Renault Magnum engine. Manual - part 46
6 / 10
A205
Available power supply (after ignition)
J20
F71
15
A41
E503
LH dipped beam headlight
H04
F72
10
A42
D001
Principal information display
B20
F72
10
A42
A247
Available power supply (alternator
information, engine running)
J20
F75
15
A40
J002
RH heated seat unit
I03
F75
15
A40
J003
LH heated seat unit
I03
F75
15
A40
J006
Refrigerated compartment
I03
F75
15
A40
K002
Air/air add-on heater
I40
F76
10
A40
S021
Alternator circuit earthing relay (ADR)
A40
F76
10
A40
A204
Available power supply (after master switch)
J20/J21
F77
15
A43
G012
Lighting and signalling management ECU
H04/H05
F90
3
A45
S101
Rear fog lights power supply relay
A42
F90
3
A45
S102
Main beam headlights power supply relay
A42
F90
3
A45
S103
Fog driving lights power supply relay
A42
F90
3
A45
S106
Switches night lighting power supply relay
A45
F90
3
A45
E124
LH front side/parking lights
H04
F91
10
A44
E128
LH clearance lights N° 3
H04
F91
10
A44
E129
LH clearance lights N° 4
H04
F91
10
A44
E133
LH clearance lights N° 1
H04
F91
10
A44
E134
LH clearance lights N° 2
H04
F91
10
A44
E138
LH rear side/parking lights
H04
F91
10
A44
E144
Roof LH side/parking lights
H04/H30
F91
10
A44
E150
Anti-glare strip-mounted RH marker lights
H30
F91
10
A44
E152
Left-hand side marker lamp N° 5
H04
F91
10
A44
A245
Available power supply (lighting
and side/parking lights)
H30
F92
10
A44
E122
RH clearance light N° 1
H04
F92
10
A44
E123
RH clearance light N° 2
H04
F92
10
A44
E125
RH front side/parking lights
H04
F92
10
A44
E131
RH clearance lights N° 3
H04
F92
10
A44
E132
RH clearance lights N° 4
H04
F92
10
A44
E137
RH rear side/parking lights
H04
F92
10
A44
E145
Roof LH side/parking lights
H04/H30
F92
10
A44
E149
Anti-glare strip-mounted LH marker lights
H30
F92
10
A44
E151
Right-hand side marker lamp N° 5
H04
F92
10
A44
