Renault Captur (2018 year). Instruction - part 4

1.50

WARNING LIGHTS

(5/5)

The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.

On display B



Passenger Airbag ON

Refer to the information on

“Child safety: deactivating/activating

the front passenger airbag” in Section 1.

Passenger Airbag OFF

Refer to the information on

“Child safety: deactivating/activating

the front passenger airbag” in

Section 1).

Front seat belt reminder

warning light

This lights up on the central display

when the engine is started then, if the

driver’s or front passenger’s seat belt

(if this seat is occupied) is not fastened

and the vehicle has reached approxi-

mately 12 mph (20 km/h), it flashes and

a bleep sounds for around 2 minutes.
Note: an object placed on the passen-

ger seat base may activate the warning

light in some cases.

Rear seat belt reminder (depending

on vehicle)

The

warning light comes on on

the central display, accompanied by a

message on the instrument panel, indi-

cating the number of seat belts buckled

for approximately 30 seconds each:

– the vehicle is started;

– a door is opened;

– a rear seat belt is fastened or unfas-

tened.

Check that the rear passengers are

wearing seat belts and that the number

of seat belt shown as fastened corre-

sponds to the number of rear bench

seat places occupied.

1.51

DISPLAYS AND INDICATORS

(1/2)

Rev counter 1

(graduations x 1000)

Driving style indicator 3

Please refer to the information on “Eco-

driving” in Section 2.

Low engine oil level warning

When the engine is started, display 2

alerts the driver when the oil level is at

its minimum. Refer to the information

on the “Engine oil level” in Section 4.

Fuel level gauge 4

1.52

Speedometer 5

(km or miles per hour)

Overspeed buzzer

Depending on the vehicle, a warning

beep sounds for approximately 10 sec-

onds every 30 seconds, as long as the

vehicle is travelling in excess of 75 mph

(120 km/h).

To return to the previous mode, repeat

the same operation.
Note: once the battery is switched off,

the trip computer and warning system

automatically returns to the original unit

of measurement.

DISPLAYS AND INDICATORS

(2/2)

Instrument panel in miles

(option to switch to km/h)
– With ignition off, press button 8 or 9

at the end of stalk 6 and the start

button 7;

– the speedometer unit indicator

flashes for approximately ten sec-

onds, then the new unit is displayed:

release button 8 or 9 when the unit

stops flashing.

1.53

ON-BOARD COMPUTER: general information

(1/2)

On-board computer 1

Depending on the vehicle, this includes

the following functions:
– distance travelled;

– journey settings;

– information messages;

– operating fault messages (con-

nected to the

warning light);

– warning messages (connected to the

warning light);

– vehicle settings customisation menu.
All these functions are described on the

following pages.

Display selection keys 2

and 3

Scroll through the following information

upwards (key 2) or downwards (key 3)

by pressing briefly and successively

(the display depends on the vehicle

equipment and country).
a) total mileage and trip mileage re-

corder;

b) fuel used;

c) average fuel consumption;

d) current fuel consumption;

e) estimated range;

f) distance travelled;

g) average speed;

h) distance before service;

– service

counter;

– oil change counter;

i) Reset the tyre pressure

j) cruise control/speed limiter pro-

grammed speed;

k) clock and temperature;

l) trip log, operating faults and informa-

tion message readout.

1.54

ON-BOARD COMPUTER: general information

(2/2)

Resetting the trip mileage

With “trip mileage recorder” selected on

the display, press button 2 or 3 until the

mileage recorder resets to zero.

Resetting the journey

parameters (reset button)

With one of the trip parameters selected

as the display, press and hold button 2

or 3 until the display resets.

Interpreting some of the

values displayed after

resetting

The values showing average fuel con-

sumption, range and average speed

will become more stable and reliable

the further you travel after pressing the

reset button.
For the first few miles after pressing

the reset key you will notice that the

range increases as you travel. This

range takes into account the average

fuel consumption since the last time the

reset button was pressed. Therefore,

the average fuel consumption may de-

crease when:
–

the vehicle stops accelerating;

–

the engine reaches its operating

temperature (if the engine was cold

when the reset key was pressed);

–

when driving from an urban area

onto the open road.

Automatic resetting of the

journey parameters

Resetting occurs automatically when

the maximum value of any of the pa-

rameters is exceeded.

1.55

TRIP COMPUTER: trip settings

(1/5)

The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.

Examples of selections

Interpreting the display selected

101778 km

a) Total mileage and trip mileage recorder.

112.4 km

FUEL USED

b) Journey parameters.

Fuel used.

Fuel consumed since the last reset.

AVERAGE

c) Average fuel consumption since the last reset.

The value is displayed after having travelled at least 400 metres since the last

reset.

5.8 L/100

CURRENT

d) Current fuel consumption.

This value is displayed after a speed of approximately 20 mph (30 km/h) is reached.

7.4 L/100

1.56

TRIP COMPUTER: trip settings

(2/5)

The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.

Examples of selections

Interpreting the display selected

RANGE

e) Estimated range with remaining fuel.

The value is displayed after driving 400 metres.

541 km

DISTANCE

f) Distance travelled since last reset.

522 km

AVERAGE

g) Average speed since the last reset.

The value is displayed after driving 400 metres.

123.4 km/H

1.57

TRIP COMPUTER: trip settings

(3/5)

The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.

Examples of selections

Interpreting the display selected

On-board computer with mileage-

before-service message

h) Mileage before service or oil change.

Mileage before service

With the ignition switched on, the engine not running and

the display set to “SERVICE INTERVALS”, press button 2 or 3

for approximately 5 seconds to display the mileage before serv-

ice (distance or time to the next service). When the range ap-

proaches its limit, there are several possible scenarios:

–

distance/time remaining less than 900 miles (1,500 km) or

one month: the message “Service due in” is displayed, ac-

companied by the nearest term (distance or time);

–

range equal to 0 km/miles or service date reached: the

message “Service required ” is displayed accompanied by
warning light

The vehicle requires a service as soon as possible.

SERVICE

INTERVALS

Service in

30 000 Kms / 12 MO

Service due in

300 Kms / 24 DAYS

Service required

Resetting: to reset the distance before service, press and hold button 2 or 3 for approximately 10 seconds until the display

shows the service mileage without flashing.
NB: if a service is performed without changing the engine oil, only the mileage before the next service should be reset. In the

event of an oil change, both the distance before the next service and the next oil change should be reset.

1.58

TRIP COMPUTER: trip settings

(4/5)

The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.

Examples of selections

Interpreting the display selected

On-board computer with distance before

next service message (cntd.)

h) Mileage before service or oil change.

Mileage before service

With the ignition switched on and the engine not running,

when the message “SERVICE INTERVALS” is displayed, press

button 2 or 3 for around 5 seconds to display the mileage before

the next service, then briefly press button 2 or 3 to view the

mileage before the next oil change (distance or time remaining

before the next service). When the range approaches its limit,

there are several possible scenarios:

–

distance/time remaining less than 900 miles (1,500 km) or

one month: the message “Service due in” is displayed, ac-

companied by the nearest term (distance or time);

–

range equal to 0 km/miles or service date reached: the

message “Service required ” is displayed accompanied by
warning light

The vehicle requires an oil change as soon as possible.

SERVICE

INTERVALS

Oil change in

30 000 Kms / 24 MO

Service due in

300 Kms / 24 DAYS

Service required

Depending on the vehicle, the mileage before an oil change varies according to the driving style (frequent driving at low speed,

door-to-door journeys, extensive use at idling speed, towing a trailer, etc.). The distance remaining until the next oil change can

therefore decrease more quickly in some cases than the actual distance travelled.
Resetting: to reset the mileage before the next service, press and hold button 2 or 3 for approximately 10 seconds until the

display shows the mileage before service without flashing.

NB: if a service is performed without changing the engine oil, only the mileage before the next service should be reset. In the

event of an oil change, both the distance before the next service and the next oil change should be reset.

1.59

TRIP COMPUTER: trip settings

(5/5)

Examples of selections

Interpreting the display selected

i) Reset the tyre pressure.

Please refer to the information on the “Tyre pressure

loss warning” in Section 2.

TYRE PRESSURE

: SET TPW

TYRE PRESSURE SET

SPEED LIMITER

CRUISE CONTROL

j) Cruise control/speed limiter programmed speed.

Refer to the information in “Cruise control” and

“Speed limiter” in Section 2.

13° 16:30

k) Clock and temperature.

Please refer to the information under “Clock and ex-

terior temperature”.

NO MESSAGE

MEMORISED

l) Trip log.

Successive display:

–

information messages (passenger airbag OFF etc.);

–

operating fault messages (Check injection system,

etc.).

1.60

TRIP COMPUTER AND WARNING SYSTEM: information messages

Examples of messages

Interpreting the display selected

« PARKING BRAKE ON » Indicates that the parking brake has been applied.

« PLEASE REMOVE

KEYCARD »

Request to remove the RENAULT card from the reader when you leave the vehicle.

« TRACTION

CONTROL OFF »

Indicates that you have deactivated the traction control function.

« TURN STEERINGWHEEL

+ START »

Turn the steering wheel slightly whilst pressing the vehicle start button to unlock the steering

column.

« STEERING WHEEL

NOT LOCKED »

Indicates that the steering column has not been locked.

These can help in the vehicle starting phase, or give information about a selection or a driving status.

Examples of information messages are given in the following pages.

1.61

TRIP COMPUTER AND WARNING SYSTEM: operating fault messages

These appear with the

warning light and mean that you should drive very carefully to an authorised dealer as

soon as possible. If you fail to follow this recommendation, you risk damaging your vehicle.

They disappear when the display selection key is pressed or after several seconds and are stored in the computer log. The

warning light stays on. Examples of operating fault messages are given in the following pages.

Examples of messages

Interpreting the display selected

« CLEAN DIESEL FILTER »

Indicates the presence of water in the diesel filter; contact an approved Dealer

as soon as possible.

« CHECK VEHICLE »

Indicates a fault in one of the pedal sensors, battery management system or oil

level sensor.

« CHECK AIRBAG »

Indicates a fault in the restraint system in addition to the seat belts. In the event

of an accident, it is possible that they may not be triggered.

« CHECK ANTI-POLLUTION SYSTEM »

Indicates a fault in the vehicle’s particle filter system.

1.62

TRIP COMPUTER AND WARNING SYSTEM: warning message

These appear with the

warning light and require you to stop immediately, for your own safety, as soon as traf-

fic conditions allow. Stop your engine and do not restart it. Contact an approved Dealer.

Examples of warning messages are given in the following pages. Note: the messages appear on the display either individually

or alternately (when there are several messages to be displayed), and may be accompanied by a warning light and/or a beep.

Examples of messages

Interpreting the display selected

« ENGINE FAILURE HAZARD »

Indicates an injection fault, the vehicle’s engine has overheated or there is a

serious engine fault.

« BRAKING SYSTEM FAULT »

Indicates a fault in the braking system.

« BATTERY CHARGING FAULT »

Indicates a fault in the vehicle battery charging circuit (alternator etc.).

« PUNCTURE »

Indicates that at least one wheel is punctured or severely underinflated.

1.63

Power Assisted Steering

Never drive with an inadequately

charged battery.

Variable power assisted

steering

The variable power assisted steering

system is equipped with an electronic

control system which alters the level of

assistance to suit the vehicle speed.
Steering is made easier during parking

manoeuvres (for added comfort) whilst

the force needed to steer increases

progressively as the speed rises (for

enhanced safety at high speeds).

Adjusting the steering wheel

height and depth

Pull lever 1 and place the steering

wheel in the required position; push the

lever beyond the point of resistance to

lock the steering wheel in place.
Make sure that the steering wheel is

correctly locked.

For safety reasons, only

adjust the steering wheel

when the vehicle is station-

ary.

STEERING WHEEL/POWER-ASSISTED STEERING

Never switch off the igni-

tion when travelling down-

hill, and avoid doing so in

normal driving (assistance

is not provided).

With the engine switched off, or if

there is a system fault, it is still pos-

sible to turn the steering wheel. The

force required will be greater.

Never leave the steering wheel at

full lock while stationary.

1.64

Wait a few seconds, the minutes will

flash: repeatedly press or press and

hold button 3 or 4 to set the time.
When setting is complete, the hours

and minutes remain displayed conti-

nuously for 2 seconds: your setting is

registered.
You may change the display.

Display A

To access the display 2 for setting the

time, press button 3 or 4 on the stalk 1.
Wait a few seconds; the hours and min-

utes will begin to flash. You are now in

setting mode, press and hold button 3

or 4 to set the hour.
Once the minutes flash, repeatedly

press or press and hold button 3 ou 4

to set the time.

CLOCK AND EXTERIOR TEMPERATURE

(1/2)

If the power supply is cut (battery

disconnected, supply wire cut, etc.),

the clock must be reset.
We recommend that you do not

adjust these settings while driving.

9°C 12:00

1.65

Display B

Vehicles fitted with touch-screen

multimedia, navigation aid systems,

telephones, etc.
Refer to the separate instructions for

the function to understand the special

features of this equipment.

External temperature

indicator

Special note:
When the exterior temperature is - 3°C

to + 3°C, the °C characters flash (si-

gnalling a risk of ice on the road).

External temperature in-

dicator
As ice formation is related

to climatic exposure, local

air humidity and temperature, the

external temperature alone is not

sufficient to detect ice.

CLOCK AND EXTERIOR TEMPERATURE

(2/2)

If the power supply is cut (battery disconnected, supply wire cut, etc.), the clock

must be reset.
We recommend that you do not adjust these settings while driving.

Content .. 2 3 4 5 ..
