/5)

The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.

Examples of selections

Interpreting the display selected

d) Reset the tyre pressure.

Refer to the information on the “Tyre pressure monitor-

ing system” in Section 2.

Tyre pressure

No message

memorised

e) Trip log.

Successive display:
–

information messages (passenger airbag OFF etc.);

–

operating fault messages (Check injection system,

etc.).

1.69

TRIP COMPUTER AND WARNING SYSTEM: information messages

Examples of messages

Interpreting the display selected

« Parking brake on »

Indicates that the parking brake has been applied.

« Checking control functions »

Displayed with the ignition on when the vehicle is running self-diagnostics.

« Turn steering wheel + START »

Turn the steering wheel slightly whilst pressing the vehicle start button to unlock

the steering column.

« Steering wheel not locked »

Indicates that the steering column has not been locked.

These can help in the vehicle starting phase, or give information about a selection or a driving status.

Examples of information messages are given in the following pages.

1.70

TRIP COMPUTER AND WARNING SYSTEM: operating fault messages

These appear with the

warning light and mean that you should drive very carefully to an authorised dealer as

soon as possible. If you fail to follow this recommendation, you risk damaging your vehicle.

They disappear when the display selection key is pressed or after several seconds and are stored in the computer log. The

warning light stays on. Examples of operating fault messages are given in the following pages.

Examples of messages

Interpreting the display selected

« Clean diesel filter »

Indicates the presence of water in the diesel filter; contact an approved Dealer

as soon as possible.

« Check lighting »

Indicates a fault in the headlights.

« Check vehicle »

Indicates a fault in one of the pedal sensors, battery management system or oil

level sensor.

« Check airbag »

Indicates a fault in the restraint system in addition to the seat belts. In the event

of an accident, it is possible that they may not be triggered.

« Check anti-pollution system »

Indicates a fault in the vehicle’s particle filter system.

1.71

TRIP COMPUTER AND WARNING SYSTEM: warning message

These appear with the

warning light and require you to stop immediately, for your own safety, as soon as traf-

fic conditions allow. Stop your engine and do not restart it. Contact an approved Dealer.

Some examples of warning messages are given below. Note: the messages appear on the display either individually or al-

ternately (when there are several messages to be displayed), and may be accompanied by a warning light and/or a beep.

Examples of messages

Interpreting the display selected

« Engine failure hazard »

Indicates an injection fault, the vehicle’s engine has overheated or there is a

serious engine fault.

« Power steering fault »

Indicates a fault in the steering or a problem with the four-wheel drive.

“Braking system fault” or ”Stop vehicle” Indicates a fault in the braking system. Apply the electronic parking brake ma-

nually and ensure that the vehicle is immobilised using a chock.

« Electric failure DANGER »

Indicates a fault in the vehicle battery charging circuit (alternator etc.).

« Puncture »

Indicates a puncture on the tyre displayed on the instrument panel.

1.72

VEHICLE SETTINGS CUSTOMISATION MENU

(1/2)

Adjusting the settings
(depending on the vehicle)
Select the function to modify:
a) unlocking the driver’s door only;
b) automatic locking of the doors while

driving;

c) hands-free function;
d) indicator audio volume;
e) internal welcome sound;
f) external welcome;
g) reading lamp in automatic mode;
h) rear windscreen wiping in reverse

gear;

i) configuration of the driving style indi-

cator;

j) Active noise control.
Select “ON” or “OFF” to activate or de-

activate the function.
For the “Light brightness intensity”

function, select the intensity by press-

ing “+” or “-”.

Depending on the vehicle equipment,

this function allows you to activate/de-

activate and adjust some of the vehi-

cle’s functions.

Vehicles fitted with a

navigation system

Accessing the settings menu
With the vehicle at a standstill, using

the multifunction screen 1, select menu

“Vehicle”, “User settings” to access the

various settings.

For safety reasons, carry

out any adjustments when

the vehicle is stationary.

1.73

VEHICLE SETTINGS CUSTOMISATION MENU

(2/2)

function activated

function deactivated

Once a line has been selected, press

the switch 3 OK to adjust the function.

If you select either “Parking assist” or

“Language”, you will have to make a

further selection (sound volume of the

parking distance control or instrument

panel language). In this case, make

your selection and confirm it by holding

the switch 3 OK – the selected value is

shown by a

in front of the line.

To exit the menu, press the control 4

upwards or downwards. It may be nec-

essary to carry out this operation sev-

eral times.

Vehicles not fitted with a

navigation system

Accessing the settings menu on

display 2
With the vehicle at a standstill, press

and hold the switch 3 OK to access the

settings menu.

Adjusting the settings

(depending on the vehicle)
Browse using the control 4 to select the

function to adjust:
a) Language;
b) Vehicle speed unit;
c) Unlocking the driver’s door only;
d) Lock doors when in motion;
e) Use handfree card;
f)  Rear wipers when reverse is ON;
g) Flashers volume;
h) Welcome lights;
i)  Automatic cabin lights;
j) Parking assist;
k) Parking assist audio volume;
l)  Lane departure volume;
m) Lane departure sensitivity;
n) Lane departure vibration;
p) Active braking;
q) Automatic main beam lights.

The vehicle settings personalisation

menu cannot be used when driv-

ing. At speed exceeding 12 mph

(20 km/h), the instrumental panel

display switches automatically back

to trip computer and warning system

mode.

1.74

Power-assisted steering

Variable power-assisted steering
The variable power assisted steering

system is equipped with an electronic

control system which alters the level of

assistance to suit the vehicle speed.
Steering is made easier during parking

manoeuvres (for added comfort) while

the force needed to steer increases

progressively as the speed rises (for

enhanced safety at high speeds).

STEERING WHEEL, POWER-ASSISTED STEERING (1/2)

For safety reasons, only

adjust the steering wheel

when the vehicle is station-

ary.

Never leave the steering wheel at

full lock while stationary.

Do not switch off the engine

when driving downhill and,

as a general rule, when

driving (the power-assisted

steering and brake cannot operate

normally).

With the engine switched off, or if

there is a system fault, it is still pos-

sible to turn the steering wheel. The

force required will be greater.

Adjusting the steering wheel

height and depth

Lower the lever 1 and position the

steering wheel in the required position.
Then, raise the lever fully, beyond the

point of resistance to lock the steering

wheel.
Make sure that the steering wheel is

correctly locked.

1.75

Activating the function
With the ignition on, press the switch 3

, the warning light integrated in the

switch lights up.

Deactivating the function
- Automatic:
The function switches off automati-

cally after the regulation phase of ap-

proximately 30 minutes. The warning

light integrated in the switch 3 re-

mains on.

Note: If the function has switched off

automatically, press the switch 3 twice

to reactivate it.
If switch 3 is not pressed again, the

function will be reactivated the next

time the ignition is switched on.
- Manually:
To deactivate the function during the

regulation phase, press the switch 3.

The indicator light in the switch 3

goes out.

STEERING WHEEL, POWER-ASSISTED STEERING (2/2)

Steering wheel heating

(depending on the vehicle)
This function heats the steering wheel

in areas 2.

Operating principle
When the temperature is reached, the

function regulates the temperature of

the heated areas for approximately

30 minutes and then switches off auto-

matically.

1.76

CLOCK AND EXTERIOR TEMPERATURE

External temperature

indicator

Special note:
When the exterior temperature is - 3 °C

to + 3 °C, the °C characters flash (sig-

nalling a risk of ice on the road).

Display 1

Vehicles fitted with a touchscreen

multimedia screen, navigation aid

systems, etc.
The time and exterior temperature are

displayed on the multifunction screen 1.
Refer to the handbook for the equip-

ment.

External temperature

indicator
As ice formation is related

to climatic exposure, local

air humidity and temperature, the

external temperature alone is not

sufficient to detect ice.

If the electrical supply is cut (battery

disconnected, broken supply wire,

etc.), the clock will automatically

go back to the right time after a few

minutes once the system is capable

of receiving information GPS.

1.77

Welcome and goodbye function

(depending on the vehicle)
From the multifunction screen, select

menu “Vehicle”, “User settings”,

“External welcome” and activate or de-

activate the function (ON or OFF).

REAR VIEW MIRRORS

(1/2)

Folding rear view mirrors

The door mirrors automatically fold in

when the vehicle is locked using the

button on the RENAULT card or remote

“Hands-free” locking. In this case, when

the engine is started, the door mirrors

fold out.
In any case, you can make the door

mirrors fold in or fold out with switch 1.

If the switch 1 is pressed, automatic

mode is deactivated. To reactivate the

automatic mode, press the switch 1

again.

Exterior rear view mirrors

Adjustment
Select the door mirror using the

switch 2, then use the control 3 to

adjust it to the desired position.

Heated door mirrors
Mirror de-icing is carried out at the

same time as rear screen de-icing.
Please refer to the information

on “Manual air conditioning” and

“Automatic climate control” in Section 3.

The driver’s door mirror

may have two clearly de-

fined zones. Zone A shows

what can normally be seen

in an ordinary rear view mirror.

Zone B increases rear side visibility.
Objects in the mirror are closer

than they appear.

For safety reasons, carry

out any adjustments when

the vehicle is not being

driven.

1.78

REAR VIEW MIRRORS

(2/2)

Interior rear view mirror

Its position can be adjusted.

Rear-view mirror with lever 4
For night driving, to avoid being dazzled

by the headlights of the car behind you,

flip the small lever 4 located behind the

rear view mirror.

Rear view mirror without lever 4
The rear-view mirror darkens automati-

cally at night if you are being followed

by a vehicle with its lights on.

1.79

Main beam headlights

With the dipped beam head-

lights lit, push stalk 1. This indicator

light on the instrument panel comes on.
To return to the dipped headlight posi-

tion, pull the stalk 1 towards you again.

EXTERIOR LIGHTING AND SIGNALS

(1/5)

Side lights

Turn ring 3 until the symbol is

opposite mark 2. This indicator light on

the instrument panel comes on.

Dipped beam

headlights

Manual operation
Turn ring 3 until the symbol is opposite

mark 2. This indicator light on the in-

strument panel comes on.

Automatic operation
Turn ring 3 until the AUTO symbol is op-

posite mark 2: with the engine running,

the dipped beam headlights switch on

or off automatically depending on the

brightness of the light outside, without

any action on stalk 1.

Before driving at night:

check that the electrical

equipment is operating cor-

rectly. As a general precau-

tion, check that the lights are not

obscured (by dirt, mud, snow or ob-

jects being transported).

When driving on the left in a left-

hand drive vehicle (or vice versa),

drivers must readjust their lights

throughout their stay (see “Adjusting

headlight beams” in Section 1).

1.80



Automatic main beam

headlights

Depending on the vehicle, this system

switches the main beam headlights on

and off automatically. The function uses

a camera located behind the interior

rear-view mirror to detect vehicles that

are following and coming in the oppo-

site direction.
The main beam headlights come on au-

tomatically if:

– exterior light is weak;

– no other vehicles or lighting are de-

tected;

– the vehicle speed is above approxi-

mately 30 mph (40 km/h).

If any of the above conditions are not

fulfilled, the system switches to dipped

beam headlights.

The “automatic main beam

headlights” system should

under no circumstances be

used to replace driver atten-

tion and responsibility with regard

to vehicle lighting and adapting to

light, visibility and traffic conditions.

Using the portable naviga-

tion system at night in the

windscreen area below the

camera may disturb the op-

eration of the “automatic main beam

headlights” system (risk of reflection

on the windscreen).

The system may encounter difficul-

ties under certain conditions, inclu-

ding:

– extreme weather conditions (rain,

snow, fog, etc.);

– obstruction in front of the wind-

screen or camera;

– when a following or oncoming ve-

hicle has weak or hidden lighting;

– incorrect settings for the front

headlights;

– reflective systems;

– ...

Activation

Turn ring 3 until the AUTO symbol is op-

posite mark 2.

Push stalk 1 to activate the main beam

headlights. The warning light



comes on on the instrument panel.

Deactivation

– Move stalk 1 towards you again;

– or turn ring 3 to a position other than

AUTO ;

– or, depending on the vehicle, on

the multifunction screen: select the

“Vehicle” menu, followed by “Driving

assistance”, “Automatic main beam

lights”, then choose “OFF".

Warning light



goes out on the

instrument panel.

EXTERIOR LIGHTING AND SIGNALS

(2/5)

1.81

Operating faults
When the message “Check auto

lighting” appears on the instrument

panel, the system is deactivated.
Consult an approved dealer.

EXTERIOR LIGHTING AND SIGNALS

(3/5)

Switching off the lights

There are two possibilities:
– manually, move ring 3 to position 0;
– automatically, the lights will go out

when the engine is switched off, the

driver’s door is opened or the vehicle

is locked. In this case, the next time

the engine is started the lights will be

switched back on according to the

position of the ring 3.

Lights-on reminder buzzer

A warning beep sounds when the driv-

er’s door is opened to warn you that the

lights are still on.

Daytime running lights

function

The daytime running lights come on

automatically with no action on stalk 1

when the engine is started, and they go

off once the engine is switched off.

Operating faults

When the message “Check lighting”
with warning light

is displayed

and warning light

flashes on the

instrument panel, this indicates that

there is a lighting fault.

Consult an approved dealer.

Content .. 3 4 5 6 ..
