Renault Espace (2016 year). Instruction - part 19

6.5

ENGINE SPECIFICATIONS

Versions

1.6 Tce

1.6 dCi

Engine type

(see engine plate)

M5M Turbo

R9M

Cubic capacity (cc)

1 618

1 598

Type of fuel

Octane rating

It is essential that you use unleaded petrol of the

octane rating stated on the label inside the fuel

filler flap.

If not available, for a limited time only, use un-

leaded fuel:
– with an octane rating of 91 for a label showing

95 or 98;

– with an octane rating of 87 for a label showing

91, 95 or 98.

Diesel

The label located in the fuel filler flap

indicates authorised fuels.

Spark plugs

Only use the spark plugs specified for your vehi-

cle’s engine.

The type should be marked on a label affixed

inside the engine compartment. If it is not then

contact an approved Dealer.

Fitting spark plugs which are not to specification

may damage the engine.

–

6.6

WEIGHTS (in kg)

The weights indicated are for a basic vehicle without options: they may vary depending on your vehicle’s equipment.

Consult an approved Dealer.

Maximum Permissible All-Up Weight (MMAC)

Gross Train Weight (MTR)

Maximum permissible all-up weight (MMTA)

Weights are indicated on the vehicle identification plate (refer

to the information on “Vehicle identification plates” in Section 6)

Braked Trailer Weight*

found by calculating: MTR - MMAC

Unbraked Trailer Weight*

750

Permissible nose weight*

Permissible load on the roof with the carrying device

80 kg (including the carrying device)

* Towing weight (towing a caravan, boat, etc.)
Towing is prohibited when the MTR - MMAC calculation is equal to zero, or when the MTR is equal to zero (or is not listed) on the

identification plate.

– It is important to comply with the towing weights, governed by local legislation in each country and, in particular, laid down in

the Road Traffic Regulations. Contact an approved Dealer about any towing equipment.

– When towing, under no circumstances may the total train weight (vehicle + trailer) be exceeded. However the following is

permitted:

– rear axle MMTA exceeded by no more than 15%,

– maximum MMAC exceeded by no more than 10% or 100 kg (whichever is reached first).

In either case, the maximum speed of the towing assembly must not exceed 60 mph (100 km/h) and the tyre pressure must be

increased by 0.2 bar (3 PSI).

– The engine output and climbing capability are reduced with altitude. You need to reduce the total train weight by 10% at an al-

titude of 1,000 metres and by an additional 10% for each 1,000 metres thereafter.

6.7

Original parts are based on strict specifications and are subject to highly-specialised tests. Therefore, they are of at least the same

level of quality as the parts fitted originally.
If you always fit genuine replacement parts to your vehicle, you will ensure that it performs well. Furthermore, repairs carried out

within the manufacturer’s Network using original parts are guaranteed according to the conditions set out on the reverse of the

repair order.

REPLACEMENT PARTS AND REPAIRS

6.8

Date: Miles (Km): Invoice number:

Comments/miscellaneous

Type of operation:

Stamp

Service □
....................................... □
Anti-corrosion check:
OK □ Not

OK*

□

*See specific page

Date: Miles (Km): Invoice number:

Comments/miscellaneous

Type of operation:

Stamp

Service □
....................................... □
Anti-corrosion check:
OK □ Not

OK*

□

*See specific page

Date: Miles (Km): Invoice number:

Comments/miscellaneous

Type of operation:

Stamp

Service □
....................................... □
Anti-corrosion check:
OK □ Not

OK*

□

*See specific page

VIN: ..................................................................................

SERVICE SHEETS

(1/6)

6.9

SERVICE SHEETS

(2/6)

VIN: ..................................................................................

Date: Miles (Km): Invoice number:

Comments/miscellaneous

Type of operation:

Stamp

Service □
....................................... □
Anti-corrosion check:
OK □ Not

OK*

□

*See specific page

Date: Miles (Km): Invoice number:

Comments/miscellaneous

Type of operation:

Stamp

Service □
....................................... □
Anti-corrosion check:
OK □ Not

OK*

□

*See specific page

Date: Miles (Km): Invoice number:

Comments/miscellaneous

Type of operation:

Stamp

Service □
....................................... □
Anti-corrosion check:
OK □ Not

OK*

□

*See specific page

6.10

SERVICE SHEETS

(3/6)

VIN: ..................................................................................

Date: Miles (Km): Invoice number:

Comments/miscellaneous

Type of operation:

Stamp

Service □
....................................... □
Anti-corrosion check:
OK □ Not

OK*

□

*See specific page

Date: Miles (Km): Invoice number:

Comments/miscellaneous

Type of operation:

Stamp

Service □
....................................... □
Anti-corrosion check:
OK □ Not

OK*

□

*See specific page

Date: Miles (Km): Invoice number:

Comments/miscellaneous

Type of operation:

Stamp

Service □
....................................... □
Anti-corrosion check:
OK □ Not

OK*

□

*See specific page

6.11

SERVICE SHEETS

(4/6)

VIN: ..................................................................................

Date: Miles (Km): Invoice number:

Comments/miscellaneous

Type of operation:

Stamp

Service □
....................................... □
Anti-corrosion check:
OK □ Not

OK*

□

*See specific page

Date: Miles (Km): Invoice number:

Comments/miscellaneous

Type of operation:

Stamp

Service □
....................................... □
Anti-corrosion check:
OK □ Not

OK*

□

*See specific page

Date: Miles (Km): Invoice number:

Comments/miscellaneous

Type of operation:

Stamp

Service □
....................................... □
Anti-corrosion check:
OK □ Not

OK*

□

*See specific page

6.12

SERVICE SHEETS

(5/6)

VIN: ..................................................................................

Date: Miles (Km): Invoice number:

Comments/miscellaneous

Type of operation:

Stamp

Service □
....................................... □
Anti-corrosion check:
OK □ Not

OK*

□

*See specific page

Date: Miles (Km): Invoice number:

Comments/miscellaneous

Type of operation:

Stamp

Service □
....................................... □
Anti-corrosion check:
OK □ Not

OK*

□

*See specific page

Date: Miles (Km): Invoice number:

Comments/miscellaneous

Type of operation:

Stamp

Service □
....................................... □
Anti-corrosion check:
OK □ Not

OK*

□

*See specific page

6.13

VIN: ..................................................................................

Date: Miles (Km): Invoice number:

Comments/miscellaneous

Type of operation:

Stamp

Service □
....................................... □
Anti-corrosion check:
OK □ Not

OK*

□

*See specific page

Date: Miles (Km): Invoice number:

Comments/miscellaneous

Type of operation:

Stamp

Service □
....................................... □
Anti-corrosion check:
OK □ Not

OK*

□

*See specific page

Date: Miles (Km): Invoice number:

Comments/miscellaneous

Type of operation:

Stamp

Service □
....................................... □
Anti-corrosion check:
OK □ Not

OK*

□

*See specific page

SERVICE SHEETS

(6/6)

6.14

ANTICORROSION CHECK

(1/5)

If the continuation of the warranty is subject to repair, it is indicated below.

VIN: ..........................................................

Corrosion repair operation to be carried

out:

Stamp

Date of repair:

Repair to be carried out:

Stamp

Date of repair:

Repair to be carried out:

Stamp

Date of repair:

6.15

ANTICORROSION CHECK

(2/5)

If the continuation of the warranty is subject to repair, it is indicated below.

VIN: ..........................................................

Corrosion repair operation to be carried

out:

Stamp

Date of repair:

Repair to be carried out:

Stamp

Date of repair:

Repair to be carried out:

Stamp

Date of repair:

6.16

ANTICORROSION CHECK

(3/5)

If the continuation of the warranty is subject to repair, it is indicated below.

VIN: ..........................................................

Corrosion repair operation to be carried

out:

Stamp

Date of repair:

Repair to be carried out:

Stamp

Date of repair:

Repair to be carried out:

Stamp

Date of repair:

6.17

ANTICORROSION CHECK

(4/5)

If the continuation of the warranty is subject to repair, it is indicated below.

VIN: ..........................................................

Corrosion repair operation to be carried

out:

Stamp

Date of repair:

Repair to be carried out:

Stamp

Date of repair:

Repair to be carried out:

Stamp

Date of repair:

6.18

ANTICORROSION CHECK

(5/5)

If the continuation of the warranty is subject to repair, it is indicated below.

VIN: ..........................................................

Corrosion repair operation to be carried

out:

Stamp

Date of repair:

Repair to be carried out:

Stamp

Date of repair:

Repair to be carried out:

Stamp

Date of repair:
