Renault Koleos (2018 year). Instruction - part 3

1.34

CHILD SAFETY: General information

(1/2)

Carrying children

Children, and adults, must be correctly

seated and strapped in for all journeys.

The children being carried in your vehi-

cle are your responsibility.
A child is not a miniature adult. Children

are at risk of specific injuries as their

muscles and bones have not yet fin-

ished growing. The seat belt alone

would not provide suitable protection.

Use an approved child seat and ensure

you use it correctly.
Please ensure that you comply with the

legislation of your country.

A collision at 30 mph

(50 km/h) is the same as fall-

ing a distance of 10 metres.

Transporting a child without

a restraint is the equivalent of allow-

ing him or her to play on a fourth-

floor balcony without railings.

Never travel with a child held in your

arms. In the event of an accident,

you will not be able to keep hold of

the child, even if you yourself are

wearing a seat belt.

If your vehicle has been involved in

a road accident, replace the child

seat and have the seat belts and

ISOFIX anchorage points checked.

To prevent the doors being

opened, use the “Child

safety” device (refer to the

information on “Opening

and closing the doors” in Section 1).

Driver’s responsibility

when parking or stopping

the vehicle
Never leave an animal,

child or adult who is not self-suffi-

cient alone on your vehicle, even for

a short time.
They may pose a risk to themselves

or to others by starting the engine,

activating equipment such as the

electric windows or by locking the

doors.
Also, in hot and/or sunny weather,

please remember that the tempera-

ture inside the passenger compart-

ment increases very quickly.
RISK OF DEATH OR SERIOUS

INJURY.

1.35

CHILD SAFETY: General information

(2/2)

Using a child seat

The level of protection offered by the

child seat depends on its ability to re-

strain your child and on its installation.

Incorrect installation compromises the

protection it offers the child in the event

of harsh braking or an impact.
Before purchasing a child seat, check

that it complies with the regulations for

the country you are in and that it can

be fitted in your vehicle. Consult an ap-

proved dealer to find out which seats

are recommended for your vehicle.
Before fitting a child seat, read the

manual and respect its instructions. If

you experience any difficulties during

installation, contact the manufacturer

of the equipment. Keep the instructions

with the seat.

Set a good example by always fas-

tening your seat belt and teaching

your child:

–  to strap themselves in correctly;

–  to always get in and out of the car

at the kerb, away from busy traf-

fic.

Do not use a second-hand child

seat or one without an instruction

manual.
Check that there are no objects in

the vicinity of the child seat which

could impede its operation.

Never leave a child unat-

tended in the vehicle.
Check that your child is

always strapped in and that

the belt or safety harness used is

correctly set and adjusted. Avoid

wearing bulky clothing which could

cause the belts to slacken.
Never let your child put their head or

arms out of the window.
Check that the child is in the correct

position for the entire journey, espe-

cially if asleep.

1.36

CHILD SAFETY: choosing a child seat

Rear-facing child seats

A baby’s head is, proportionally, heavier

than that of an adult and its neck is very

fragile. Transport the child in this po-

sition for as long as possible (until the

age of 2 at the very least). It supports

both the head and the neck.

Choose a bucket type seat for best side

protection and change it as soon as the

child’s head is higher than the shell.

Forward-facing child seats

The child’s head and abdomen need to

be protected as a priority. A forward-fac-

ing child seat which is firmly attached to

the vehicle will reduce the risk of impact

to the head. Ensure your child travels in

a forward-facing seat with a harness for

as long as their size permits.

Choose a bucket type seat for optimum

side protection.

Booster cushions

From 15 kg or 4 years, the child can

travel using a booster seat, which will

enable the seat belt to be adapted to

suit his/her size and shape. The boos-

ter seat cushion must be fitted with

guides to position the seat belt on the

child’s thighs rather than the stomach.

It is recommended that you use a seat-

back fitted with a belt strap guide which

can be adjusted in terms of height to

position the seat belt in the centre of the

shoulder. It must never rest on the neck

or on the arm.

Choose a bucket type seat for optimum

side protection.

1.37

Attachment using the ISOFIX

system
Authorised child seats ISOFIX are

standardised in accordance with cur-

rent regulations. If any of the five cases

below applies:

–  ISOFIX universal 3-point forward-

facing seat;

–  ISOFIX semi-universal 2-point seat;

– Specific;

i-Size which has:

–  either a belt which attaches to the

third ring of the sear concerned;

–  or a support leg that rests on the ve-

hicle floor, compatible with the ap-

proved seat i-Size, the role of which

is to prevent the child seat from

moving in the event of a collision.

In the latter three cases check that your

child seat can be installed by consulting

the list of compatible vehicles.
Attach the child seat with the ISOFIX

locks, if these are provided. The ISOFIX

system allows quick, easy, safe fitting.
The ISOFIX system consists of 2 rings

and, in some cases, a third ring.

CHILD SAFETY: choosing a child seat mounting

(1/2)

There are two ways of attaching child

seats: via the seat belt or using the

ISOFIX system.

Attachment via the seat belt

The seat belt must be adjusted to

ensure that it is effective in the event of

harsh braking or an impact.

Ensure that the strap paths indicated

by the child seat manufacturer are re-

spected.

Always check that the seat belt is cor-

rectly fastened by pulling it up, then

pulling it out fully whilst pressing on the

child seat.

Check that the seat is correctly held by

moving it from side to side and back

to front: the seat should  remain firmly

fixed.

Check that the child seat has not been

installed at an angle and that it is not

resting against a window.

No modifications may be

made to the component

parts of the restraint system

(ISOFIX seat belts, seats

and their mountings) originally fitted.

The seat belt must never

be twisted or the tension

relieved. Never pass the

shoulder strap under the

arm or behind the back.

Check that the seat belt has not

been damaged by sharp edges.

If the seat belt does not operate nor-

mally, it will not protect the child.

Consult an approved dealer. Do not

use this seat until the seat belt has

been repaired.

Do not use the child seat

if it may unfasten the seat

belt restraining it: the base

of the seat must not rest on

the buckle and/or catch of the seat

belt.

Before using an ISOFIX

child seat that you pur-

chased for another vehicle,

check that its installation is

authorised. Consult the list of ve-

hicles which can be fitted with the

seat from the equipment manufac-

turer.

1.38

CHILD SAFETY: choosing a child seat mounting

(2/2)

3

The third ring 3 or 4 is used to attach

the upper strap on some seats ISOFIX.

The ISOFIX anchorage

points have been exclu-

sively designed for child

seats with the ISOFIX

system. Never fit a different type of

child seat, seat belt or other objects

to these anchorage points. Check

that nothing is obstructing the an-

chorage points.
If your vehicle has been involved in

a road accident, have the ISOFIX

anchorage points checked and re-

place your child seat.

Attachment using the ISOFIX

system (continued)

The two rings 1 are located between

the seatback and the seat base of the

seat and are identified by a marking.

To ensure your child seat can be easily

fitted and locked on the rings 1, use

access guides 2 on the child seat.

To access the rings, insert your finger in

the cover and pull.

Depending on the vehicle, you can find

the rings 1 when its cover is opened.
Note: Keep the covers you have re-

moved in a storage compartment so as

not to lose or damage them.

The rings are located on the rear seat-
backs and indicated by the symbol



.

In all cases, attach the strap hook to the

corresponding ring 3 and 4 and place

the seat in the desired position.
Pull the belt so that the back of the child

seat comes into contact with the back

of the vehicle seat.

The child seat strap must

be attached to the corre-

sponding ring.
Do not use any other

mounting point.

1

2

4

1.39

CHILD SAFETY: fitting a child seat, general information

(1/2)

In the front seat
The laws concerning children travel-

ling in the front passenger seat differ in

every country. Consult the legislation in

force and follow the indications on the

diagram on the following page.
Before fitting a child seat in this seat (if

authorised):

–  lower the seat belt as far as possible;

–  move the seat as far back as possi-

ble;

–  gently tilt the seatback away from

vertical (approximately 25°);

–  on equipped vehicles, raise the seat

base as far as possible.

In all situations, reinsert the headrest to

its full extent so that it does not interfere

with the child seat (see the information

on “Front headrests” in Section 1);

Some seats are not suitable for fitting

child seats. The diagram on the follow-

ing page shows you how to attach a

child seat.
The types of child seats indicated may

not be available. Before using a differ-

ent child seat, check with the manufac-

turer that it can be fitted.

Fit the child seat in a rear

seat wherever possible.
Check that when installing

the child seat in the vehicle

it is not at risk of coming loose from

its base.
If you have to remove the headrest,

check that it is correctly stored so

that it does not come loose under

harsh braking or impact.
Always attach the child seat to the

vehicle even if it is not in use so that

it does not come loose under harsh

braking or impact.

RISK OF DEATH OR

SERIOUS INJURY: before

fitting a rear-facing child

seat to this seat, check

that the air bag has been deacti-

vated (refer to the information on

“Child safety: deactivating/activat-

ing the front passenger air bag” in

Section 1).

After installing the child seat, if neces-

sary, the seat may be advanced (so as

to leave enough space in the rear seats

for passengers or other child seats).

For a rear-facing child seat, do not let

it touch the dashboard or move it to the

furthest forward position.
Do not change other settings after in-

stalling the child seat.

1.40

Fit the child seat in a rear

seat wherever possible.

In the rear side seat
A carrycot can be installed across the

vehicle and will take up at least two

seats.

Position the child with their feet nearest

the door.

Move the front seat as far forward as

possible to install a rear-facing child

seat, then move back the seat in front

as far as it will go, although without al-

lowing it to come into contact with the

child seat.
For the safety of a child facing forwards,

move the seat in front of the child as

far forward as possible, remember-

ing to move the seatback forwards to

avoid contact between the seat and the

child’s legs.
In all situations, remove the rear head-

rests (refer to the information on the

“Rear headrests” in Section 3). This

must be done before fitting the child

seat.

Check that the forward-facing child seat

is resting against the back of the vehi-

cle seat.

CHILD SAFETY: fitting a child seat, general information

(2/2)

Ensure that the child seat

or the child’s feet do not

prevent the front seat from

locking correctly. Refer to

the information on the “Front seat”

in Section 1.

When fitting a child seat

(Group 2 or 3 booster seat),

check that the seat belts op-

erate (wind) correctly: refer

to Section 1 “Rear seat belts”. If

necessary, adjust the position of the

vehicle seat.

1.41

CHILD SEATS: attachment by seat belt

(1/3)

RISK OF DEATH OR

SERIOUS INJURY: Before

installing a child seat on the

front passenger seat, check

that the airbag has been deacti-

vated (please refer to “Child safety:

front passenger airbag deactivation

and activation” in Section 1).

Using a child safety system

which is not approved for

this vehicle will not correctly

protect the baby or child.

They risk serious or even fatal injury.

³

  Check the status of the airbag

before fitting a child seat or allowing a

passenger to use the seat.

²

Seat not suitable for fitting

child seats.

Child seat attached using the belt

¬

  Seat which allows a child seat

with “Universal” approval to be attached

by a seat belt.

1.42

CHILD SEATS: attachment by seat belt

(2/3)

Type of child seat

Weight of the child

Front passenger

seat (1) (2)

Rear side seats

Rear centre

seat

Without airbag

or with airbag

deactivated

With airbag

activated

C a r r y c o t   f i t t e d

across the vehicle

Group 0

< 10 kg

X

X

U (3)

X

Rear-facing shell

seat

Groups 0 or 0 +

< 10 kg and < 13 kg

U

X

U (4)

U (6)

Shell seat/rear-facing

seat

Groups 0+ and 1

< 13 kg and 9 to 18 kg

U

X

U (4)

U (6)

Forward-facing seat

Group 1

9 to 18 kg

U

X

U (4) (5)

U (6)

Booster seat

Groups 2 and 3

15 to 25 kg and 22 to

36 kg

U

U

U (4) (5)

U

(1) RISK OF DEATH OR SERIOUS INJURY: Before installing a child seat on the front passenger seat, check that

the airbag has been deactivated (please refer to “Child safety: front passenger airbag deactivation and activation” in

Section 1).

The table below summarises the information already shown on the diagram on the previous page, to ensure the applica-

ble regulations are respected.

1.43

X =  Seat not suitable for fitting child seats of this type.
U  =  Seat which allows a child seat with “Universal” approval to be installed using a seat belt; check that it can be fitted.
(2) Raise the seat to the maximum and position it as far back as possible, tilting the seatback slightly (approximately 25°).
(3)  A carrycot can be installed across the vehicle and will take up at least two seats. Position the child with his or her feet nearest

the door.

(4) Move the seat in front of the child forwards, move the seatback forward to avoid contact between the seat and the child’s legs.
(5)  In all situations, remove the rear headrest of the seat on which the child seat is positioned. This must be done before fitting the

child seat. Please refer to the information on the “Rear headrests” in Section 3.

CHILD SEATS: attachment by seat belt

(3/3)

(6) RISK OF DEATH OR SERIOUS INJURY: A child seat with a support leg must never be fitted.

1.44

Type of child seat

Weight of

the child

Seat size ISOFIX

Front passenger

seat

Rear side seats

Rear centre seat

Carrycot fitted across

the vehicle

Group 0

< 10 kg

F, G

X

X

X

Rear-facing shell

seat

Groups 0 or 0 +

< 10 kg and

< 13 kg

E

X

IL (1)

X

Shell seat/rear-facing

seat

Groups 0+ and 1

< 13 kg and 9 to

18 kg

C, D

X

IL (1)

X

Forward-facing seat

Group 1

9 to 18 kg

A, B, B1

X

IUF - IL (2)

X

Booster seat

Groups 2 and 3

15 to 25 kg and

22 to 36 kg

-

X

IUF - IL (2)

X

Seat i-Size

X

i-U

X

CHILD SEATS: attachment using the ISOFIX system

(1/3)

The table below summarises the information already shown in the diagram on the following pages, to ensure the appli-

cable regulations are respected.

1.45

CHILD SEATS: attachment using the ISOFIX system

(2/3)

X =  Seat not suitable for fitting child seats ISOFIX.
IUF/IL =   On equipped vehicles, seat which allows an approved “Universal/semi-universal” or “vehicle specific” child seat to be at-

tached using the ISOFIX system; check that it can be fitted.

i-U = Suitable for the i-Size restraint devices in the “Universal” forward-facing and backward-facing category.
(1)  Move the front seat as far forward as possible to install a rear-facing child seat, then move back the seat in front as far as it will

go, although without allowing it to come into contact with the child seat.

(2)  In all situations, remove the rear headrest of the seat on which the child seat is positioned. This must be done before fitting the

child seat. Please refer to the information on the “Rear headrests” in Section 3. Move the seat in front of the child forwards,

move the seatback forward to avoid contact between the seat and the child’s legs.

The size of the ISOFIX child seat is indicated by a letter:
–  A, B and B1: for forward-facing seats in group 1 (9 to 18 kg);
–  C and D: shell seat or rear-facing seats in group 0+ (less than 13 kg) or group 1 (9 to 18 kg);
–  E: rear-facing shell seats in group 0 (less than 10 kg) or 0+ (less than 13 kg);
–  F and G: cots in group 0 (less than 10 kg).

1.46

CHILD SEATS: attachment using the ISOFIX system

(3/3)

Child seat fitted using the  ISOFIX

mounting

ü

 Seat which allows a ISOFIX child

seat to be attached.

±

 The rear seats are fitted with

an anchorage point which allows a

forward-facing ISOFIX child seat with

universal approval to be attached. The

anchorage points are located on the

backs of the rear seats.

Using a child safety system

which is not approved for

this vehicle will not correctly

protect the baby or child.

They risk serious or even fatal injury.

²

Seat which does not allow a

child seat to be fitted.

check the status of the airbag before fit-

ting a child seat or allowing a passen-

ger to use the seat.

1.47

CHILD SAFETY: deactivating, activating the front passenger air bag (1/3)

Deactivating the front

passenger airbags

(on equipped vehicles)
Before fitting a child seat on the front

passenger seat you must deactivate

the passenger airbag.

1

2

The passenger air bag must

only be deactivated or acti-

vated with the ignition off.

If it is interfered with when

the vehicle is being driven, indicator

lights

å

 and

©

 will come

on.

Switch the ignition off then on again

to reset the air bag in accordance

with the lock.

To deactivate the  airbags: with the

vehicle stopped and the ignition off,

push and turn lock 1 to the OFF posi-

tion.
With the ignition on, you must check

that the warning light

]

 on the dis-

play 2 is lit up and, depending on the

vehicle, that the message “airbag pas-

senger deactivated” is displayed.
This light remains permanently lit to

let you know that you can fit a child

seat.

1.48

3

DANGER
Since operation of the front

passenger airbag is not

compatible with the position

of a rear-facing child seat, NEVER

fit a restraint system for a rear-fac-

ing child in a seat protected by an

ACTIVATED front AIRBAG. This

can cause the CHILD’S DEATH or

SERIOUS INJURY.

The markings on the dashboard and

labels A on each side of passenger sun

blind 3 (example: label shown above)

remind you of these instructions.

A

A

CHILD SAFETY: deactivating, activating the front passenger air bag (2/3)

1.49

CHILD SAFETY: deactivating, activating the front passenger air bag (3/3)

The passenger airbag must

only be deactivated or acti-

vated when the vehicle is

stationary.

If it is interfered with when the ve-

hicle is being driven, indicator lights

å

 and

©

 will come on.

Switch the ignition off then on again

to reset the airbag in accordance

with the lock position.

2

Activating the front

passenger air bags

You should reactivate the airbags as

soon as you remove the child seat from

the front passenger seat to ensure the

protection of the front passenger in the

event of an impact.

Operating faults

It is forbidden to fit a rear-facing child

seat to the front passenger seat if the

airbags activation/deactivation system

is faulty.
Allowing any other passenger to sit in

that seat is not recommended.
Contact your approved dealer as soon

as possible.

To reactivate the  airbags: with the

vehicle stopped and the ignition off,

push and turn lock 1 to the ON position.
With the ignition switched on, you must

check that the warning light

]

 is

out and that the warning light





comes on the display 2 after each start-

up for around 60 seconds.
The front passenger seat belt additional

restraint systems are activated.

1
