Audio and Telematics

Traveller-VP_en_Chap10d_RD6_ed01-2016

Receiving TA messages

Press the TA button to activate or
deactivate traffic messages.

The TA (Traffic Announcement)
function gives priority to TA alert
messages. To operate, this function
needs good reception of a radio station
transmitting this type of message.
When a traffic report is transmitted, the
current audio source (Radio, CD, ...)
is interrupted automatically to play the
TA message. Normal playback of the
audio source resumes at the end of the
transmission of the message.

Take care when increasing the volume
while listening to TA messages. The
volume may prove too high on return to
the original audio source.

Select "RadioText (TXT) display"
and confirm OK to save.

Select or deselect categories.

With the radio displayed on the
screen, press OK to display the
contextual menu.

Make a long press on this button to
display the list of categories.

Receiving INFO messages

The INFo function gives priority to TA
traffic announcements. To be active,
this function needs good reception
of a radio station that transmits this
type of message. When a message is
transmitted, the current audio source
(Radio, CD, uSB, ...) is interrupted
automatically to receive the INFo
message. Normal play resumes at the
end of the message transmission.

Radio text is information transmitted by
the radio station related to the current
programme or song.

Display RADIO TEXT

Activate or deactivate the reception of
the corresponding messages.

480

Audio and Telematics

DAB (Digital Audio Broadcasting) radio

Display options:
if active but not available, the display will
be struck out.

Preset radio station, buttons 1 to 6.
Short press: select the preset radio
station.
Long press: preset a radio station.

Display the name of the multiplex
service being used.

Display the list of all radio stations and
"multiplexes".

Represents the signal sterngth for the
band being listened to.

Display RadioText (TXT) for the current
radio station.

Display the name of the current radio
station.

If the current "DAB" radio station is not available
on "FM", "DAB FM" is barred.

When changing region, an update
of the list of preset radio stations is
advisable.

481

Audio and Telematics

Traveller-VP_en_Chap10d_RD6_ed01-2016

Select "Multimedia" and confirm.

Select "DAB / FM auto tracking"
and confirm

Long press: select the desired
categories of announcements from
Transport, News, entertainment and
Flash special (availability according
to the station).

Change of station within the same
"multiplex service".

Press the "Menu" button.

Start a search for the previous / next
"multiplex service".

Change band (FM1, FM2, DAB, ...)

Digital radio provides a superior audio
quality and also additional categories of
traffic announcements (TA INFo).
The different "multiplex services"
offer a choice of radio stations in
alphabetical order.

Digital radio

When the radio station is displayed in
the screen, press on "OK" to display
the contextual menu.
(Frequency search (RDS), DAB / FM
auto tracking, RadioText (TXT) display,
Information on the station, ...)

DAB / FM tracking

"DAB" does not have 100% coverage of
the country.
When the digital signal is weak,
"DAB / FM auto tracking" allows you to
continue listening to the same station,
by automatically switching to the
corresponding analogue "FM" station
(if there is one).
When "DAB / FM auto tracking" is
active, the DAB station will be selected
automatically.

If "DAB / FM auto tracking" is activated,
there will be a difference of a few
seconds in the programme when the
system changes to analogue "FM" radio,
with sometimes a variation in volume.

If the "DAB" station you are listening
to is not available on "FM" ("DAB/FM"
option barred), or if "DAB / FM auto
tracking" is not on, the sound will be cut
when the digital signal is too weak.

482

Audio and Telematics

Media

USB player

This unit consists of a uSB port and an
auxiliary Jack socket, depending on model.

Insert a uSB memory stick into the uSB port
or connect a uSB peripheral device to the uSB
port using a suitable cable (not supplied).
The system changes automatically to "uSB"
source.

The system creates playlists
(temporary memory), which can take
from a few seconds to several minutes
on the first connection.
Reducing the number of non-music
files and the number of folders reduces
this waiting time. Playlists are updated
every time a new uSB memory stick is
connected.

Press this button to display the
contextual menu for the Media
function.

Press this button to select the play
mode.

Press this button to confirm.

Play mode

The play modes available are:
-

Normal: the tracks are played in order,
depending on the classification of the
selected files.

Random: the tracks in an album or folder
are played in a random order.

Random on all media: all of the tracks
saved in the media are played in random
order.

Repeat: the tracks played are only those
from the current album or folder.

The choice made is displayed at the top of the
screen.

While connected by uSB, the portable
device may be charged automatically.

483

Audio and Telematics

Traveller-VP_en_Chap10d_RD6_ed01-2016

Choosing a track to play

File classification

Playing files

Make a long press on this button to
display the different classifications:

Choose by "Folder" / "Artist" /
"Genre" / "Playlist"*.

Press OK to select the desired
classification, then press OK again
to confirm.

Make a long press on this button to
display the chosen classification.

Navigate in the list using the left /
right and up / down buttons.

Confirm the selection by
pressing OK.

Press one of these buttons to go to
the previous / next track in the list.
Press and hold one of these buttons
for fast forward or fast back.

Press one of these buttons to go
to the next "Folder" / "Artist" /
"Genre" / "Playlist"* in the list.

* Depending on availability and the type of

device used.

Press one of these buttons to go to
the previous / next track.

Press one of these buttons to go to
the previous / next folder.

484

Audio and Telematics

Jack auxilary (AUX) socket

Connect the portable device (MP3 player, …) to
the auxiliary Jack socket using an audio cable
(not supplied).

Press the SOURCE button
several times in succession and
select "AUX".

First adjust the volume on your portable device
(to a high level). Then adjust the volume on
your audio system. operation of controls is via
the portable device.

Do not connect a device to both the
Jack auxiliary socket and the uSB port
at the same time.

CD player

Insert circular compact discs only.
Some anti-pirating systems, on original discs
or CDs copied using a personal recorder, may
cause faults which are no reflection on the
quality of the vehicle's player.
Insert a CD in the player, play begins
automatically.

To play a disc which has already
been inserted, press the SOURCE
button several times in succession
and select CD.

Press one of the buttons to select a
track on the CD.

Press the LIST button to display the
list of tracks on the CD.

Press and hold one of the buttons for
fast forward or fast back.

Playing an MP3 compilation

Insert an MP3 CD compilation in the player.
The audio equipment searches for all of the
music tracks, which may take anything between
a few seconds and several tens of seconds,
before play begins.

on a single disc, the CD player can
read up to 255 MP3 files spread over
8 folder levels.
However, it is advisable to keep to a
limit of two levels to reduce the access
time before the CD is played.
While the CD is being played, the folder
structure is not followed.
All of the files are displayed on a single
level.

external CD players connected via the
uSB port are not recognised by the
system.

485

Audio and Telematics

Traveller-VP_en_Chap10d_RD6_ed01-2016

To play a disc which has already
been inserted, press the SOURCE
button several times in succession
and select CD.

Press one of the buttons to select a
folder on the CD.

Press one of the buttons to select a
track on the CD.

Press the LIST button to display
the list of directories of the MP3
compilation.

Press and hold one of the buttons for
fast forward or backward play.

Bluetooth

audio streaming

Streaming allows music files on the telephone
to be played via the audio system.

Connect the telephone.
(Refer to the "Pairing a telephone" section).

Play can be controlled using the buttons on the
audio system control panel and the steering
mounted controls**. Contextual information
may be displayed in the screen.

Activate the streaming source by
pressing the SOURCE* button.

Connecting Apple

players

Connect the Apple

player to the uSB port

using a suitable cable (not supplied).
Play starts automatically.

Control is via the audio system.

The classifications available are those of the
portable device connected (artists / albums /
genres / playlists).

The version of software in the audio system
may not be compatible with the generation of
your Apple

player.

* In certain cases, play of the audio files must

be initiated from the keypad.

** If the telephone supports the function. The

audio quality depends on the quality of
transmission by the telephone.

486

Audio and Telematics

The CD player can play files with .mp3, .wma,
.wav and .aac file extensions, with a bit rate of
of 32 to 320 Kbps.
It also supports TAg mode (ID3 tag,
WMA TAg).
other file types (mp4, ...) may be played.
Files of the".wma" type should be to the
wma9 standard.
The sampling rates supported are 11, 22, 44
and 48 KHz.

File names should have less than
20 characters, avoiding special characters
(e.g.: " ?; ù) so as to avoid any reading or
display problems.

In order to be able to play a recorded CDR or
CDRW, the ISo 9660 level 1. 2 or Joliet file
format is recommended when recording.
If the disc is recorded in another format, it may
not be played correctly.
It is recommended that the same recording
format is always used for an individual disc,
with as low a speed as possible (4x maximum)
for optimum sound quality.
In the particular case of a multi-session CD, the
Joliet format is recommended.

Information and advice

use only uSB memory sticks formatted FAT32
(File Allocation Table).

It is recommended that you use
genuine Apple

uSB cables for correct

operation.

487

Audio and Telematics

Traveller-VP_en_Chap10d_RD6_ed01-2016

Telephone

Pairing a Bluetooth

telephone

As a safety measure and because it
requires the sustained attention of the
driver, the pairing of your a Bluetooth
telephone to the Bluetooth hands-free
audio system must only be carried
out with the vehicle stationary and the
ignition on

The services available depend on
the network, the SIM card and the
compatibility of the Bluetooth telephone
used.
Refer to the instructions for your
telephone and to your service provider
for the services available to you.

Activate the telephone's Bluetooth
function and ensure that it is "visible to
all" (telephone configuration).

* If your telephone is fully compatible.

The "Telephone" menu gives access to the
following functions in particular: "Directory"*,
"Calls list", "View paired devices".
Depending on the type of telephone, you may
be asked to accept or confirm access by the
system to each of these functions.

If pairing fails, the number of attempts is not
restricted.
A message appears in the screen confirming
the pairing.

Procedure from the telephone

Completing the pairing

Procedure from the system

Select the name of the system in the
list of devices detected.

To complete the pairing, whichever
procedure is used (from the telephone
or from the system), check that the
code displayed in the system and the
telephone is the same and confirm.

Press the MENU button.

Select the "Connections" menu.

Confirm with OK.

A window is displayed with a search in progress
message.

In the list of devices detected, select a
telephone to pair. only one telephone can be
paired at a time.

Confirm with OK.

Select "Search for a device".

Information and advice

go to the brand's website or more
information (compatibility, more
help, ...).

488

Audio and Telematics

Confirm with OK.

The telephone connection
automatically includes hands-free
operation and audio streaming.
The ability of the system to connect
to just one profile depends on the
telephone. Both profiles may connect
by default.

A number indicates the profile of the
connection with the system:
-

1 for media or 1 for telephone.

2 for media and telephone.

When you delete a pairing in the
system, remember to delete it from your
telephone as well.

Indicates that a device is connected.

Indicates the audio streaming profile.

Indicates the hands-free telephone
profile.

Press MENU.

Managing connections

Select "Connections".

Select "Connections management"
and confirm. The list of paired
devices is displayed.

Select a telephone.

Then select and confirm:
- "Connect telephone" /

"Disconnect telephone":

to connect / disconnect the
telephone or the hands-free kit
only.

- "Connect media player" /

"Disconnect media player":

to connect / disconnect
streaming only.

- "Connect telephone +

media player" / "Disconnect
telephone + media player":

to connect / disconnect the
telephone (hands-free kit and
streaming).

- "Delete connection": to delete

the pairing.

489

Audio and Telematics

Traveller-VP_en_Chap10d_RD6_ed01-2016

Receiving a call

An incoming call is announced by a ring and a
superimposed display in the screen.

Select the "YES" tab in the screen
using the buttons.

Confirm with OK.

Press this button at the steering
mounted controls to accept the call.

Making a call

In the "Telephone" menu.

Select "Call".

Select "Calls list".

Select "Dial".

Select "Directory".

Press this button for more than two
seconds for access to your directory,
then navigate using the thumb wheel.

In the "Telephone" menu.

Select "End call".

Ending a call

During a call, press one of the
buttons for more than 2 seconds.

Confirm with OK to end the call.

The system accesses the telephone's
contacts directory, depending on its
compatibility, and while it is connected
by Bluetooth

With certain telephones connected by
Bluetooth, you can send a contact to
the directory of the audio system.
Contacts imported in this way are
saved in a permanent directory
visible to all, whatever the telephone
connected.
The menu for the directory is not
accessible if it is empty.

490

Audio and Telematics

During a call, press OK to display the
contextual menu.

In the contextual menu, select "End
call" to end the call.

Managing calls

Hang up

(so that the caller cannot hear)

In the contextual menu:
-

select "Micro OFF" to switch off
the microphone.

deselect "Micro OFF" to switch
the microphone on.

In the contextual menu:
-

select "Telephone mode" to
transfer the call to the telephone
(for example, to leave the vehicle
while continuing a conversation).

deselect "Telephone mode" to
transfer the call to the vehicle.

Microphone off

Telephone mode

If the contact has been cut off, when you
reconnect on returning to the vehicle,
the Bluetooth connection will be restored
automatically and sound returned to the
system (depending on the compatibility of the
telephone).
In some cases telephone mode must be
activated from the telephone.

From the contextual menu, select
"DTMF tones" and confirm to use
the digital keypad to navigate in the
interactive voice response menu.

From the contextual menu, select
"Switch" and confirm to return to a
call left on hold.

Interactive voice response

Dual call

Confirm with OK.

491

Audio and Telematics

Traveller-VP_en_Chap10d_RD6_ed01-2016

To modify the contacts saved in the
system, press MENU then select
"Telephone" and confirm.
Select "Directory management"
and confirm.
You can:
- "Consult an entry",
- "Delete an entry",
- "Delete all entries".

Make a long press on SRC/TEL.

The system accesses the telephone's
contacts directory, depending on
its compatibility, and while it is
connected by Bluetooth.

With certain telephones connected
by Bluetooth you can send a contact
to the directory of the audio system.
Contacts imported in this way are
saved in a permanent directory
visible to all, whatever the telephone
connected.
The menu for the directory is not
accessible if it is empty.

Select "Directory" to see the list of
contacts.

Directory

Confirm with OK.

Voice recognition

This function allows you to use your
smartphone's voice recognition via the system.

To start voice recognition, depending on the
type of steering mounted controls:

Make a long press on the end of the lighting
control stalk.

Press this button.

Voice recognition requires the use of a
compatible smartphone first connected
to the vehicle by Bluetooth.

492

Audio and Telematics

The table below gives answers to the most frequently asked questions on your audio system.

QUESTION

ANSWER

SOLUTION

With the engine off, the
audio system switches off
after a few minutes of use.

When the engine is switched off, the audio system operating time
depends on the state of charge of the battery.
The switch-off is normal: the audio equipment switches to economy
mode and switches off to prevent discharging of the vehicle's
battery.

Start the vehicle's engine to increase the battery
charge.

The message "the audio
system is overheated"
appears on the display.

In order to protect the installation if the surrounding temperature
is too high, the audio system switches to an automatic thermal
protection mode leading to a reduction in volume or CD play
stopping.

Switch the audio system off for a few minutes to
allow the system to cool.

Frequently asked questions

QUESTION

ANSWER

SOLUTION

There is a difference in
sound quality between the
different audio sources
(radio, CD...).

For optimum sound quality, the audio settings (Volume,Bass, Treble,
Ambience and Loudness) can be adapted to the different sound
sources, which may result in audible differences when changing
source (radio, CD...).

Check that the audio settings (Volume, Bass,
Treble, Ambience and Loudness) are adapted to
the sources listened to. It is advisable to set the
audio functions (Bass, Treble, Front-Rear Balance
and Left-Right Balance) to the middle position,
select the musical ambience "None" and set the
loudness correction to the "Active" position in CD
mode or to the "Inactive" position in radio mode.

Radio

493

Audio and Telematics

Traveller-VP_en_Chap10d_RD6_ed01-2016

QUESTION

ANSWER

SOLUTION

The preset stations do
not function (no sound,
87.5 Mhz is displayed...).

An incorrect waveband is selected.

Press the BAND AST button to return to the
waveband (FM, FM2, DAB, AM) on which the
stations are preset.

The traffic announcement
(TA) is displayed. I do
not receive any traffic
information.

The radio station is not part of the regional traffic information
network.

Tune to a radio station which broadcasts traffic
information.

The quality of reception of
the radio station listened
to gradually deteriorates
or the stored stations do
not function (no sound,
87.5 Mhz is displayed...).

The vehicle is too far from the transmitter used by the station
listened to or there is no transmitter in the geographical area
through which the vehicle is travelling.

Activate the RDS function to enable the system
to check whether there is a more powerful
transmitter in the geographical area.

The environment (hills, buildings, tunnels, underground car parks...)
block reception, including in RDS mode.

This phenomenon is normal and does not indicate
a fault in the audio system.

The aerial is absent or has been damaged (for example when going
through an automatic car wash or into an underground car park).

Have the aerial checked by a franchised dealer.

Sound cut-outs of 1 to
2 seconds in radio mode.

During this brief sound cut-out, the RDS searches for another
frequency giving better reception of the station.

Deactivate the RDS function if the phenomenon is
too frequent and always on the same route.

494

Audio and Telematics

Media

QUESTION

ANSWER

SOLUTION

The Bluetooth connection
is broken.

The state of charge of the device may be too low.

Charge the battery of the portable device.

The message "uSB device
error" is displayed in the
screen.

The uSB memory stick is not recognised.
The uSB memory stick may be corrupt.

Reformat the uSB memory stick.

The CD is ejected every
time or is not played.

The CD is upside down, cannot be read, does not contain audio files
or contains an audio files of a format that cannot be played by the
audio system.
The CD is protected by an anti-pirating system not recognised by
the audio system.

Check that the CD is inserted in the player the
right way up.

Check the condition of the CD: the CD cannot
be played if it is too damaged.

Check the content in the case of a recorded
CD: consult the advice in the "Audio" section.

Due to their quality level, certain writeable
CDs will not be played by the audio system.

The sound from the CD is
poor.

The CD used is scratched or of poor quality.

Insert a good quality CD and store them in
suitable conditions.

The audio settings (base, treble, ambience) are unsuitable.

Return bass and treble settings to 0, without
selecting an ambience.

I am unable to play
the music files on my
smartphone via the uSB
port.

Depending on the smartphone, access by the audio system to music
on the smartphone may have to be approved on the latter.

Manual activate the MTP profile on the
smartphone (uSB settings menu).

Peugeot Traveller (2016 year). Instruction - part 31
