Peugeot Traveller (2016 year). Instruction

383

Audio and Telematics

Traveller-VP_en_Chap10b_NAC-1_ed01-2016

Level 1

Level 2

Comments

Radio Media

Secondary page

Music files

Albums

Choose a selection mode.

Artists

Genres

Playlists

Folders

Radio Media

Secondary page

Managing photos

USB

Display photos.
The system supports the following image
formats: .gif, .jpg, .jpeg, .bmp, .png, .raw and .tiff
with a maximum file size of 10 Mb per image.

384

Audio and Telematics

Traveller-VP_en_Chap10b_NAC-1_ed01-2016

Press Radio Media to display the
menu.

Press the "OPTIONS" button to go to
the secondary page.

Press "Frequency".

enter the values using the virtual
keypad.
First enter the units then click on the
decimals zone to enter the figures
after the decimal point.

Press one of the buttons for an
automatic search for radio stations.

Press Radio Media to display the
primary page.

Radio

Selecting a station

Radio reception may be affected by
the use of electrical equipment not
approved by the brand, such as a uSB
charger connected to the 12 V socket.
The exterior environment (hills,
buildings, tunnel, car park, below
ground...) may prevent reception,
even in RDS station tracking mode.
This phenomenon is normal in the
propagation of radio waves and is in no
way indicative of a fault with the audio
system.

Select "Radio stations" in the
secondary page.

Move the cursor for a manual search
for frequencies up or down.

Select a radio station or frequency (refer to the
corresponding section).

Press "Presets".

Make a long press on one of the
buttons to preset the station.

Preset a station

Press "Confirm".

385

Audio and Telematics

Traveller-VP_en_Chap10b_NAC-1_ed01-2016

Press Radio Media to display the
primary page.

Press the "OPTIONS" button to go to
the secondary page.

Select "Radio settings".

Select "General".

Select "Announcements".

Activate/deactivate "Station follow".

Activate / Deactivate "Display radio
text".

Activate / Deactivate "Traffic
announcement".

Activate/ Deactivate RDS

RDS, if activated, allows you to continue
listening to the same station by automatic
retuning to alternative frequencies. However,
in certain conditions, coverage of an RDS
station may not be assured throughout the
entire country as radio stations do not cover
100 % of the territory. This explains the loss
of reception of the station during a journey.

Press "Confirm".

The "radiotext" function allows
information transmitted by the radio
station and related to the station or the
song playing to be displayed.

Display text information

Play TA messages

The TA (Traffic Announcement)
function gives priority to TA alert
messages. To operate, this function
needs good reception of a radio station
that carries this type of message. While
traffic information is being broadcast,
the current media is automatically
interrupted so that the TA message can
be heard. Normal play of the media
previously playing is resumed at the
end of the message.

386

Audio and Telematics

Traveller-VP_en_Chap10b_NAC-1_ed01-2016

Display of options:
if active but not available,
the display will be greyed
out.
if active and available, the
display will be clear.

Display "Radiotext" for the
current station.

Switch between the page with the presets and the page
with the frequencies.

Change of band.

Display of the name of the current station
and "multiplex" being listened to, also
called an "ensemble".

Display of the list of radio
stations.

Next "multiplex".
Next radio station.

Secondary page.

Select audio source.

Previous "Multiplex".
Previous radio station.

DAB radio (Digital Audio Broadcasting)

Terrestrial Digital Radio

If the current "DAB" station is not available on
"FM" the "DAB/FM" option is greyed out.

387

Audio and Telematics

Traveller-VP_en_Chap10b_NAC-1_ed01-2016

Select the audio source.

Press Radio Media to display the
primary page.

Press "Band" to select the "DAB"
waveband.

Press Radio Media to display the
primary page.

Press the "OPTIONS" button to go to
the secondary page.

DAB / FM auto tracking

Digital radio

"DAB" does not cover 100% of the
territory.
When the digital radio signal is poor,
"DAB/FM auto tracking" allows you to
continue listening to the same station,
by automatically switching to the
corresponding "FM" analogue station
(if there is one).

If "DAB / FM auto tracking" is activated,
there is a difference of a few seconds
when the system switches to "FM"
analogue radio with sometimes a
variation in volume.
once the digital signal is restored,
the system automatically changes back
to "DAB".

Digital radio provides higher quality
reception.
The different multiplexes offer a
choice of radio stations arranged in
alphabetical order.

If the "DAB" station being listened to
is not available on "FM" ("DAB/FM"
option greyed out), or "DAB/FM auto
tracking" is not activated, the sound
will cut out while the digital signal is too
weak.

Select "Radio settings".

Select "General".

Activate / Deactivate "Station
follow".

Press "Confirm".

388

Audio and Telematics

Traveller-VP_en_Chap10b_NAC-1_ed01-2016

Media

USB player

Selecting the source

Select "Source".

Press Radio Media to display the
primary page.

The system builds playlists (in temporary
memory), an operation which can take from
a few seconds to several minutes at the first
connection.
Reduce the number of non-music files and the
number of folders to reduce the waiting time.
The playlists are updated every time the
ignition is switched off or connection of a uSB
memory stick. The lists are memorised: if they
are not modified, the subsequent loading time
will be shorter.

Insert the uSB memory stick into the uSB port
or connect the uSB device to the uSB port
using a suitable cable (not supplied).

Auxiliary (AUX) socket

First adjust the volume of your portable device
(to a high level). Then adjust the volume of your
audio system.
Display and management of the controls are
via the portable device.

This source is only available if "Auxiliary input"
has been checked in the audio settings.

Connect the portable device (MP3 player…) to
the auxiliary Jack socket using an audio cable
(not supplied).

Choose the source.

Bluetooth

audio streaming

Streaming allows you to listen to music from
your telephone.

The Bluetooth profile must be activated. First
adjust the volume on your portable device (to a
high level).
Then adjust the volume of your audio system.

If play does not start automatically, it may be
necessary to start the audio playback from the
telephone.
Control is from the portable device or by using
the audio system buttons.

once connected in streaming mode,
the telephone is considered to be a
media source.

389

Audio and Telematics

Traveller-VP_en_Chap10b_NAC-1_ed01-2016

Connecting Apple

players

Connect the Apple

player to the uSB port

using a suitable cable (not supplied).
Play starts automatically.

Control is via the audio system.

The classifications available are those
of the portable device connected
(artists / albums / genres / playlists /
audiobooks / podcasts).
The default classification used is by
artist. To modify the classification used,
return to the first level of the menu
then select the desired classification
(playlists for example) and confirm
to go down through the menu to the
desired track.

The version of software in the audio system
may not be compatible with the generation of
your Apple

player.

The audio equipment will only play audio
files with ".wma, .aac, .flac, .ogg and
.mp3" file extensions and with a bit rate of
between 32 Kbps and 320 Kbps.
It also supports VBR (Variable Bit Rate) mode.
No other type of file (.mp4, ...) can be played.
".wma" files must be of the standard wma 9 type.
The sampling rates supported are 32, 44 and
48 KHz.

It is advisable to restrict file names to
20 characters, without using of special
characters (e.g.: " " ? ; ù) to avoid any playing
and displaying problems.

Information and advice

use only uSB memory sticks formatted FAT 32
(file allocation table).

The system supports uSB mass
storage devices, BlackBerry

devices

or Apple

players via uSB ports. The

adaptor cable is not supplied.
Control of the peripheral device is with
the audio system controls.
other peripherals, not recognised on
connection, must be connected to the
auxiliary socket using a Jack cable (not
supplied) or via Bluetooth streaming,
depending on compatibility.

It is recommended that the uSB cable
for the portable device is used.

390

12:13

23 °C

531 kHz

12:13

23 °C

531 kHz

Audio and Telematics

Traveller-VP_en_Chap10b_NAC-1_ed01-2016

Level 1

Telephone

Level 2

Level 3

Known devices

Recent calls

Contacts and favourites

391

Audio and Telematics

Traveller-VP_en_Chap10b_NAC-1_ed01-2016

Level 1

Level 2

Level 3

Comments

Telephone

Bluetooth

Contact

All

View contacts according to presentation choices.
Select a contact or a favourite saved in the
system via the profile selected to start the call.

Telephone

Address

Favourites

Sort the contacts by Surname-First name or First
name-Surname.

update the contacts from the telephone.

Search

Confirm

Search for a contact in the directory.

Create

Telephone

Create a new contact in the system.

Address

Confirm

Telephone

Bluetooth

Calls

All

View calls according to choice of presentation.
Select a contact to start the call.

Incoming

Outgoing

Missed

View details for the contact.

392

Audio and Telematics

Traveller-VP_en_Chap10b_NAC-1_ed01-2016

Level 1

Level 2

Settings - Bluetooth

Bluetooth connection

Messages

Email

393

Audio and Telematics

Traveller-VP_en_Chap10b_NAC-1_ed01-2016

Level 1

Level 2

Comments

Telephone

Secondary page

Bluetooth

connection

All

Display all telephones, connected or
disconnected, recognised by the system.

Connected

Display all connected telephones.

Search

Start the search for a device to connect.

Telephone

Secondary page

Messages

All

Display messages according to the choice made.

Received

Sent

Telephone

Secondary page

Email

Received

Display emails according to the choice made.

Sent

Not read

Mailbox

394

Audio and Telematics

Traveller-VP_en_Chap10b_NAC-1_ed01-2016

Level 1

Level 2

Settings - Bluetooth

Options

Quick messages

395

Audio and Telematics

Traveller-VP_en_Chap10b_NAC-1_ed01-2016

Level 1

Level 2

Comments

Telephone

Secondary page

Options

Security

Make driving safe.

Voicemail

enter and save the number for the telephone
voicemail.

Ringtone

Adjust the ringtone volume.

Statistics

Display data for the telephone connected.

Confirm

Save the options.

Telephone

Secondary page

Quick messages

Delayed

Select a quick message from the categories, as
required.

My arrival

Not available

Other

Create

Create a quick message.

396

Audio and Telematics

Traveller-VP_en_Chap10b_NAC-1_ed01-2016

Pairing a Bluetooth

telephone

As a safety measure and because it
requires sustained attention by the
driver, the pairing of a Bluetooth mobile
telephone with theBluetooth hands-free
system of your audio system must be
done with the vehicle stationary and
the ignition on.

Procedure from the telephone

Select the system name in the list of
devices detected.

In the system, accept the connection request
from the telephone.

Procedure from the system

Press Telephone to display the
primary page.

Press Connect telephone.

Select "Search".
The list of telephones detected is
displayed.

If the pairing procedure fails, it is recommended
that you deactivate and then reactivate the
"Bluetooth" function in your telephone.

The system offers to connect the telephone
with 3 profiles:
-

Telephone (hands-free kit, telephone
only),

Streaming (wireless play of audio files on
the telephone),

Mobile internet data.

Depending on the type of telephone,
you may be asked to accept or not
the transfer of your contacts and
messages.

Select the name of the chosen
telephone in the list.

Press "Confirm".

Select one or more profiles.

or.

Activate the Bluetooth function on the
telephone and ensure that it is "visible
to all" (telephone configuration).

To complete the pairing, whichever
procedure used (from the telephone or
from the system), ensure that the code
is the same in the system and in the
telephone.

The "Mobile internet data" profile
must be activated for connected
navigation, having first activated
sharing of this connection on your
smartphone.

Connection sharing

397

Audio and Telematics

Traveller-VP_en_Chap10b_NAC-1_ed01-2016

Press Telephone to display the
primary page.

Select "Bluetooth connection" to
display the list of paired devices.

on return to the vehicle, if the last
telephone connected is present again,
it is automatically recognised and
within about 30 seconds of switching
on the ignition, the connection is
established without any action on your
part (Bluetooth activated).

The services available depend on
the network, the SIM card and the
compatibility of the Bluetooth devices
used. Check in your telephone's
manual and with your service provider
for the services available to you.

The ability of the system to connect with
just one profile depends on the telephone.
All three profiles may connect by default.

go to the brand's website for more information
(compatibility, additional help, ...).

To modify the connection profile:

Automatic reconnection

Press the "details" button.

Press the "OPTIONS" button to go to
the secondary page.

Press on "Confirm".

Select one or more profiles.

The profiles compatible with the system
are HFP, oPP, PBAP, A2DP, AVRCP,
MAP and PAN.

398

Audio and Telematics

Traveller-VP_en_Chap10b_NAC-1_ed01-2016

Receiving a call

An incoming call is announced by a ring and a
superimposed display in the screen.

Make a short press on the steering
mounted TEL button to accept an
incoming call.

Make a long press

on the steering mounted TEL button
to reject the call.

And

Select "End call".

Press on the name of the telephone
chosen in the list to disconnect it.
Press again to connect it.

Select the basket at top right of the
screen to display a basket alongside
the telephone chosen.

Press the basket alongside the
telephone chosen to delete it.

Managing paired telephones

This function allows the connection or
disconnection of a peripheral device as
well as the deletion of a pairing.

Press Telephone to display the
primary page.

Press the "OPTIONS" button to go to
the secondary page.

Select "Bluetooth connection" to
display the list of paired peripheral
devices.

Deleting a telephone

Peugeot Traveller (2016 year). Instruction - part 25
